The safety-related F35 controller is a compact system located inside a metal exterior with 24 digital inputs, 8 digital outputs, 2 counters and 8 analog inputs. The controllers are available in 3 models of SILworX and 3 models of ELOP factory
The safety-related F35 controller is a compact system housed in a metal housing with 24 digital inputs, 8 digital outputs, 2 counters and 8 analog inputs. The controllers are available in 3 models of SILworX and 3 models of ELOP, see Chapter 3.2. All variants are described in this manual. This device is suitable for installation in Ex-zone 2. See Chapter 4.1.5. The device has been certified by TUV for safety-related applications up to SIL 3 (IEC 61508, IEC 61511 and IEC 62061), Cat.4 (EN 954-1) and PLe (EN ISO 13849-1). Advanced safety standards, application standards and test standards are detailed in the certificate on the HIMA website.
Provide attentive service and complete parts
(1) Reply to you within 24 hours;
(2) 100% quality guarantee, 1 year warranty;
(3) Good service, reasonable price;
(4) has been in business for many years and has a good reputation;
(5) We will deliver the goods within 3 working days after payment;
(6) All goods are tested before shipment;
(7) Packed in professional anti-static bag;
(8) We can ship to you via DHL/UPS/EMS/fedex... Please contact us directly and we will deliver the goods according to your requirements.
The controller is equipped with 2 independent counters and the input can be configured to either 5v or 24v voltage levels. The required voltage level is determined by the user program with the counter [0x]. System parameters in 5/24V mode. Input A is the counter input, B is the counter direction input, and input Z(zero rail) is used for reset. Alternatively, all inputs are 3-bit grey code inputs (in decoder operations), enabling the following modes of operation: Counter function 1 (depending on the input signal in the counting direction) Counter function 2(independent of count direction input signal) Decoder operations with absolute rotary transducers are described in Chapter 3.4.4 for counter configuration. The safety-related counter has a 24-bit resolution and a maximum counter reading of 224-1 (= 16 777-215).
