Brand GE
Function: Driver simplex backup board
Model IS200ESBPG1A
Product description
IS200ESBPG1A model is a simplex backup model of driver. The model is typically connected to the backplane model and is connected via 13 backplane connectors, which are divided into four groups on the model. For group orientation, there are three groups of three and one group of four. On one side of the single-row board, there are five vertical ribbon connectors, these connectors are called male connectors, all of which vary in size and working principle.
There are nine female plug connectors on the IS200ESBPG1A board, all of which vary in size. On the bottom half of the board, in the middle, there are five sub-d connectors. From left to right, they are named J504 EACF, J505 EXTB and EXHS, J405 ECTB, J305 EPCT, and J7 Bridge. These connectors are intended to be able to connect with other models and motherboards in the EX2100 system. Ge no longer produces the board, but it can still be found on the market, especially at AX Control INC. We have new and used surplus in our large inventory, for more information you can contact us by phone or email.
The IS200ESBPG1A is an exciter simplex backup board developed by GE. It is part of the EX2100 excitation system. ESBP plays a pivotal role in the architecture of control systems, providing the infrastructure for seamless communication and functionality between various components. This component is used as both a control board and an I/O terminal board cable, primarily for simplex applications within the system operating framework. The board is no longer manufactured by GE, but is still in stock. We have both new and second-hand surplus from large inventories.
trait
IS200ESBPG1A It is designed with special emphasis on providing the necessary connectivity and housing functions for the control board. It serves as a substrate to plug into these control boards, allowing them to interact, communicate and contribute to the overall functionality of the control system. In particular, for the controller M1, the ESBP not only provides the necessary slots for the ACLE, DSPX, EISB, EMIO and ESEL boards, but also houses the EROC ground detector interface. This integration promotes a cohesive control ecosystem in which different boards work together to achieve efficient and reliable control operations.
A notable feature of the card is that it contains an EPSM (Driver power module). This power module plays a key role in ensuring that the necessary power is supplied to the connected components, maintaining their operational integrity. For optimal performance, a single overhead fan is used to effectively cool the controller, prevent overheating and ensure stable and reliable operation even during long periods of use.
The design of the board meets the complex connection requirements of the control system. The upper part is equipped with DIN connectors, providing a reliable platform for plug-in control panels. This design simplifies the installation process and promotes the orderly arrangement of components. The lower part of the backplane has a D-SUB connector dedicated to the I/O interface cable as well as a circular DIN connector. These connectors have a variety of functions, including keyboard interface cables, power plugs, and test rings, further enhancing the flexibility and adaptability of the system.
