Model IS200EACFG1A
Brand GE
Category, input/output terminal board
The exciter AC feedback board under part number IS200EACFG1A is part of the EX2100 series manufactured by General Electric Company. This particular model is the G1 version of the IS200EACFG module. The G1 version of the module can support a separate three-phase input voltage with a nominal range of 480 VRMS and a positive 20% at 50 to 60 Hz.
The IS200EACFG1A module is also labeled as an input/output terminal board in the EX2100 series. The module also handles most of the bridge AC voltage and current feedback as it measures the excitation power Potential Transformer (PPT) AC voltage supply. The board contains three transformers for measuring three-phase voltage. The IS200EACFG1A can be connected to the EBKP backplane model. When connecting IS200EACFG1A and EBKP backplanes, a cable not exceeding 90 mm in length will connect the board. The three screw connectors labeled TB1, TB2, and TB3 on the IS200EACFG1A model are strictly for voltage input.
The IS200EACFG1A has three 9-pin connectors, J504, J509 and J514, which are used to connect cables to the EBKP backplane of the EMIO board.
The exciter AC feedback board under part number IS200EACFG1A is part of the EX2100 series manufactured by General Electric Company. This particular model is the G1 version of the IS200EACFG module. The G1 version of the module can support a separate three-phase input voltage with a nominal range of 480 VRMS and a positive 20% at 50 to 60 Hz.
The IS200EACFG1A module is also labeled as an input/output terminal board in the EX2100 series. The module also handles most of the bridge AC voltage and current feedback as it measures the excitation power Potential Transformer (PPT) AC voltage supply. The board contains three transformers for measuring three-phase voltage. The IS200EACFG1A can be connected to the EBKP backplane model. When connecting IS200EACFG1A and EBKP backplanes, a cable not exceeding 90 mm in length will connect the board. The three screw connectors labeled TB1, TB2, and TB3 on the IS200EACFG1A model are strictly for voltage input.
The IS200EACFG1A has three 9-pin connectors, J504, J509 and J514, which are used to connect cables to the EBKP backplane of the EMIO board.
