Product Overview
The IC695CHS007-CA is a critical component within GE’s RX3i series, a robust programmable logic controller (PLC) platform designed for mid-to-large scale industrial automation. As a 7-slot chassis, its core function is to serve as a centralized backplane, facilitating seamless communication and power distribution between RX3i modules—including CPUs, I/O cards, communication interfaces, and specialty modules. This integration hub ensures synchronized data flow across connected components, making it indispensable in setups where modularity and reliability are paramount.
What sets IC695CHS007-CA apart is its balance of compact design and expandability. By accommodating up to seven modules, it strikes a sweet spot for applications that require flexibility without excessive footprint, ideal for both new installations and system upgrades. Its rugged construction and adherence to GE’s strict quality standards ensure consistent performance in demanding industrial environments, solidifying its role as a trusted foundation for automation systems in diverse sectors. Whether in process control or discrete manufacturing, IC695CHS007-CA delivers the stability needed to keep operations running smoothly.
Technical Specifications
| Parameter |
Value |
| Product Model |
IC695CHS007-CA |
| Manufacturer |
GE |
| Product Type |
7-Slot PLC Chassis (RX3i Series) |
| Slot Count |
7 slots (compatible with RX3i modules) |
| Backplane Bandwidth |
160 Mbps (synchronous data transfer) |
| Operating Voltage |
24 VDC (via compatible power supply) |
| Operating Temperature |
0°C to 60°C (32°F to 140°F) |
| Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
| Dimensions (HxWxD) |
130 mm x 330 mm x 220 mm (5.1" x 13.0" x 8.7") |
| Mounting Type |
DIN rail or panel mount |
| Material |
Aluminum alloy frame with steel cover |
| Certifications |
CE, UL, cUL |
| Compatibility |
GE RX3i CPUs, I/O modules, and accessories |
Key Features and Benefits
The IC695CHS007-CA excels in modular flexibility, allowing users to configure systems tailored to specific needs by mixing and matching RX3i modules. Its 160 Mbps backplane ensures high-speed data transfer between components, minimizing latency in time-critical processes such as conveyor synchronization or batch processing. This speed is paired with robust signal integrity, reducing the risk of data loss even in electrically noisy industrial environments.
Durability is another standout feature. The chassis’s aluminum alloy frame and steel cover provide protection against mechanical stress and dust, while its wide operating temperature range makes it suitable for both indoor control rooms and harsh on-site installations. Unlike fixed-configuration systems, the IC695CHS007-CA supports easy module replacement or upgrades—simply power down, swap components, and restart—minimizing downtime during maintenance or system expansions.
Diagnostic support is integrated into its design, with built-in monitoring of backplane health and module connectivity. This helps technicians quickly identify issues like loose connections or faulty modules, streamlining troubleshooting. Compatibility with GE’s Proficy Machine Edition software further enhances usability, enabling centralized configuration and monitoring of the entire RX3i system, with the IC695CHS007-CA serving as the reliable backbone.
Application Scenarios
The IC695CHS007-CA finds its place in a wide range of industrial settings where modular, scalable control systems are essential. In water and wastewater treatment plants, it serves as the core of PLC systems managing pump stations, filtration units, and chemical dosing processes, connecting flow meters, level sensors, and valve controllers into a cohesive network. Its compact size is particularly valuable in space-constrained treatment facilities where equipment density is high.
In automotive manufacturing, the IC695CHS007-CA supports assembly line automation, integrating robotic arms, vision systems, and conveyor controls. Its high-speed backplane ensures real-time coordination between these components, critical for maintaining production throughput and precision. Similarly, in food and beverage processing, it enables safe, compliant control of mixing, heating, and packaging equipment, with its rugged design resisting the moisture and temperature fluctuations common in such environments.
Oil and gas midstream operations also benefit from the
IC695CHS007-CA, where it manages pipeline monitoring systems, pressure control valves, and pump stations. Its reliability ensures uninterrupted operation in remote locations, where downtime can have significant financial and safety implications. Across all these scenarios, the
IC695CHS007-CA proves its versatility as a foundational component in automation.
Related Models
IC695CHS010-CA – 10-slot variant of the same chassis series, offering expanded module capacity for larger systems.
IC695CHS005-CA – 5-slot compact version, ideal for smaller setups or applications with limited space.
IC695PSD140 – 24 VDC power supply specifically designed to pair with the IC695CHS007-CA and other RX3i chassis.
IC695CPU310 – High-performance CPU module fully compatible with the IC695CHS007-CA, supporting advanced programming features.
IC695ETM001 – Ethernet module that integrates with the IC695CHS007-CA to enable network connectivity for remote monitoring.
IC695I/O131 – Digital input module designed for use with the IC695CHS007-CA, handling up to 16 discrete inputs.
IC695CHS007 – Non-CA variant with identical functionality, tailored for regions with different certification requirements.
IC695CMM002 – Communication module that fits the IC695CHS007-CA, enabling serial communication protocols like Modbus RTU.
Installation and Maintenance
Installation preparation for the IC695CHS007-CA requires a clean, dry environment with ambient temperatures between 0°C and 60°C. Ensure adequate space around the chassis—at least 100 mm of clearance on all sides—to facilitate airflow and ease of access. The chassis can be mounted on a standard DIN rail (35 mm) or directly to a panel using the provided mounting holes. Proper grounding is critical; connect the chassis ground terminal to a dedicated earth ground to minimize electrical interference. Before installation, verify compatibility of all RX3i modules with the IC695CHS007-CA to avoid connectivity issues.
For maintenance, conduct quarterly visual inspections of the IC695CHS007-CA to check for loose connections, dust buildup, or signs of corrosion. Use compressed air to clean vents and slots, taking care not to damage internal components. Test backplane continuity annually using a multimeter to ensure consistent power and data transfer. Replace any modules showing erratic behavior promptly, as faulty components can affect the entire chassis performance. With proper care, the IC695CHS007-CA is designed to operate reliably for 10+ years in typical industrial conditions.
