Brand GE
Model IS200EHPAG1A
Class sensor card
The IS200EMCSG1A part is an exciter multi-bridge conduction sensor card. It has four conduction sensors built into the circuit board, which are labeled E1 through E4. The board's power supply comes from two six-position plugs located on the edge of the board.
The IS200EMCSG1A model is part of the EX2100 innovation family produced by General Electric. The module is an exciter multi-bridge conduction sensor control. The board has a total of four conductance sensors built into the board, which are located on the bottom edge of the board and labeled E1, E2, E3 and E4. There are two separate sensor circuits between sensor E2 and E3, which are labeled U1 and U2.
Another feature of the IS200EMCSG1A board is two six-plug connectors that can be used for power supply. These connectors are located on the opposite side of the board from the conduction sensor and are closest to the board's alphanumeric catalog number. There are also four metal film resistors and a separate ceramic capacitor on the board. Because of its size, the board has very few components, but can usually be configured to operate at high current.
In factory automation or computer integrated process control system, in order to disperse risk and disperse function, a decentralized integrated control system structure is adopted. Programmable controller is a decentralized autonomous control system, which can be used as a subordinate computer to complete decentralized control functions, and has a qualitative leap compared with the centralized control of direct digital computer. This hierarchical control system is also the basis of decentralized control systems.
The IS200EMCSG1A is part of a series of excitation controllers produced by General Electric Company. Its main function is to control the excitation current and control the output current by adjusting the control voltage.
The excitation controller is a device used to control the excitation of a generator, which can change the excitation current and thus change the voltage of the generator.
Excitation controller is generally composed of measurement and comparison circuit, comprehensive amplifier circuit, pulse triggering circuit, isolation circuit, power supply circuit and so on.
