Product Overview
The IC695ACC302-BB is a critical accessory module designed for GE’s RX3i PLC series, a next-generation platform renowned for its scalability and performance in modern industrial automation. As a key connectivity component, IC695ACC302-BB serves as a backplane adapter, facilitating seamless integration between RX3i processors, I/O modules, and communication interfaces. Its core function is to ensure reliable data transfer across the PLC system, acting as a bridge that synchronizes signals between components—essential for maintaining real-time control in complex processes.
What distinguishes IC695ACC302-BB is its optimized design for the RX3i ecosystem, supporting high-speed communication and flexible expansion. Unlike generic adapters, it is engineered to match the RX3i’s processing power, eliminating bottlenecks that could delay critical commands. Whether deployed in a pharmaceutical plant coordinating batch processes or a logistics hub managing conveyor systems, IC695ACC302-BB ensures the RX3i PLC operates as a cohesive unit, enhancing system efficiency and reducing downtime. Its robust construction and plug-and-play functionality make it a trusted choice for both new installations and upgrades of legacy systems.
Technical Specifications
| Parameter |
Value |
| Product Model |
IC695ACC302-BB |
| Manufacturer |
GE |
| Product Type |
Backplane Adapter Module (RX3i PLC) |
| Compatibility |
GE RX3i PLC Series |
| Number of Slots |
3 slots (supports RX3i I/O modules) |
| Data Transfer Rate |
Up to 100Mbps (synchronous with RX3i bus) |
| Operating Temperature |
0°C to 60°C (32°F to 140°F) |
| Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
| Dimensions (HxWxD) |
102mm x 76mm x 152mm (4.0" x 3.0" x 6.0") |
| Power Requirements |
5V DC (0.8A) from RX3i power supply |
| Mounting Type |
DIN rail or panel mount |
| Protection Features |
Overvoltage protection, ESD resistance |
| Certifications |
UL, CSA, CE |
Key Features and Benefits
The IC695ACC302-BB excels in enhancing RX3i system flexibility, offering 3 slots to accommodate a mix of I/O modules, communication cards, or specialty interfaces. This adaptability is particularly valuable in industries like automotive manufacturing, where production lines often require custom configurations—such as integrating analog sensors for pressure monitoring alongside digital modules for conveyor control. By centralizing these connections, IC695ACC302-BB simplifies wiring and reduces the risk of signal interference.
High-speed data transfer (up to 100Mbps) ensures that the RX3i processor and connected modules communicate in real time, critical for time-sensitive applications like precision packaging or chemical batching. Unlike older adapters, IC695ACC302-BB maintains signal integrity even under heavy load, preventing delays that could compromise process accuracy.
Built with industrial durability in mind, IC695ACC302-BB withstands harsh conditions, including vibration, temperature fluctuations, and electrical noise—common in facilities with heavy machinery. Its compact design saves space in control cabinets, a valuable asset in modern plants where space is at a premium.
Installation is streamlined, with plug-and-play functionality that eliminates the need for complex programming. The module’s compatibility with all RX3i components adds versatility, allowing users to upgrade or reconfigure systems without replacing the adapter. This longevity reduces lifecycle costs, making
IC695ACC302-BB a cost-effective choice for long-term automation strategies.
Application Scenarios
The IC695ACC302-BB is integral to industries leveraging the RX3i PLC’s capabilities for advanced control. In food and beverage processing, it connects temperature sensors, flow meters, and valve actuators to the RX3i processor, ensuring precise regulation of pasteurization cycles. The 3 slots of IC695ACC302-BB accommodate the mix of analog and digital modules needed to monitor heating elements and adjust conveyor speeds, critical for maintaining product quality and compliance with safety standards.
In water treatment plants, IC695ACC302-BB integrates with RX3i I/O modules tracking turbidity, pH levels, and pump statuses. Its high-speed communication ensures the PLC receives real-time data, enabling rapid adjustments to chemical dosing or filtration rates—preventing contamination and optimizing resource use.
Pharmaceutical manufacturing relies on IC695ACC302-BB to link RX3i processors with cleanroom sensors and robotic filling equipment. The module’s reliability ensures consistent data flow, supporting strict batch traceability requirements and reducing the risk of costly production errors.
In renewable energy facilities, such as solar farms, IC695ACC302-BB connects weather monitoring modules to RX3i controllers, enabling adaptive adjustments to panel positioning—maximizing energy capture while protecting equipment from extreme conditions.
Related Models
IC695ACC301-BB – 2-slot variant of IC695ACC302-BB, ideal for smaller RX3i setups with fewer modules.
IC695ACC303-BB – 5-slot backplane adapter, offering expanded capacity for larger RX3i systems compared to IC695ACC302-BB.
IC695ACC302-CC – Ruggedized version with conformal coating, designed for washdown or corrosive environments.
IC695ACC100 – Base backplane for RX3i processors, compatible with IC695ACC302-BB for extended I/O expansion.
IC695ACC201 – Communication-focused adapter, working alongside IC695ACC302-BB to add Ethernet/IP capabilities.
IC694ACC302 – Legacy adapter for 90-70 PLCs, serving as a predecessor to IC695ACC302-BB in GE’s product line.
IC695ACC304-BB – High-temperature variant (-20°C to 70°C), suitable for extreme environments like foundries.
Installation and Maintenance
Installing IC695ACC302-BB requires a compatible RX3i rack or DIN rail mounting in a control cabinet with ambient temperatures between 0°C and 60°C. Ensure the cabinet is free from direct moisture or corrosive fumes, and that there is adequate airflow to prevent heat buildup. Proper grounding of the module and connected RX3i components is critical to minimize electrical noise, which can disrupt data transfer. Align the adapter with the RX3i processor’s backplane connector, securing it firmly to avoid loose connections during operation.
For maintenance, inspect IC695ACC302-BB quarterly for dust accumulation, using compressed air to clean vents and slot openings—debris can impede signal transmission. Check that all connected modules are seated properly, as vibration may loosen connections over time. Monitor system diagnostics via RX3i software to identify potential issues like voltage fluctuations, addressing them promptly to prevent downtime. Replace the adapter every 8-10 years to account for component aging, ensuring consistent performance in critical applications.
Product Warranty
The IC695ACC302-BB is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., covering manufacturing defects and performance issues. During this period, we provide free replacement for faulty units, ensuring minimal disruption to your RX3i PLC system. Our global technical support team, with expertise in GE’s RX3i series, offers assistance with installation, compatibility checks, and troubleshooting. Sourced directly from trusted suppliers, IC695ACC302-BB is guaranteed to be genuine, reflecting our commitment to quality and customer satisfaction. This warranty underscores our confidence in the module’s reliability, making us a trusted partner for your industrial automation needs.
