531X305NTBANG1 F31X305NTBANG1 GE module
F31X305NTBANG1 is a circuit board manufactured by GE. The board can be used as part of a DC 300 drive, or as part of other similar general-purpose drive systems manufactured by GE.
F31X305NTBANG1 is an NTB/3TB terminal board. Its alternate number is 531X305NTBANG1. The board is installed in the drive (excitation) cabinet. It consists of a passive interface circuit and a connection end for an exciter
End, input/output at most external signal levels.
The F31X305NTBANG1 has a switch assembly with seven pins on its top surface. There are seven relays on the circuit board. These are labeled DS2E M DC24V H300. Six of the components are concentrated in the plate
On the left, one is located on the right edge of the board. The board has two inductors, four potentiometers, three head connectors of different sizes, 24 jumper switches, and three vertical pin cable connectors, two male and two male
A mother. Potentiometers are used for scaling various analog inputs. The board also has 6 terminal bands. Two of them have 24 screw connections, two each have 3 screw connections, and two each have 21 screw connections. This circuit
The board has an onboard test point that allows access to the signal path for test purposes.
