Product Overview
The GE IC695ACC302-AA is a high-performance communication adapter designed for GE’s RX3i and PACSystems™ RX7i programmable automation controllers (PACs), serving as a critical interface for seamless data exchange between the controller and industrial networks. Its primary function is to enable reliable communication via Ethernet/IP and Modbus TCP/IP protocols, facilitating connectivity with HMIs, SCADA systems, remote I/O modules, and other automation devices.
As a key component in GE’s advanced control ecosystems, the GE IC695ACC302-AA supports high-speed data transmission, ensuring real-time synchronization between the PAC and networked devices—essential for time-sensitive applications like precision manufacturing or process control. What distinguishes the GE IC695ACC302-AA is its robust design, which includes redundant network capabilities and enhanced noise immunity, making it suitable for harsh industrial environments where electrical interference or network disruptions are common. This combination of protocol versatility, speed, and reliability positions it as a vital asset for integrating modern PAC systems into complex industrial networks.
Technical Specifications
| Parameter |
Value |
| Product Model |
IC695ACC302-AA |
| Manufacturer |
GE |
| Product Type |
Industrial Ethernet Communication Adapter |
| Supported Protocols |
Ethernet/IP, Modbus TCP/IP |
| Communication Ports |
2 x 10/100/1000 Mbps Ethernet (RJ45) |
| Input Voltage |
5V DC (from controller backplane) |
| Operating Temperature |
0°C to 60°C (32°F to 140°F) |
| Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
| Dimensions (HxWxD) |
130mm x 40mm x 170mm |
| Mounting Type |
RX3i/RX7i rack-mounted (1-slot width) |
| Data Transfer Rate |
Up to 1 Gbps |
| Protection Features |
ESD protection (±8kV contact, ±15kV air); overvoltage protection |
| Redundancy Support |
Dual-port for network redundancy |
| Compliance |
UL 508, CE, RoHS |
Key Features and Benefits
The GE IC695ACC302-AA excels in protocol versatility, supporting both Ethernet/IP and Modbus TCP/IP—the most widely used industrial Ethernet protocols. This eliminates the need for additional gateways in mixed-protocol environments, simplifying system architecture and reducing hardware costs for facilities using diverse automation equipment.
Equipped with two 10/100/1000 Mbps Gigabit Ethernet ports, the GE IC695ACC302-AA enables flexible network topologies, including redundant ring configurations. Redundancy is critical in mission-critical applications, as it provides a failover path if the primary network link fails, ensuring uninterrupted communication and minimizing production downtime.
The adapter integrates seamlessly with RX3i and RX7i backplanes, offering plug-and-play functionality that reduces installation time. It also features advanced diagnostic capabilities, including real-time status LEDs, error logging, and network performance metrics accessible via PAC software. These tools help maintenance teams quickly identify issues like cable faults or protocol mismatches, streamlining troubleshooting and improving system uptime.
Built to industrial standards, the GE IC695ACC302-AA operates reliably in environments with temperature fluctuations and electrical noise, ensuring consistent performance in factories, power plants, and processing facilities.
Application Scenarios
The GE IC695ACC302-AA is widely used in automotive manufacturing plants, where it connects RX3i PACs to HMI panels monitoring assembly line status and SCADA systems overseeing plant-wide operations. By facilitating high-speed data exchange, it ensures real-time updates on robot performance and part quality, enabling quick adjustments to optimize production efficiency.
In energy generation facilities, such as natural gas power plants, the GE IC695ACC302-AA enables RX7i controllers to communicate with turbine sensors, generator monitors, and grid management systems. Its redundant ports ensure continuous data flow, critical for monitoring turbine vibrations and adjusting fuel flow to prevent equipment damage.
Water treatment facilities utilize the GE IC695ACC302-AA to link RX3i PACs with remote I/O modules measuring water pressure and chemical levels, as well as with central SCADA systems. This connectivity ensures timely adjustments to treatment processes, maintaining compliance with environmental regulations and preventing system overloads.
In semiconductor manufacturing, the adapter connects RX7i controllers to cleanroom environmental sensors and wafer handling robots, where its high data transfer rate supports precise synchronization of temperature controls and robotic movements—essential for producing high-yield microchips.
Related Models
GE IC695ACC301-AA – Previous generation communication adapter with 10/100 Mbps ports, lacking the Gigabit speed of the GE IC695ACC302-AA.
GE IC695ACC303-AA – Enhanced variant with support for PROFINET protocol, expanding compatibility beyond the GE IC695ACC302-AA’s Ethernet/IP and Modbus focus.
GE IC694ACC310 – RX3i-specific communication adapter with dual 10/100 ports, a compact alternative to the GE IC695ACC302-AA for smaller networks.
GE IC695ACC305-AA – Wireless-enabled adapter with Wi-Fi 6 support, designed for remote applications where wired connectivity is impractical compared to the GE IC695ACC302-AA.
GE IC695ACC300-AA – Basic communication adapter with Modbus TCP only, suitable for simple systems not requiring the GE IC695ACC302-AA’s dual-protocol support.
Installation and Maintenance
Installation of the GE IC695ACC302-AA requires an available 1-slot position in the RX3i or RX7i rack, with the system powered down during insertion. Use Cat6a Ethernet cables for Gigabit performance, routing them away from high-voltage cables to minimize electromagnetic interference. Ensure the rack is properly grounded to maintain signal integrity, and verify that the network switch supports the adapter’s protocols (Ethernet/IP, Modbus TCP/IP) before deployment.
For maintenance, inspect the GE IC695ACC302-AA quarterly for loose Ethernet connections or dust accumulation on vents; clean with compressed air if needed. Monitor LED status indicators regularly—steady green lights confirm normal operation, while flashing or red lights indicate issues. Update firmware annually via GE’s Proficy Machine Edition software to ensure compatibility with new devices and security patches. If communication errors persist, test with a known-good cable or port to isolate faults.
Product Warranty
The GE IC695ACC302-AA is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., covering manufacturing defects and performance issues under normal operating conditions. During the warranty period, we provide free replacement for any faulty units, ensuring minimal disruption to your automation systems. Our technical support team offers expert guidance on installation, network configuration, and troubleshooting, leveraging over a decade of experience in industrial automation. We stand behind the reliability of the GE IC695ACC302-AA, committed to delivering consistent performance and exceptional service to support your operational needs.
