Product Overview
The GE IC694PWR330 is a reliable power supply module designed specifically for GE’s RX3i series programmable logic controllers (PLCs), serving as the primary power source for the various modules within an RX3i rack. Its core function is to convert incoming AC voltage into stable, regulated DC power—delivering consistent 5V and 24V outputs to power processors, I/O modules, communication adapters, and other critical components in the system.
As a foundational component of the RX3i ecosystem, the GE IC694PWR330 ensures uninterrupted operation of the PLC system by maintaining steady voltage levels even during minor input fluctuations, a common occurrence in industrial environments with heavy machinery. Its robust design prioritizes durability, making it suitable for extended use in demanding settings where reliability directly impacts production uptime. What sets the GE IC694PWR330 apart is its seamless integration with RX3i racks, requiring no complex configuration to power connected modules. This plug-and-play functionality, combined with built-in protection features, makes it an essential asset for maintaining the integrity of automation systems across diverse industries.
Technical Specifications
| Parameter |
Value |
| Product Model |
IC694PWR330 |
| Manufacturer |
GE |
| Product Type |
Power Supply Module (RX3i PLC) |
| Input Voltage Range |
85-264V AC (50/60Hz) |
| Output Voltage |
5V DC (main); 24V DC (auxiliary) |
| Output Current |
5V: 8A; 24V: 1.2A |
| Operating Temperature |
0°C to 60°C (32°F to 140°F) |
| Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
| Dimensions (HxWxD) |
127mm x 36mm x 165mm |
| Mounting Type |
RX3i PLC rack-mounted (1-slot width) |
| Protection Features |
Overload protection; short-circuit protection; overvoltage protection |
| Efficiency |
Up to 82% at full load |
| Status Indicators |
Power-on LED (green); fault LED (red) |
| Compliance |
UL 508, CE, RoHS |
Key Features and Benefits
The GE IC694PWR330 delivers consistent power regulation, ensuring that 5V and 24V outputs remain within tight tolerances (±5% for 5V, ±10% for 24V) even when input voltage fluctuates. This stability is critical for sensitive RX3i components like processors and communication modules, which rely on steady power to avoid data corruption or unexpected shutdowns.
Equipped with comprehensive protection mechanisms, the GE IC694PWR330 guards against overloads, short circuits, and overvoltage events. In the event of a fault, the module automatically limits current or shuts down temporarily, preventing damage to itself and connected devices. A red fault LED provides clear visual alerts, simplifying troubleshooting for maintenance teams.
Its wide input voltage range (85-264V AC) makes the GE IC694PWR330 compatible with global power grids, eliminating the need for voltage transformers in international facilities. This flexibility reduces inventory complexity for multinational operations using RX3i systems.
The module’s compact 1-slot design maximizes rack space, leaving room for additional I/O or communication modules. Its seamless integration with RX3i backplanes ensures plug-and-play installation, minimizing setup time and reducing the risk of configuration errors—key advantages for both new installations and system upgrades.
Application Scenarios
The GE IC694PWR330 is widely deployed in automotive manufacturing plants, where it powers RX3i PLC systems controlling robotic assembly lines, conveyor belts, and quality inspection sensors. Its stable output ensures these systems operate without interruptions, maintaining production 节奏 and reducing scrap rates caused by unexpected shutdowns.
In water and wastewater treatment facilities, the GE IC694PWR330 supplies power to RX3i modules monitoring flow meters, pH sensors, and valve controllers. Its ability to withstand voltage fluctuations protects critical monitoring equipment, ensuring the PLC can adjust treatment processes in real time to meet environmental regulations.
Food and beverage processing plants rely on the GE IC694PWR330 to power temperature control modules, packaging line sensors, and safety interlock systems. Its robust design operates reliably in environments with temperature variations and occasional moisture, supporting consistent product quality and compliance with hygiene standards.
In logistics automation, the module powers RX3i-based systems managing warehouse robots, barcode scanners, and conveyor diverters, ensuring uninterrupted material flow in high-throughput distribution centers.
Related Models
GE IC694PWR331 – Higher-capacity variant with 5V/10A and 24V/1.5A outputs, suitable for RX3i racks with more modules than the GE IC694PWR330 can support.
GE IC694PWR320 – Lower-power model with 5V/5A and 24V/1A outputs, a cost-effective option for small RX3i systems where the GE IC694PWR330’s capacity is unnecessary.
GE IC694PWR340 – Redundant power supply module, designed for critical applications requiring failover protection, unlike the non-redundant GE IC694PWR330.
GE IC694PWR332 – Extended-temperature version (-20°C to 70°C), suitable for unheated industrial enclosures where the GE IC694PWR330’s standard range is insufficient.
GE IC693PWR330 – Legacy power supply for GE’s 90-30 series, a predecessor to the RX3i-compatible GE IC694PWR330.
GE IC694PWR350 – High-efficiency model (88% at full load), offering energy savings compared to the GE IC694PWR330 in 24/7 operations.
Installation and Maintenance
Installation of the GE IC694PWR330 requires an available slot in the RX3i rack, with the system powered down during insertion to prevent electrical damage. The module must be mounted in a control cabinet with ambient temperature between 0°C and 60°C and relative humidity below 95% (non-condensing). Proper grounding of the RX3i rack is critical—connect the ground terminal to the cabinet’s earth ground using 14AWG wire to minimize electrical noise.
For maintenance, inspect the GE IC694PWR330 quarterly for loose connections or dust accumulation on vents; use compressed air to clean debris if needed. Monitor the power and fault LEDs during operation—consistent green power LED indicates normal function, while a red fault LED signals issues requiring investigation (e.g., overload or short circuit). Replace the module every 5-7 years as preventive maintenance, or immediately if it repeatedly enters fault mode despite resolved load issues, to avoid unplanned downtime.
