Brand: Moog
Model: DS200 CZ1008EVA
Product type: Servo drive
Payment method: Wire transfer, Western Union
Port of shipment for remittance: Xiamen, China
Delivery time: 1-3 working days
Condition: New and 100% original
Warranty: 12 months
Type: G761-3033B is a servo valve with a T-type, cross-throttled four-way flow control valve for better control performance.
Applications: Suitable for position, speed, force (or pressure) servo control systems, and provide high dynamic response. It is widely used in water turbine generator set, power station, test equipment and other fields.
DS200 CZ1008EVA Technical parameters:Rated pressure: from 7Mpa rated pressure.
Rated flow: 4L/min to 63L/min.
Material: hardened stainless steel.
Sealing material: fluorine rubber.
Operating temperature: ≤135℃.
Applicable medium: EH fuel resistant.
Electrical characteristics: With a standard 4-core electrical socket, it can be used with a variety of coils with different resistance values.
DS200 CZ1008EVA Working principle:Input a current command signal to the coil of the torque motor to generate electromagnetic force for both ends of the armature, so that the armature drives the baffle deflection.
The deflection of the baffle reduces the flow of the nozzle and changes the pressure on the spool side connected to the nozzle, causing the spool to move to one side.
When the electrical signal is fed into the servo amplifier, the armature coil of the DS200 CZ1008EVA torque motor flows a current, generates a magnetic field, generates a rotating torque under the action of magnets on both sides, rotates the armature, and moves the connected baffle.
When the distance between the two sides of the baffle and the nozzle is the same, the drainage area of the side nozzle is the same, and the oil pressure on both sides of the nozzle is the same.
The displacement of the spool opens the passage between the oil supply port (P) and the control oil port, and passes back to the oil circuit between the oil port (T) and other control oil ports.
