● Space requirement :4 TE
● Working data :5 volt DC= 110 MA, 24 volt DC= 180 MA. load
● Shipping weight :5 kg
The input and output module is also known as the control module, which can output signals when there are control requirements, or provide a switching signal to make the controlled device act, and can receive the feedback signal of the device to the master
Machine report is an important part of disaster alarm linkage system.
The input and output module is also known as the control module, which can output signals when there are control requirements, or provide - switch signals to make the controlled device act, and can receive the feedback signal of the device to the main
Machine report is an important part of disaster alarm linkage system. Input/output modules on the market can provide a pair of passive normally open/normally closed contacts to control the controlled device, some manufacturers of modules
Can be set through parameters, set to active output (such as gulf GST-LD-8305), the corresponding dual input output module, multi-input output module and so on. If the module input is set to Normal
"Check line" status input, module input line not end (away from the module end) must be connected to a 4.7kQ terminal resistor; Module input If the status is Normally Closed Check Line, enter the end of the module input line
(away from the module end) a 4.7kQ terminal resistor must be connected in series. When the module is an active output, the active output terminal should be connected by a 4.7kQ terminal resistor and an IN4007 diode in series.
When cooking alarms, the alarm controller starts the external control equipment that needs to be linked through the output module, such as smoke exhaust valve, air supply valve, fire shutter door, fan, alarm, etc., and automatically accepts the action of the equipment.
The output module is connected to the loop bus of the controller and can be installed near the control device or in the floor terminal module box. Using electronic coding, can be field coding. Output Indicates the output of the module
The control logic can be programmed according to the engineering situation. When the controller receives the alarm letter of the detector, according to the pre-programmed program, the controller transmits the linkage control signal to the output mode through the bus
Block, the output module starts the fire fighting equipment that needs linkage; The device responds with a signal when it acts.
When the smoke sensor detects a fire, the information is transmitted to the controller. The controller, through the output end of the input and output module, gives the fire pump number and starts the fire pump. After the fire pump starts, the fire pump will be sent through the input end of the input and output module
The startup information is sent to the controller.
The control module controls the field equipment through him, but does not accept the feedback signal; The output module. Input/output: Control field equipment and receive its feedback signals. The input module is also called the monitor module, only
Receive feedback signals and play a monitoring role.
