Product Overview
The IC695CBL001 is a critical communication cable designed specifically for GE’s RX3i series PLC systems, serving as a vital link between modular components in industrial automation setups. This cable facilitates high-integrity data transfer between RX3i CPU modules, I/O modules, and auxiliary components, ensuring seamless communication within the control system. Its design prioritizes reliability in harsh industrial environments, where signal interference or connection failures could disrupt operations.
What sets IC695CBL001 apart is its optimized construction for the RX3i architecture, ensuring compatibility and performance that generic cables cannot match. By maintaining consistent data transmission speeds and minimizing signal loss, IC695CBL001 helps keep automation systems responsive and accurate, making it an indispensable component for maintaining operational efficiency in mission-critical applications. Whether used in new installations or system upgrades, IC695CBL001 delivers the stability required for continuous industrial operations.
Technical Specifications
| Parameter |
Value |
| Product Model |
IC695CBL001 |
| Manufacturer |
GE |
| Product Type |
Communication Cable (RX3i Series) |
| Cable Type |
Shielded twisted-pair |
| Length |
1 meter |
| Connector Type |
Proprietary GE RX3i-compatible |
| Data Transfer Rate |
Up to 100 Mbps |
| Operating Temperature |
-20°C to 70°C |
| Shielding |
Tinned copper braid (95% coverage) |
| Compatible System |
GE RX3i PLC Series |
| Jacket Material |
PVC (flame-retardant) |
| Voltage Rating |
300V AC/DC |
| Bending Radius |
10x cable diameter (static), 15x (dynamic) |
Key Features and Benefits
The IC695CBL001 stands out for its robust shielding, which uses a tinned copper braid with 95% coverage to minimize electromagnetic interference (EMI) and radio frequency interference (RFI)—common issues in industrial environments with heavy machinery or high-voltage equipment. This ensures signal integrity even in noisy settings, reducing the risk of data corruption or system lag.
Its precise length (1 meter) is optimized for typical RX3i rack configurations, eliminating excess cable that could cause tangling or signal degradation. The proprietary connectors on IC695CBL001 are designed for secure, tool-free mating with RX3i modules, reducing installation time and the chance of loose connections.
Durability is another strength: the flame-retardant PVC jacket resists oil, chemicals, and abrasion, extending the cable’s lifespan in harsh conditions. Compatibility with the entire RX3i ecosystem means IC695CBL001 integrates seamlessly with existing setups, avoiding the need for adapters or system modifications. These features combine to make IC695CBL001 a cost-effective choice for maintaining reliable communication in GE automation systems.
Application Scenarios
The IC695CBL001 finds its place in diverse industrial environments where GE RX3i PLCs manage critical processes. In automotive manufacturing plants, it connects CPU modules to I/O modules controlling assembly line robots, ensuring real-time coordination between welding, painting, and material handling systems. This reliability prevents costly downtime caused by communication errors.
In water and wastewater treatment facilities, IC695CBL001 links RX3i controllers to sensor modules monitoring flow rates and chemical levels, enabling precise adjustments to treatment processes. Its resistance to moisture and chemicals makes it suitable for these damp, corrosive environments.
Power generation facilities also rely on
IC695CBL001 to connect PLC components regulating turbine operations and grid synchronization. Here, its EMI shielding is crucial, as nearby high-voltage equipment could otherwise disrupt data transmission. Across all these applications,
IC695CBL001 ensures the RX3i system operates as a unified, responsive unit.
Related Models
IC695CBL002 – Longer 2-meter variant of IC695CBL001, ideal for larger RX3i rack configurations requiring extended cable runs.
IC695CBL003 – 3-meter version with reinforced jacket for heavy-duty industrial environments.
IC693CBL001 – Compatible with older GE 90-30 PLC series, serving as a predecessor to IC695CBL001 with similar core functionality.
IC695CBL010 – Ruggedized variant of IC695CBL001 with enhanced temperature tolerance (-40°C to 85°C) for extreme environments.
IC695CBL005 – 5-meter cable with flexible jacket, designed for installations with complex routing requirements.
IC695CBL000 – Short 0.5-meter cable for compact RX3i setups where space is limited.
IC695CBL100 – Fiber-optic alternative to IC695CBL001 for high-speed, long-distance communication in EMI-sensitive areas.
Installation and Maintenance
Installation preparation for IC695CBL001 requires ensuring the RX3i rack has sufficient space for the 1-meter cable to route without tension or sharp bends. The mounting area should be clean and free of debris that could damage the jacket during installation. Proper grounding of the cable’s shielding is critical—connect the shield to the rack’s ground terminal to maximize EMI protection. Verify that the RX3i modules are powered off before connecting IC695CBL001 to prevent electrical damage.
For maintenance, inspect IC695CBL001 quarterly for signs of wear, such as frayed jackets or loose connectors. Check that the shielding remains securely grounded, as compromised grounding reduces interference protection. If the cable is exposed to oils or chemicals, wipe it gently with a dry cloth to prevent material degradation. Replace IC695CBL001 immediately if signal errors occur or physical damage is detected, as delays could lead to system instability.
Product Warranty
The
IC695CBL001 comes with a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., covering defects in materials and workmanship. During this period, we offer free replacement for any units that fail under normal operating conditions. Our global support network ensures timely assistance with installation or troubleshooting, backed by our expertise in industrial automation. We stand behind the quality of
IC695CBL001, ensuring it meets the rigorous demands of industrial environments and providing peace of mind to customers relying on seamless communication in their automation systems.
