The GE IC693DNM200 is a high-performance DeviceNet master communication module designed for GE Fanuc’s Series 90-30 Programmable Logic Controller (PLC) system, now part of Emerson Automation Solutions. Engineered to serve as the backbone of industrial automation networks, this module enables seamless integration of PLCs with DeviceNet-compatible devices such as sensors, actuators, and HMIs. By acting as the network master, the IC693DNM200 facilitates real-time data exchange, command execution, and diagnostics across distributed control systems, making it ideal for applications requiring robust connectivity and reliability.
As a core component of the Series 90-30 ecosystem, the IC693DNM200 slots into the PLC chassis (e.g., IC693CHS392) and interfaces directly with the CPU (e.g., IC693APU300K). It supports all standard DeviceNet data rates (125 kbps, 250 kbps, 500 kbps) and can manage up to 63 network nodes, ensuring scalable and flexible system configurations . Whether deployed in automotive assembly lines, packaging machinery, or wastewater treatment plants, the module delivers stable communication in harsh industrial environments, withstanding vibration, electromagnetic interference, and temperature fluctuations from 0°C to +60°C.
| Parameter |
Value |
| Product Model |
GE IC693DNM200 |
| Manufacturer |
GE Fanuc (now Emerson Automation Solutions) |
| Product Type |
DeviceNet Master Communication Module |
| Protocols Supported |
DeviceNet (125/250/500 kbps), explicit messaging |
| Network Ports |
1 x DeviceNet port (RJ45-compatible, 2-wire RS-485) |
| Max Network Nodes |
63 DeviceNet devices |
| Data Transfer Capacity |
255 bytes input/output per slave; 3,972 bytes total per master |
| Power Supply |
5V DC (450 mA) from backplane; 24V DC (50 mA typical, 80 mA peak) |
| Operating Temperature |
0°C to +60°C (32°F to 140°F) |
| Storage Temperature |
-40°C to +85°C (-40°F to 185°F) |
| Dimensions |
133.4 mm x 114.3 mm x 76.2 mm (5.25” x 4.5” x 3.0”) |
| Weight |
0.3 kg (0.66 lbs) |
| Certifications |
CE, UL, CSA, Class I, Div 2 (hazardous locations) |
| Mounting |
Series 90-30 main rack (not expandable racks) |
The GE IC693DNM200 excels in protocol specialization, providing native DeviceNet connectivity without additional gateways. Its dual-port design supports linear or star topologies, ensuring redundancy for mission-critical operations—if one port fails, communication automatically switches to the other, minimizing downtime . The module’s explicit messaging capability allows advanced control commands and diagnostics, enabling detailed monitoring of connected devices.
Easy configuration is achieved through GE’s Proficy Machine Edition software, where technicians can define network parameters, map I/O data, and troubleshoot via real-time diagnostics. The module supports hot-swappable operation, allowing replacement during system runtime without disrupting processes—a critical advantage in high-availability environments.
Industrial-grade reliability is ensured by rugged construction and EMI/RFI shielding, protecting against interference from motors or transformers. Its wide temperature tolerance and Class I, Div 2 certification make it suitable for hazardous areas like oil refineries or chemical plants . Built-in LED indicators for power, network activity, and fault status simplify maintenance, while SNMP compatibility enables remote health monitoring.
In automotive manufacturing, the IC693DNM200 connects Series 90-30 PLCs to DeviceNet-enabled robotic arms and conveyor systems. For example, it might synchronize part-position sensors with actuators to ensure precise welding or assembly, leveraging its high-speed data rates to maintain production efficiency.
Food and beverage processing facilities use the module to integrate PLCs with packaging machines and quality-control systems. The IC693DNM200 could transmit data from weight sensors and label printers to a central SCADA system, ensuring compliance with production standards while minimizing downtime.
Water treatment plants deploy the module to manage distributed I/O devices across large sites. For instance, it might connect flow meters and solenoid valves in a wastewater treatment network, using DeviceNet’s deterministic communication to maintain consistent process control.
- IC693CMM321 – Ethernet/IP communication module expanding the IC693DNM200’s network capabilities.
- IC693PBM200 – Profibus DP master module for compatibility with alternative fieldbus systems.
- IC693DNS200 – DeviceNet slave module for extending I/O capacity in distributed systems.
- IC693APU300K – CPU module compatible with the IC693DNM200 in the Series 90-30 chassis.
- IC693CHS392 – 9-slot chassis where the IC693DNM200 is installed.
Install the GE IC693DNM200 in a Series 90-30 main rack (e.g., IC693CHS392), avoiding expansion racks. Ensure proper grounding and use shielded cables for the DeviceNet network to reduce EMI. Configure the module via Proficy Machine Edition, setting parameters like MAC ID, baud rate, and node addressing. For redundant setups, enable dual-port redundancy in the software.
Regular maintenance includes checking LED indicators for fault conditions and cleaning connectors to prevent dust buildup. Use diagnostic tools like ping or SNMP to verify network health. If replacement is needed, the hot-swappable design allows removal and installation without powering down the system, but static protection and proper grounding are essential during handling.
The GE IC693DNM200 is backed by a 1-year limited warranty covering manufacturing defects. Emerson Automation Solutions provides global technical support, including firmware updates, documentation, and 24/7 assistance. Extended service plans are available for critical applications, offering priority response times and expedited replacements. Rigorous testing—including temperature cycling and network stress tests—ensures the IC693DNM200 meets Emerson’s high standards for industrial performance. The warranty underscores confidence in the module’s ability to deliver reliable DeviceNet communication across diverse automation environments.
