BENTLY 3500/15 114M5330-01 | 8mm Eddy Current Proximity Probe
No.3500/15 114M5330-01
Brand: BENTLY Model:3500/15 114M5330-01 Product type:8mm Eddy Current Proximity Probe Payment method: Wire transfer, Western Union Port of shipment for remittance: Xiamen, China Delivery time: 1-3 working days Condition: 100% original Warranty: 12 months
Product Overview The330104-00-05-10-02-00is a high-precision eddy current proximity probe from Bently Nevada’s 3300 XL series, engineered to deliver non-contact monitoring of rotating machinery health. As a critical component of predictive maintenance systems, this probe measures shaft vibration, axial displacement, and rotational speed by detecting minute changes in electromagnetic fields induced by conductive surfaces like turbine shafts or compressor rotors.
Part of Bently Nevada’s Machinery Protection System ecosystem,330104-00-05-10-02-00integrates seamlessly with 3300 XL proximitor sensors and extension cables to form a complete measurement chain. Its robust design ensures reliable performance in extreme environments, withstanding temperatures from -51°C to 177°Cwhile maintaining ±0.5% full-scale accuracy. This makes it indispensable for industries like power generation, oil refining, and heavy manufacturing, where early detection of imbalances, misalignments, or bearing wear is essential to prevent catastrophic failures.
Technical Specifications
Parameter
Value
Product Model
330104-00-05-10-02-00
Manufacturer
Bently Nevada (GE)
Product Type
8mm Eddy Current Proximity Probe
Measurement Range
±1.27 mm (±50 mils)
Sensitivity
200 mV/mil (7.87 V/mm)
Frequency Response
0–10 kHz
Operating Temperature
-51°C to 177°C (probe); -51°C to 177°C (cable); -35°C to 85°C (proximitor)
Thread Size
M10×1 (metric)
Cable Length
1.0 meter (integrated)
Connector Type
Miniature coaxial ClickLoc
Environmental Rating
IP65 (when properly terminated)
Compatibility
3300 XL proximitors, 3500 Machinery Protection System
Linearity
±1% of full scale
Target Material
AISI 4140 steel (factory-calibrated)
Key Features and Benefits High Precision and Stability: The330104-00-05-10-02-00achieves exceptional linearity across its ±1.27 mm measurement range, ensuring accurate detection of shaft movements as small as 0.006 mm. Its double-layer braided copper shielding and advanced signal conditioning minimize electromagnetic interference (EMI), making it ideal for noisy industrial settings like refineries or power plants.
Rugged Construction: Built with a stainless steel housing and oil-resistant polyurethane jacket, this probe resists chemical exposure, abrasion, and extreme temperatures. The integrated 1.0-meter CableLoc cable design provides a secure connection capable of withstanding 330 N (75 lbf) of tensile force, preventing accidental dislodgment in high-vibration environments.
Interchangeable System Design: Part of Bently Nevada’s 3300 XL ecosystem,330104-00-05-10-02-00allows seamless swapping of probes, cables, and proximitors without recalibration. This reduces maintenance complexity and downtime, supporting rapid component replacement during predictive maintenance cycles.
API 670 Compliance: The probe meets rigorous API 670 standards for machinery protection systems, ensuring compliance in critical applications like steam turbine monitoring. Its compatibility with the 3500 system enables real-time data integration with SCADA platforms, facilitating centralized diagnostics and control.
Application Scenarios Power Generation: In coal-fired power plants,330104-00-05-10-02-00monitors steam turbine shafts for radial vibration, detecting early signs of rotor imbalance or bearing degradation. By transmitting data to a 3500 system, it helps operators schedule maintenance before vibrations escalate to dangerous levels.
Oil & Gas: Offshore platforms use this probe on centrifugal compressors to measure axial displacement, critical for preventing seal failures caused by saltwater corrosion. Its high-temperature tolerance allows continuous operation near heated pipelines or processing units.
Heavy Manufacturing: In steel mills,330104-00-05-10-02-00tracks the rotational speed and runout of rolling mill spindles, ensuring precise alignment and reducing material waste. Its non-contact design eliminates wear from physical sensors, extending equipment lifespan.
Related Models 330101-00-30-10-02-00– 8mm probe with 3.0-inch threaded housing, ideal for deep mounting in machinery casings. 330180-91-00– 3300 XL proximitor sensor that converts probe signals to 4–20 mA outputs for PLC integration. 330130-030-00-00– 3.0-meter extension cable with ClickLoc connectors, compatible with330104-00-05-10-02-00for longer installations. 330703-000-120-10-02-00– High-temperature variant rated for -52°C to +218°C, suitable for furnace-adjacent machinery. 3500/42M 140482-01– Vibration monitoring module that pairs with330104-00-05-10-02-00in the 3500 system for multi-channel analysis.
Installation and Maintenance Installation: Mount330104-00-05-10-02-00using its M10×1 thread into pre-drilled housing ports, ensuring the probe tip aligns perpendicularly with the target surface. Secure the cable away from high-voltage lines and heat sources exceeding 177°C. Proper grounding of the proximitor and shielded cabling is essential to minimize EMI.
Maintenance: Conduct quarterly inspections to check for cable abrasion, connector tightness, and probe alignment. Calibrate annually using a traceable standard to verify sensitivity and linearity. Replace the probe if signal drift exceeds ±5% of full scale, typically after 8–10 years of continuous operation.
Product Warranty The330104-00-05-10-02-00is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., covering defects in materials or workmanship. This warranty reflects our commitment to Bently Nevada’s engineering excellence and our global support network, which provides prompt assistance for installation, troubleshooting, and replacements. Direct overseas sourcing ensures rapid delivery of genuine spare parts, minimizing downtime for your machinery protection system.
Company Introduction: We offer a one-year warranty and free replacement service： Xiamen Xiongba E-commerce Co., Ltd. Branch specializes in industrial automation, focusing on Distributed Control Systems (DCS), robot systems, and large-scale servo control modules. Our product portfolio includes PLCs, MOTOROLA MVME modules, Anybus converters, and industrial PCs. With over a decade of experience, we source directly from overseas to provide high-quality spare parts at competitive prices, solving procurement challenges for global industries.
