Brand: MOOG
Model: G761-3002B
Product type: electro-hydraulic servo valve
Payment method: Wire transfer, Western Union
Port of shipment for remittance: Xiamen, China
Delivery time: 1-3 working days
Condition: New and 100% original
Warranty: 12 months
G761-3002B Features:High dynamic response: The servo valve has a fast dynamic response, can quickly respond to system requirements, to ensure the real-time and accuracy of the system.
High-precision control: Through precision design and manufacturing, the G761-3002B enables high-precision control to meet the needs of a variety of complex industrial applications.
Long service life: The use of high-quality materials and manufacturing processes, so that the servo valve has a long service life and stable performance.
Pollution characteristics: The servo valve has high requirements for the quality and cleanliness of the oil, but it has strong anti-pollution ability and can operate stably in harsh industrial environments.
G761-3002B Working principle:G761-3002B servo valve is composed of permanent magnet torque motor, nozzle, stop plate, valve core, valve sleeve and control chamber.
When the input coil passes the current, the baffle moves, which strengthens or decreases the throttling effect of the nozzle, resulting in a change in the pressure difference between the two ends of the spool, thereby driving the spool to move.
The displacement of the spool is proportional to the input current to achieve electrical to hydraulic conversion.
G761-3002B Application field:G761-3002B servo valve is widely used in a variety of high-precision hydraulic control systems, such as aviation, aerospace, Marine, metallurgy, chemical and so on.
It is especially suitable for applications requiring fast response and high precision control, such as flight control, ship steering gear control, metallurgical equipment control, etc.
