Product Overview
The GE IC694MDL350 is a high-performance digital output module designed for seamless integration with GE’s RX3i PLC system, a cornerstone of modern industrial automation. As a 16-channel relay output module, GE IC694MDL350 converts digital control signals from the PLC into actionable commands, enabling the operation of external devices such as solenoid valves, contactors, motors, and indicator lights.
Its role in automation setups is critical: acting as the "muscle" of the system, GE IC694MDL350 bridges the gap between the PLC’s processing power and physical equipment, ensuring precise execution of control logic. What makes it valuable is its robust relay design, which handles higher current loads than solid-state alternatives, making it versatile for both low- and medium-power devices. Compatible with all RX3i racks, it simplifies system expansion and reduces integration complexity, making GE IC694MDL350 a reliable choice for diverse industrial environments.
Technical Specifications
| Parameter |
Value |
| Product Model |
GE IC694MDL350 |
| Manufacturer |
GE |
| Product Type |
16-Channel Digital Output Module (Relay) |
| Number of Channels |
16 (independent) |
| Output Type |
Electromechanical relay |
| Maximum Output Current |
5A per channel (resistive load) |
| Supported Voltage |
24V DC, 120V AC, 240V AC |
| Isolation |
Channel-to-channel: 250V AC |
| Operating Temperature |
0°C to 60°C |
| Power Consumption |
3.0W (typical) |
| Mounting |
RX3i rack (compatible with IC694CHS012/024) |
| Compliance |
UL, CE, RoHS |
| Dimensions |
120mm x 35mm x 110mm (LxWxH) |
| Weight |
Approximately 0.5kg |
Key Features and Benefits
The GE IC694MDL350 offers 16 independent channels, providing ample capacity to control multiple devices from a single module—ideal for complex automation setups where space is limited. Its electromechanical relays deliver robust performance, handling both AC and DC loads up to 5A, making it versatile for applications ranging from small solenoids to larger contactors.
Channel-to-channel isolation (250V AC) prevents cross-interference, a critical feature in industrial environments with high electrical noise, ensuring reliable operation even near motors or variable frequency drives. Built-in diagnostics, including relay status indicators, allow quick identification of faults such as blown fuses or failed relays, reducing troubleshooting time and minimizing downtime.
Integration with GE’s Proficy Machine Edition software simplifies configuration, enabling engineers to map channels to specific devices and set up fault alerts without specialized coding. The GE IC694MDL350’s rugged design, resistant to vibration and temperature swings, ensures durability in harsh settings, from factory floors to outdoor enclosures.
Application Scenarios
The GE IC694MDL350 excels in industries requiring reliable control of electromechanical devices. In automotive manufacturing, it controls conveyor belt motors, robotic arm actuators, and welding machine triggers—16 channels allowing coordinated operation of multiple components in assembly lines.
In food and beverage processing, GE IC694MDL350 manages valves for ingredient dosing, pump motors for fluid transfer, and heater elements in pasteurization units, with its relay design handling the mixed AC/DC loads common in such facilities. Water treatment plants use the module to operate butterfly valves regulating flow, sludge pumps, and chemical injection systems, where reliable switching is critical for maintaining treatment efficiency.
For packaging lines in consumer goods industries,
GE IC694MDL350 controls sealing machines, label applicators, and sorting gates, ensuring precise synchronization to meet production targets. Its versatility across load types and environments makes it a staple in diverse automation ecosystems.
Related Models
GE IC694MDL340 – 8-channel variant of GE IC694MDL350, suitable for smaller systems with fewer output requirements.
GE IC694MDL351 – Solid-state digital output module, offering faster switching speeds than GE IC694MDL350 for high-cycle applications.
GE IC694MDL360 – 16-channel module with higher current rating (10A), designed for heavy-duty loads beyond GE IC694MDL350’s capacity.
GE IC693MDL940 – Legacy 90-30 series digital output module, compatible with GE IC694MDL350 via adapter for hybrid system upgrades.
GE IC694MDL352 – Relay output module with enhanced diagnostics, including remote fault reporting via PLC.
GE IC694MDL370 – 32-channel high-density module, ideal for large-scale systems needing more channels than GE IC694MDL350.
Installation and Maintenance
Installation preparation for GE IC694MDL350 requires mounting it in an RX3i rack (such as IC694CHS012) with secure DIN rail fixation, ensuring 30mm of clearance for ventilation. Verify the rack is properly grounded to minimize electrical noise, and check that the supply voltage matches the module’s requirements (24V DC backplane). Wiring should use appropriately sized conductors (16-22 AWG) to handle output currents, with fuses installed per channel to protect against overloads.
For maintenance, inspect GE IC694MDL350 quarterly for loose terminal connections or signs of relay overheating (discoloration). Test relay operation annually by activating each channel and verifying load response; replace relays if they fail to switch reliably. Clean the module’s surface with a dry cloth to prevent dust buildup, which can impede heat dissipation. Typically, GE IC694MDL350 has a service life of 8–10 years under normal operating conditions, with relays lasting 100,000+ cycles.
Product Warranty
The GE IC694MDL350 is covered by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., which includes free replacement for units with manufacturing defects or performance issues. Our technical support team provides global assistance for installation troubleshooting, wiring guidance, and compatibility checks, leveraging over a decade of industrial automation expertise. We stand behind the reliability of GE IC694MDL350, ensuring prompt service to minimize operational disruptions. This warranty reflects our commitment to quality and customer satisfaction, reinforcing confidence in the module’s performance in critical automation applications.
