BNC-2110 Terminals designed for high precision measurement
No.BNC-2110
Ncc-2110 is a shielded, DIN rail, tabletop mounting terminal identified by part number 777643-01. It provides connections from 68-pin SCSI to 1-pin BNC (15 PCS) and 30-pin spring terminals. The BNC-2110 helps simplify the connection of analog signals, as well as some digital signals, to DAQ devices. Using this terminal, it is easier to connect and disconnect signal transmission between various electronic devices.
Ncc-2110 is a shielded, DIN rail, tabletop mounting terminal identified by part number 777643-01. It provides connections from 68-pin SCSI to 1-pin BNC (15 PCS) and 30-pin spring terminals. The BNC-2110 helps simplify the connection of analog signals, as well as some digital signals, to DAQ devices. Using this terminal, it is easier to connect and disconnect signal transmission between various electronic devices.
If you have any PLC DCS query, please feel free to contact Ah Please
Mobile:+86 18059868280 Nbc-2110 is a terminal designed for high precision measurement with the following advantages and features: Advantages: Shielding housing: The BNC-2110 provides shielding housing that ensures the integrity of the measurement results and helps reduce the impact of external interference. A variety of connection methods: The terminal supports the connection with analog signals and some digital signals, as well as the connection with a variety of user-defined data acquisition devices, convenient for users to perform flexible signal connection. Simplify the connection process: BCN-2110 simplifies the connection of analog signals and some digital signals with DAQ devices, greatly reducing the workload of wiring and improving work efficiency. High compatibility: It not only works with a variety of NI multi-function I/O and analog output devices, but also supports a variety of software, such as Ni-DAQMX driver software, LabVIEW, LabWindows/CVI or Measurement Studio. Features: Floating signal measurement: The floating signal can be measured by moving the corresponding switch under the BNC connector to the FS position. Ground reference signal measurement: If a ground-referenced signal is required, move the switch under the BNC connector for the AI channel to the GS position. This allows the device to be used as a 68-pin male SCSI male I/O connector. Shielding feature: With this terminal, desktop mounting and DIN rail mounting configurations are possible. Its shielded terminals ensure better measurement integrity. Despite the above advantages and features of BCN-2110, there may be limitations in some specific application scenarios. For example, it applies only to differential analog input signals. In addition, because it is an industrial grade equipment, it may have certain requirements for the use of the environment, such as the need for high cleanliness and temperature and humidity control.
