Product Overview
The BENTLY 24765-02-01 is a high-performance shielded cable assembly designed to serve as a reliable link in Bently Nevada’s machinery monitoring systems, facilitating precise signal transmission between proximity probes and signal conditioners or monitoring modules. As a critical accessory in the brand’s portfolio, this cable ensures that raw vibration, displacement, and position data from rotating machinery sensors reaches processing units without degradation, supporting accurate machinery health assessments.
The BENTLY 24765-02-01 is engineered for durability, with a construction tailored to withstand the harsh conditions of industrial environments—including exposure to oils, chemicals, and extreme temperatures. Its design minimizes electromagnetic interference (EMI) and signal loss, which is vital for maintaining the integrity of low-level signals from proximity probes. What sets the BENTLY 24765-02-01 apart is its seamless compatibility with Bently Nevada’s 3300 and 3500 series probes and monitors, making it a trusted choice for critical applications where data accuracy directly impacts maintenance decisions and operational safety.
Technical Specifications
| Parameter |
Value |
| Product Model |
BENTLY 24765-02-01 |
| Manufacturer |
Bently Nevada |
| Product Type |
Shielded Proximity Probe Cable Assembly |
| Cable Length |
5 meters |
| Connector Type |
M12 male (probe end) to stripped/tinned leads (monitor end) |
| Cable Material |
Oil-resistant thermoplastic elastomer (TPE) |
| Shielding |
Braided copper shield with drain wire for EMI protection |
| Operating Temperature Range |
-40°C to +100°C |
| Voltage Rating |
30 VDC |
| Chemical Resistance |
Resistant to mineral oils, greases, and mild solvents |
| Bend Radius |
Minimum 10 mm (static), 20 mm (dynamic) |
| Compatibility |
3300 series proximity probes, 3500/18 signal conditioners |
| Compliance |
RoHS, CE |
Key Features and Benefits
The BENTLY 24765-02-01 delivers exceptional signal integrity through its braided copper shielding, which effectively blocks EMI from nearby electrical equipment—critical for preserving the accuracy of low-amplitude signals from proximity probes. This ensures that even subtle machinery vibrations or shaft displacement measurements are transmitted without distortion, supporting reliable fault detection.
Constructed from oil-resistant TPE, the BENTLY 24765-02-01 withstands exposure to industrial fluids and mechanical abrasion, making it suitable for installation in dirty or high-oil environments such as turbine enclosures or compressor rooms. Its wide operating temperature range (-40°C to +100°C) ensures performance stability in both cold storage areas and high-heat industrial zones, enhancing versatility across applications.
The cable’s 5-meter length balances flexibility and manageability, allowing routing between probes and monitoring modules in typical machinery setups without excess slack. Compatibility with Bently Nevada’s 3300 probes and 3500 signal conditioners simplifies integration into existing systems, reducing installation time and minimizing the risk of connection errors.
Application Scenarios
The BENTLY 24765-02-01 is widely used in industries where precise machinery monitoring is essential. In coal-fired power plants, it connects 3300 series proximity probes on steam turbine shafts to 3500/18 signal conditioners, ensuring accurate transmission of shaft displacement data—critical for detecting rotor rubs or misalignment that could lead to costly outages.
In oil refineries, the BENTLY 24765-02-01 links vibration probes on centrifugal pumps to monitoring systems, withstanding exposure to hydrocarbon vapors and high ambient temperatures. Its chemical resistance prevents degradation from oil leaks, ensuring consistent signal transmission for early detection of bearing wear.
Chemical processing facilities utilize the BENTLY 24765-02-01 to connect probes on agitator motors to control rooms, where its shielding protects against EMI from nearby variable frequency drives (VFDs), ensuring reliable vibration data for maintaining process efficiency.
In paper mills, the cable connects probes on roller bearings to monitoring modules, withstanding the humid, dust-laden environment and ensuring accurate data to prevent unplanned downtime in production lines.
Related Models
24765-02-02 – Extended-length variant of BENTLY 24765-02-01 with a 10-meter cable for larger installation distances.
24765-01-01 – Previous generation cable of BENTLY 24765-02-01 with basic shielding, suitable for less EMI-sensitive applications.
330180-90-00 – Bently Nevada signal conditioner fully compatible with BENTLY 24765-02-01 for processing transmitted signals.
24765-02-03 – High-temperature variant of BENTLY 24765-02-01 rated up to 125°C, ideal for furnace-associated machinery.
330130-045-01-00 – 3300 series proximity probe commonly paired with BENTLY 24765-02-01 in vibration monitoring setups.
24765-02-04 – Shortened 2-meter version of BENTLY 24765-02-01 for compact installations where probes are close to monitors.
Installation and Maintenance
Installation of BENTLY 24765-02-01 requires routing the cable away from high-voltage lines and VFDs to minimize EMI interference. Secure the cable using plastic clips to prevent sagging or contact with moving machinery parts, which could cause abrasion. Ensure the M12 connector is fully seated on the probe to maintain a tight seal, and strip/tinned leads are properly terminated to the monitor module’s terminals with secure, insulated connections.
For maintenance, inspect BENTLY 24765-02-01 quarterly for signs of jacket damage, such as cuts or cracks, especially in high-traffic areas. Check connector integrity to ensure no moisture or debris has entered the M12 fitting, which could degrade signal quality. Clean the shield drain wire connection annually to prevent corrosion, which can compromise EMI protection. Replace the cable every 6-8 years under normal operation, or immediately if damage to the shielding or jacket is detected, to maintain reliable signal transmission.
Product Warranty
The BENTLY 24765-02-01 is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., covering manufacturing defects and performance issues under normal operating conditions. During this period, we provide free replacement for any unit that fails to meet signal integrity or durability standards, ensuring minimal disruption to your machinery monitoring setup. Our technical support team offers guidance on installation, routing, and compatibility with Bently Nevada systems, leveraging over a decade of industrial automation experience. We stand behind the quality of BENTLY 24765-02-01, ensuring customers receive consistent performance and responsive service to support their critical monitoring needs.
