EG1033AA EG1033AA01 261A1812P002 Gas turbine flame monitoring system
Manufacturer: Honeywell
LG series EG amplifier
EG1033AA01
Honeywell gas turbine flame monitoring system
The Honeywell LG/EG Flame monitoring system detects ultraviolet radiation emitted by hydrocarbon flames and produces an output signal to indicate it
Conditions with or without flame.
The system has delivered more than 35 years of proven performance on GE (and GE licenser) gas turbines.
Geiger-miller type sensor photocell.
Detect ultraviolet radiation in 180... Spectral range of 260 nanometers. Solar blindness and tolerance to blackbody radiation.
Two years shelf life, 10,000 hours MTBF, more than 1 billion (109) hours of operation time.
Gas turbines and compressors for power generation
Temperature range :-40... 176C
Hardware output: Only for EG1033 amplifier module
EG1033AA: open transistor collector
EG1033AB and EG1033AC: Relay Contacts (SPDT)
Features: High sensitivity, fast flame response time (typical value 0.1 seconds)
Flame loss response time: up to 0.2 seconds.
The amplifier supports multiple voltage requirements :28 Vdc, 20-35 Vdc, and 115 Vac.
The sensor can operate up to 330 meters (1,000 feet) from the amplifier.
Qualified components for General Electric turbines.
