BENTLY 3500/93 135799-01 | System Display Interface Module

BENTLY 3500/93 135799-01

Parameter	Value
Product Model	3500/93 135799-01
Manufacturer	Bently Nevada
Product Type	System Display Interface Module (3500 Series)
Input Voltage	24 VDC (from 3500 chassis backplane)
External Power Option	115 VAC or 230 VAC (for remote displays)
Communication Protocols	Modbus RTU, Ethernet/IP, RS-232/485
Display Resolution	800 × 600 pixels (WVGA)
Mounting Types	Face-mounted, 19-inch EIA rack, panel, independent
Operating Temperature	-25°C to 70°C (-13°F to 158°F)
Certifications	ATEX, IECEx, UL, CE
Dimensions	41.5 cm × 20.5 cm × 5 cm
Weight	0.8 kg (display interface module)
Power Consumption	≤15 W (module + display)
Response Time	<100 ms for alarm updates

1. Multi-Location Monitoring:
   The 3500/93 135799-01 supports up to two displays per rack, enabling operators to monitor machinery health from control rooms, field panels, or remote locations. For example, in a petrochemical plant, one display could be mounted in the control room for centralized oversight, while another is installed near the turbine for on-site diagnostics .
2. Rugged Industrial Design:
   Built to withstand extreme conditions, the module’s ATEX-certified enclosure  ensures safe operation in hazardous zones. Its IP67 rating  protects against dust and water ingress, making it suitable for offshore rigs or high-vibration environments like cement mills.
3. Intuitive Data Visualization:
   The 800 × 600 pixel display  presents real-time data in graphical formats (e.g., trend charts, bar graphs), simplifying analysis of vibration spectra or temperature profiles. Front-panel LEDs  indicate power status, communication activity, and alarm conditions, streamlining troubleshooting.
4. Flexible Configuration:
   Operators can define custom display layouts using Bently’s 3500 Configuration Software, including alarm thresholds, data refresh rates, and user-access levels. This is particularly valuable in power plants, where engineers may prioritize turbine vibration data over auxiliary equipment readings .
5. Long-Distance Connectivity:
   For installations requiring displays beyond 100 feet from the 3500 rack, the external power supply kit  supports cable lengths up to 4,000 feet, ensuring reliable signal transmission without degradation.

• Oil & Gas:
  In offshore platforms, the 3500/93 135799-01 monitors compressor vibration and seal pressure data, triggering alerts via its 4–20 mA outputs  when anomalies are detected. This allows operators to adjust flow rates or schedule maintenance before equipment failure.
• Power Generation:
  In steam turbine systems, the module integrates data from the 3500/42M vibration monitor  to visualize blade resonance patterns. By correlating vibration peaks with temperature trends, operators can predict blade fatigue and avoid catastrophic failures.
• Chemical Processing:
  Installed in reactor control rooms, the 3500/93 135799-01 displays real-time pressure and temperature data from agitators. Custom alarm rules (e.g., rapid temperature rise) enable immediate shutdowns, preventing thermal runaway and ensuring personnel safety.
• Manufacturing:
  In steel mills, the module aggregates data from 3500/33 relay modules  to monitor hydraulic press performance. Deviations from baseline pressure profiles trigger alerts, minimizing material waste and maintaining production quality.

• 3500/94 147663-01 – VGA display module with higher resolution (1280 × 1024 pixels) for detailed waveform analysis .
• 3500/22M 288055-01 – Communication gateway transmitting display data to enterprise systems via Ethernet/IP .
• 3500/05 – Power supply module ensuring stable 24 VDC to the 3500/93 135799-01 in 3500 chassis .
• 3500/32M 149986-02 – 4-channel relay module enabling automated responses (e.g., activating cooling systems during alarms) .
• 330103-00-04-10-02-00 – Proximity probe providing shaft displacement data complementing display analytics .

1. Insert the 3500/93 135799-01 into an available slot in the 3500 chassis, ensuring secure backplane contact.
2. Connect shielded cables from the display unit to the module’s terminals, using coaxial connectors  for noise reduction. For remote displays, install the external power supply  and route cables away from high-voltage lines.
3. Configure the module via Bently’s 3500 Configuration Software: define sensor types, alarm thresholds, and display layouts. Verify 24 VDC supply from the 3500/05 power module .

• Quarterly Checks: Inspect LED indicators for fault codes and clean dust from vents using compressed air.
• Annual Calibration: Use a precision temperature simulator to validate display accuracy within ±0.5°C . Update firmware via Bently software to support new sensor protocols.
• Redundancy Testing: If deployed in a dual-display configuration, test failover functionality by disconnecting one display and confirming the other maintains data flow.
