Product Overview
The IC695CHS012CA is a 12-slot chassis designed as a foundational component of GE’s RX3i series programmable logic controller (PLC) systems, serving as the mechanical and electrical backbone for integrating critical automation modules. This chassis provides a structured framework to house CPU modules, I/O modules, communication interfaces, and power supplies, ensuring they operate as a cohesive unit. Its design is optimized for modular flexibility, allowing users to configure systems tailored to specific application needs—from small-scale setups with a few modules to more complex configurations requiring additional I/O or communication capabilities.
What makes IC695CHS012CA valuable is its robust construction, which supports reliable operation in industrial environments where vibration, temperature fluctuations, and electrical noise are common. By providing a standardized backplane for data and power distribution, IC695CHS012CA minimizes wiring complexity and reduces the risk of connection errors, streamlining both initial setup and future system expansions. Whether deployed in new installations or as an upgrade to existing RX3i systems, IC695CHS012CA ensures consistent performance and scalability.
Technical Specifications
| Parameter |
Value |
| Product Model |
IC695CHS012CA |
| Manufacturer |
GE |
| Product Type |
12-Slot Chassis (RX3i Series PLC) |
| Slot Count |
12 (supports RX3i CPU, I/O, and specialty modules) |
| Material |
Cold-rolled steel (frame), ABS (front panel) |
| Dimensions |
356 mm (H) x 133 mm (W) x 280 mm (D) |
| Weight |
2.8 kg (without modules) |
| Operating Temperature |
0°C to 60°C (ambient) |
| Mounting Type |
DIN rail or panel mount |
| Backplane Data Rate |
100 Mbps (shared bus for module communication) |
| Compatibility |
GE RX3i series modules (IC695CPU, IC695I/O, etc.) |
| Protection Rating |
IP20 (front panel) |
| Certifications |
CE, UL 508, CSA C22.2 No. 14 |
| Humidity Range |
5% to 95% RH (non-condensing) |
Key Features and Benefits
The IC695CHS012CA offers a 12-slot configuration that strikes a balance between compactness and expandability, making it suitable for applications requiring moderate I/O density without excessive space usage. Its cold-rolled steel frame provides structural rigidity, protecting installed modules from mechanical stress during operation or transportation, a critical feature in environments with frequent vibration, such as manufacturing floors or mobile equipment enclosures.
The integrated backplane of IC695CHS012CA simplifies module installation with tool-free locking mechanisms, allowing quick insertion and removal of RX3i components during setup or maintenance. This design reduces downtime when reconfiguring systems or replacing faulty modules. Additionally, the chassis supports hot-swappable modules (when used with compatible components), enabling repairs without powering down the entire system—an advantage for mission-critical operations where uninterrupted service is essential.
Thermal management is another strength: the open-frame design and strategic venting facilitate airflow around modules, preventing overheating even when fully populated. This ensures stable performance in high-temperature industrial settings. With certifications from global standards bodies, IC695CHS012CA meets safety and reliability requirements across international markets, making it a versatile choice for global industrial deployments.
Application Scenarios
The IC695CHS012CA is widely utilized in industries where modular automation systems are essential for adaptability and efficiency. In automotive manufacturing, it serves as the housing for RX3i PLC components controlling assembly line robots, conveyor systems, and quality inspection stations. Its 12-slot capacity allows integration of digital I/O modules for sensor data and analog modules for monitoring pressure or temperature in welding stations, all connected via the chassis backplane for synchronized operation.
In oil and gas refineries, IC695CHS012CA supports systems regulating pipeline valves, pump stations, and safety shutdown mechanisms. Its rugged construction withstands the harsh conditions of refinery environments—including exposure to dust, hydrocarbons, and temperature swings—while the modular design allows adding communication modules (such as Ethernet/IP) for integration with plant-wide SCADA systems.
Water and wastewater treatment plants also rely on IC695CHS012CA to house I/O modules monitoring flow rates, chemical dosing levels, and filtration systems. The chassis’s expandability lets operators add modules as treatment processes scale, ensuring the control system grows with facility needs without requiring a complete overhaul.
Related Models
IC695CHS008CA – 8-slot variant of IC695CHS012CA, ideal for smaller RX3i systems with lower I/O requirements.
IC695CHS016CA – 16-slot expansion of IC695CHS012CA, designed for high-density applications needing additional module capacity.
IC693CHS391 – Predecessor from GE’s 90-30 series, offering 10 slots but limited compatibility with RX3i modules compared to IC695CHS012CA.
IC695CHS012CR – Ruggedized version of IC695CHS012CA with extended temperature range (-25°C to 70°C) for extreme environments.
IC695CHS004CA – Compact 4-slot chassis, a space-saving alternative to IC695CHS012CA for minimalistic setups.
IC695CHS020CA – 20-slot high-capacity model, suitable for large-scale systems requiring integration of multiple CPUs and specialized modules alongside those used with IC695CHS012CA.
IC695CHS012CE – Enhanced version of IC695CHS012CA with isolated backplane segments to reduce electrical noise in sensitive applications.
Installation and Maintenance
Installation of IC695CHS012CA requires a clean, dry mounting surface with sufficient space for airflow—typically 150 mm of clearance above and below the chassis to prevent heat buildup. It can be mounted on standard DIN rails or directly to panels using pre-drilled holes, with secure grounding of the steel frame to minimize electrical interference. Before installation, ensure the mounting location is free from excessive vibration or exposure to corrosive substances, as these can degrade the chassis over time. Verify that all modules to be installed are compatible with RX3i specifications to avoid fitment issues.
For maintenance, inspect IC695CHS012CA semi-annually for signs of dust accumulation, which can impede cooling; use compressed air to clean vents if necessary. Check module locking levers to ensure they are fully engaged, preventing loose connections that could cause communication errors. Inspect the backplane connectors for corrosion or bent pins, especially in humid environments, and address any damage promptly. While the chassis itself has no moving parts, regular checks of adjacent components (like power supplies) ensure the entire system supported by IC695CHS012CA remains reliable.
Product Warranty
The IC695CHS012CA is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., covering defects in materials and workmanship under normal operating conditions. During the warranty period, we provide free replacement for any unit that fails to meet performance standards, ensuring minimal disruption to your operations. Our global support network offers technical assistance for installation and troubleshooting, leveraging our decade of experience in industrial automation. We stand behind the quality of IC695CHS012CA, confident in its ability to withstand industrial demands, and are committed to ensuring customer satisfaction through responsive service and reliable product support.
