Product Model: DS3800HAIA
Manufacturer: GE Fanuc
Module Type: Analog Conversion Board
Signal Conversion: 16-bit A/D resolution
Input Channels: 8 differential/16 single-ended
Sampling Rate: 100kS/s per channel
Interface: Dual 34-pin modular connectors
Calibration: 2 trimmer resistors + 8 jumpers
Operating Temp: -40°C to 70°C
Power Supply: 24VDC ±10%
Certifications: UL/CE/RoHS compliant
The GE DS3800HAIA sets new standards in industrial signal conversion with its military-grade components and adaptive filtering technology. Three core strengths make it stand out:
Featuring 0.01% linearity error and ±1 LSB integral nonlinearity, the DS3800HAIA delivers laboratory-grade accuracy in harsh industrial environments. Its active thermal compensation ensures stable performance across the full temperature range.
The onboard EEPROM socket allows storing multiple configuration profiles, enabling quick system repurposing. Maintenance teams appreciate the diagnostic LEDs that provide real-time status monitoring of all conversion channels.
With conformal coating and vibration-resistant connectors, the GE DS3800HAIA survives in environments with 95% non-condensing humidity and 5G vibration loads. The gold-plated contacts ensure 10,000+ mating cycles reliability.
