Product Overview
The 3500/22M 288055-01 is a high-performance communication gateway module designed for Bently Nevada’s 3500 machinery protection system, serving as a critical interface between industrial monitoring sensors and enterprise-level data systems. As part of the 3500 series, its primary role is to aggregate real-time data from vibration monitors, temperature sensors, and position probes—then transmit this information to SCADA systems, HMIs, or cloud-based analytics platforms via multiple industrial protocols. This makes the 3500/22M 288055-01 essential for industries where proactive machinery health monitoring reduces downtime and operational risks.
What sets the 3500/22M 288055-01 apart is its advanced protocol support and redundant architecture. It seamlessly integrates with 3500 modules like the 3500/15 vibration monitor and 3500/42 temperature module, supporting both legacy (Modbus RTU) and modern (OPC UA, Ethernet/IP) communication standards. Its rugged design ensures reliable operation in harsh environments—from high-vibration turbine rooms to corrosive chemical plants—while its hot-swappable redundancy capability guarantees uninterrupted data flow even if a module fails. Whether deployed in power generation, oil and gas, or manufacturing, the 3500/22M 288055-01 ensures critical machinery data reaches decision-makers in real time.
Technical Specifications
| Parameter |
Value |
| Product Model |
3500/22M 288055-01 |
| Manufacturer |
Bently Nevada |
| Product Type |
Communication Gateway Module (3500 Series) |
| Supported Protocols |
OPC UA, Ethernet/IP, Modbus TCP/IP, Modbus RTU |
| Communication Ports |
2 x Gigabit Ethernet, 1 x RS-485 |
| Operating Voltage |
24 VDC (±10%) from 3500 chassis |
| Power Consumption |
≤15 W |
| Operating Temperature |
-40°C to 70°C (-40°F to 158°F) |
| Storage Temperature |
-55°C to 85°C (-67°F to 185°F) |
| Humidity |
0–95% non-condensing |
| Vibration Resistance |
5–2000 Hz, 1.0 g RMS |
| Shock Resistance |
15 g, 11 ms, half-sine |
| Certifications |
UL, CE, ATEX, IECEx |
| Redundancy Support |
Hot-standby with automatic failover |
| Data Update Rate |
≤10 ms for critical parameters |
Key Features and Benefits
The 3500/22M 288055-01 excels in protocol flexibility, supporting OPC UA for secure cloud connectivity, Ethernet/IP for industrial networks, and Modbus for legacy systems. This eliminates the need for external protocol converters, simplifying integration in mixed-technology environments. For example, it can simultaneously transmit vibration data to a plant’s SCADA system via Ethernet/IP while sending temperature trends to a cloud analytics platform via OPC UA.
Redundancy is a critical strength. When deployed in pairs, the modules share data transmission duties, automatically switching to the backup if one fails. This ensures continuous monitoring of critical assets like turbines or compressors, where communication interruptions could delay fault detection and lead to costly downtime.
Durability is engineered into its design. The module’s robust aluminum housing resists vibration, shock, and extreme temperatures, making it suitable for harsh environments. Its conformal-coated circuit boards protect against dust and moisture, ensuring reliable operation in offshore platforms, mines, or chemical plants.
Diagnostic capabilities enhance maintainability. Built-in LEDs indicate power status, communication activity, and faults, while detailed logs track protocol errors and data transmission rates. This allows technicians to quickly identify and resolve issues, minimizing system downtime. Additionally, firmware updates via Bently’s 3500 Configuration Software enable seamless upgrades to support new protocols or features.
Application Scenarios
The 3500/22M 288055-01 is vital in industries where real-time machinery data drives operational decisions. In power generation, it connects 3500 vibration monitors on steam turbines to plant control systems, transmitting critical data like shaft displacement and bearing temperature. Operators use this information to detect imbalance or misalignment early, preventing catastrophic failures and optimizing turbine efficiency.
In oil and gas refineries, the module links 3500 systems monitoring centrifugal pumps to enterprise-level analytics platforms. Its redundant design ensures continuous data flow from subsea pumps to onshore control rooms, even in harsh offshore conditions. This enables predictive maintenance scheduling, reducing unplanned shutdowns and extending equipment lifespan.
For chemical processing plants, the
3500/22M 288055-01 integrates temperature and pressure sensors on reactors with HMIs. By transmitting real-time data via OPC UA, it enables operators to monitor reaction conditions closely, ensuring product quality and preventing safety incidents. Its ATEX certification allows deployment in hazardous zones, further expanding its utility in high-risk environments.
Related Models
3500/22M 138607-01 – Earlier version with similar functionality but limited protocol support (no OPC UA).
3500/15 – Vibration monitoring module that feeds data to the 3500/22M 288055-01 for transmission.
3500/05 – Power supply module that provides 24 VDC to the 3500/22M 288055-01 in the 3500 chassis.
3500/42 – Temperature monitoring module compatible with the 3500/22M 288055-01.
330103-00-04-10-02-00 – Proximity probe whose data is processed by 3500 modules and transmitted via the 3500/22M 288055-01.
3500/92 – Advanced communication module that complements the 3500/22M 288055-01 for cloud connectivity.
Installation and Maintenance
Installing the 3500/22M 288055-01 requires inserting it into an available slot in the 3500 chassis, ensuring secure contact with the backplane. Connect Ethernet cables to network switches and RS-485 lines to legacy devices, using shielded cables to minimize interference. Configure the module via Bently’s software, defining communication parameters, data points, and redundancy settings. Verify proper grounding (≤4Ω) to prevent electrical noise.
For maintenance, inspect the module quarterly. Check LED indicators for normal operation (green for power and communication, amber for warnings). Clean dust from vents using compressed air, especially in dusty environments. Update firmware annually to ensure compatibility with new protocols or security patches. Test redundancy by temporarily disconnecting one module and confirming continuous data flow from the backup. With proper care, the module typically operates reliably for 8–10 years.
Product Warranty
The 3500/22M 288055-01 is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., covering manufacturing defects and premature failure under normal operating conditions. Xiamen Xiongba provides free replacement and technical support, ensuring minimal downtime for your 3500 monitoring system. Their team of automation experts offers guidance on installation, configuration, and troubleshooting, leveraging direct access to genuine Bently Nevada parts. This commitment to quality and service ensures users can trust the 3500/22M 288055-01 for critical machinery monitoring applications.
