Brand GE
Series: EX2100 excitation control
Model IS200ERBPG1A
IS20OERBPG1A is a thermocouple module manufactured by GE General Electric Company as IS2OERBPG1A. The following is the product description, product parameters, application and brand introduction of IS20OERBPG1A:
Product description :IS20OERBPG1A thermocouple module adopts advanced conversion technology to convert thermocouple signals into standard voltage signals, which is convenient for industrial automation control system for data processing and control. It has a wide measuring range. High precision measurement, low drift and other characteristics, suitable for a variety of temperature measurement and control occasions.
Product parameters: The IS20EREPG1A has a range of 50C to 1300 ° C, an accuracy of 40.1 ° C, a resolution of 0.1 ° C and a response time of 150ms. Its working voltage is DC 24V, working current is ≤1A, with overload protection and short circuit protection functions. In addition, it also has a variety of output interfaces, including analog output, digital output, etc., convenient for users to choose according to actual needs.
Product Application :IS200EREPG1A is widely used in various industrial automation control systems, such as steel, metallurgy, petrochemical and other high-temperature industrial process control fields. It can be used in temperature detection, temperature compensation, heating control and other application scenarios to improve production efficiency and product quality.
The excitation regulator backplane module IS200ERBPG1A is one of the backplanes in the EX2100 series and can also be used with GE's Mark VI series. The board's power connectors are at the bottom, labeled TB1 and TB2, and the negative power supply will be connected to the TB2 and the positive power supply will be connected to the TB1. At the top corner of the board, there are five connectors; One of them is a keyboard connector, three are a three-bit female plug connector, and the fifth is a 12-bit female plug connector.
The IS200ERBPG1A can also be integrated to connect stand-alone Modbus applications, which should have built-in Ethernet modbus or serial communication protocols. The ERBP board provides connectivity to many different EX2100 boards, such as EPSM and DSPX modules.
