Product Overview
The GE IC695ALG600 is a high-performance analog input module designed for GE’s PACSystems™ RX3i and RX7i programmable automation controllers (PACs), specializing in precise measurement and conversion of analog signals from industrial sensors. Its core function is to transform continuous physical variables—such as pressure, temperature, flow, and level—into digital data that the PAC can process, enabling real-time monitoring and control of critical processes.
As a key component in GE’s advanced control ecosystem, the GE IC695ALG600 stands out for its high resolution and accuracy, making it ideal for applications where even minor signal variations can impact product quality or safety. Its design supports a wide range of analog input types, eliminating the need for multiple specialized modules. What distinguishes the GE IC695ALG600 is its robust channel isolation and noise immunity, ensuring reliable performance in electrically noisy environments common in factories and processing plants. This combination of versatility, precision, and durability positions it as an essential tool for integrating analog sensors into modern automation systems.
Technical Specifications
| Parameter |
Value |
| Product Model |
IC695ALG600 |
| Manufacturer |
GE |
| Product Type |
Analog Input Module |
| Input Channels |
8 (isolated, differential) |
| Input Signal Types |
4-20mA, 0-20mA, 0-10V, 0-5V, ±10V |
| Resolution |
16 bits + sign |
| Accuracy |
±0.05% of full scale (at 25°C) |
| Operating Temperature |
0°C to 60°C (32°F to 140°F) |
| Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
| Dimensions (HxWxD) |
130mm x 40mm x 170mm |
| Mounting Type |
RX3i/RX7i rack-mounted (1-slot width) |
| Isolation |
500V AC channel-to-channel; 250V AC channel-to-backplane |
| Filtering |
Programmable low-pass filter (0.1Hz to 1kHz) |
| Protection Features |
Overvoltage protection (up to 30V DC); open-circuit detection |
| Compliance |
UL 508, CE, RoHS |
Key Features and Benefits
The GE IC695ALG600 delivers exceptional precision with 16-bit resolution and ±0.05% accuracy, ensuring that even subtle changes in analog signals—such as small pressure fluctuations in chemical reactors or minor temperature shifts in industrial ovens—are captured accurately. This level of detail is critical for processes where tight tolerances directly impact product quality or safety.
Its 8 isolated differential channels minimize cross-talk and electromagnetic interference (EMI), a common challenge in factories with heavy machinery or variable frequency drives. This isolation ensures signal integrity, reducing the risk of erroneous readings that could lead to incorrect process adjustments.
The module supports a wide range of input signals, including 4-20mA current loops and 0-10V voltage signals, making it compatible with most industrial sensors—from pressure transducers to level transmitters. This versatility eliminates the need for signal converters, simplifying system design and lowering costs.
Integrated diagnostic features, such as open-circuit detection and overvoltage alerts, provide real-time feedback via PAC software, allowing maintenance teams to quickly identify faulty sensors or wiring issues. Its seamless integration with RX3i and RX7i backplanes ensures plug-and-play functionality, reducing installation time and configuration errors.
Application Scenarios
The GE IC695ALG600 is widely used in chemical processing plants, where it connects RX7i PACs to pressure sensors in reactor vessels and flow meters in chemical feed lines. By converting these analog signals to digital data, it enables the PAC to precisely control valve positions and pump speeds, maintaining optimal reaction conditions and preventing overpressure incidents.
In automotive manufacturing, the GE IC695ALG600 monitors temperature sensors in paint curing ovens and pressure transducers in hydraulic press systems. The accurate data it provides allows the RX3i PAC to adjust oven temperatures and press force, ensuring consistent paint adhesion and part forming.
Water and wastewater treatment facilities utilize the GE IC695ALG600 to process signals from pH meters in treatment pools and turbidity sensors in filtration systems. This enables the PAC to regulate chemical dosing and filter backwashing, maintaining water quality and compliance with environmental standards.
In pharmaceutical production, the module monitors temperature and humidity sensors in cleanrooms, providing the RX7i controller with data to adjust HVAC systems—critical for ensuring sterile conditions during drug manufacturing.
Related Models
GE IC695ALG601 – 4-channel analog input module, a compact alternative to the 8-channel
GE IC695ALG600 for smaller systems.
GE IC695ALG610 – 16-channel analog input module, offering double the channel count of the
GE IC695ALG600 for large-scale monitoring.
GE IC695ALG620 – Analog output module with 8 channels, complementary to the
GE IC695ALG600 for systems requiring both input and output control.
GE IC694ALG222 – Previous-generation 8-channel analog input module for RX3i, with lower resolution (12-bit) compared to the
GE IC695ALG600.
GE IC695ALG630 – High-temperature variant (-20°C to 70°C), designed for harsh environments where the
GE IC695ALG600’s standard range is insufficient.
Installation and Maintenance
Installation of the GE IC695ALG600 requires an available 1-slot position in RX3i or RX7i racks, with the system powered down during insertion. Use shielded twisted-pair cables for sensor connections, grounding the shields at both the module and sensor ends to minimize EMI. Ensure the mounting rack is properly grounded per GE specifications, and maintain ambient temperatures between 0°C and 60°C with relative humidity below 95% (non-condensing).
For maintenance, calibrate the GE IC695ALG600 annually using a precision signal generator to verify accuracy. Inspect terminal connections quarterly for tightness and corrosion, especially in humid environments. Clean dust from vents with compressed air to prevent overheating. Replace the module every 7-10 years as preventive maintenance, or immediately if diagnostic alerts indicate persistent accuracy issues despite calibration.
