Product Overview
The GE IC695ALG704 is a high-performance analog output module designed to extend the control capabilities of GE’s RX3i programmable logic controller (PLC) systems, a leading platform in modern industrial automation. Its core function is to convert digital control signals from the RX3i PLC into precise analog outputs, enabling seamless control of field devices such as proportional valves, variable speed drives, and industrial heaters. This conversion is critical in processes where continuous, adjustable control—rather than simple on/off commands—is required to maintain quality and efficiency.
In automation setups, the GE IC695ALG704 acts as the bridge between the PLC’s digital decision-making and the analog world of industrial machinery, ensuring that commands translate into accurate, real-world actions. What sets the GE IC695ALG704 apart is its combination of high precision and robust design, making it ideal for applications where fine-tuned adjustments are essential. Whether integrated into new installations or retrofitting existing RX3i systems, the GE IC695ALG704 enhances the PLC’s ability to manage complex processes, ensuring consistency even in demanding industrial environments.
Technical Specifications
| Parameter |
Value |
| Product Model |
GE IC695ALG704 |
| Manufacturer |
GE (Fanuc) |
| Product Type |
Analog Output Module (RX3i PLC Series) |
| Number of Channels |
4 differential channels |
| Output Signal Types |
4-20mA DC, 0-10V DC |
| Accuracy |
±0.1% of full scale (at 25°C) |
| Resolution |
16-bit |
| Channel Isolation |
250V AC channel-to-channel and channel-to-backplane |
| Power Requirements |
5V DC from RX3i backplane |
| Mounting Type |
RX3i PLC rack (backplane compatible) |
| Update Rate |
<50ms per channel |
| Protection Features |
Short-circuit and overcurrent protection |
| Certifications |
UL, CE, RoHS compliant |
Key Features and Benefits
The GE IC695ALG704 delivers exceptional precision with ±0.1% full-scale accuracy and 16-bit resolution, enabling fine adjustments to output signals—critical for applications like regulating chemical flow rates or adjusting motor speeds in manufacturing lines. This level of precision minimizes waste and ensures consistent product quality, even in processes with tight tolerances.
Channel isolation (250V AC) is a standout feature, reducing interference from nearby high-voltage equipment or electrical noise common in industrial environments. This isolation ensures output signals remain stable, preventing erratic behavior in connected devices—a key advantage in factories with motors, welders, or other noise-generating machinery.
The module’s flexibility in supporting both 4-20mA and 0-10V signals eliminates the need for external converters, simplifying system design and reducing potential failure points. It integrates seamlessly into RX3i racks without specialized tools, making upgrades or replacements straightforward. Built-in short-circuit and overcurrent protection safeguards the module and connected devices, reducing downtime and repair costs. For operations requiring precise analog control, the
GE IC695ALG704 balances performance, reliability, and ease of use.
Application Scenarios
The GE IC695ALG704 is widely utilized in industries where precise analog control is central to operations. In chemical processing plants, it converts RX3i PLC signals into 4-20mA outputs to regulate diaphragm valves, controlling the flow of raw materials into reactors. This ensures mixing ratios remain within tight tolerances, critical for producing consistent chemical formulations—any drift in output could compromise product quality or safety.
In power generation facilities, the module controls variable speed drives for boiler feed pumps, adjusting pump speeds based on steam demand. The GE IC695ALG704’s accuracy allows the RX3i PLC to maintain optimal water flow, improving energy efficiency while preventing boiler damage from low water levels. Its fast update rate ensures rapid response to changing demand, a must for grid stability.
Food and beverage processing plants use the GE IC695ALG704 to regulate industrial ovens, converting PLC commands into 0-10V signals that adjust heating elements. This maintains precise temperatures during baking or pasteurization, ensuring compliance with food safety standards and reducing product waste from over- or under-cooking.
Related Models
IC695ALG702 – 2-channel analog output variant, suitable for smaller systems requiring fewer control points than GE IC695ALG704.
IC695ALG708 – 8-channel high-density version, ideal for large-scale applications needing more outputs than GE IC695ALG704.
IC695ALG608 – Analog input companion module that pairs with GE IC695ALG704 to create a complete analog I/O system in RX3i PLCs.
IC695ALG704-B – Ruggedized variant with extended temperature range (-20°C to 70°C), designed for harsh environments.
IC695ALG700 – Previous generation module with basic functionality, lacking the enhanced accuracy of GE IC695ALG704.
IC695BEM001 – Backplane expansion module that supports additional GE IC695ALG704 units in large RX3i configurations.
Installation and Maintenance
Installation preparation for the GE IC695ALG704 requires verifying compatibility with the RX3i rack, ensuring firmware supports analog output modules. The rack should be mounted in a control cabinet with ambient temperatures between 0°C and 60°C, with adequate ventilation to prevent overheating. Proper grounding is essential—connect the rack’s earth terminal to facility ground using 12-gauge wire to maximize isolation effectiveness. Use shielded twisted-pair cables for output wiring, matched to the connected device’s signal requirements (4-20mA or 0-10V).
For maintenance, calibrate the GE IC695ALG704 annually using a precision multimeter to maintain accuracy, as environmental factors can cause minor drift. Inspect terminal connections quarterly for corrosion or looseness, especially in humid environments, and tighten as needed. Monitor PLC fault logs for output errors, which may indicate a faulty device or wiring issue. Under normal operating conditions, the module has a service life of 7-9 years, with replacement recommended if calibration adjustments exceed allowable limits.
Product Warranty
The GE IC695ALG704 is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., covering defects in materials and workmanship. This warranty includes free replacement for any unit that fails under normal operating conditions within the coverage period. Sourced directly from trusted overseas suppliers, the GE IC695ALG704 meets strict quality standards, ensuring reliability in industrial environments. Our technical support team is available to assist with installation guidance, warranty claims, and troubleshooting, leveraging over a decade of industry experience to minimize downtime. We stand behind the module’s performance, committed to ensuring it delivers consistent analog control for your RX3i PLC system.
