Product Overview
The IC695CHS016-CA is a high-capacity 16-slot chassis from GE’s RX3i series, a versatile programmable logic controller (PLC) platform designed to support large-scale industrial automation systems. As a central backplane, its primary function is to facilitate seamless communication and power distribution among a wide range of RX3i modules, including CPUs, I/O cards, communication interfaces, and specialty modules. This integration capability makes the IC695CHS016-CA a critical component in setups where modularity, scalability, and reliable data flow are essential.
What sets the IC695CHS016-CA apart is its ability to accommodate complex configurations without sacrificing performance. With 16 slots, it eliminates the need for multiple smaller chassis in large systems, reducing wiring complexity and improving operational efficiency. Built to GE’s stringent standards, it delivers consistent performance in harsh industrial environments, from extreme temperatures to high electrical noise. Whether in process control or discrete manufacturing, the IC695CHS016-CA provides a robust foundation that adapts to evolving automation needs.
Technical Specifications
| Parameter |
Value |
| Product Model |
IC695CHS016-CA |
| Manufacturer |
GE |
| Product Type |
16-Slot PLC Chassis (RX3i Series) |
| Slot Count |
16 slots (compatible with RX3i modules) |
| Backplane Bandwidth |
160 Mbps (synchronous data transfer) |
| Operating Voltage |
24 VDC (via compatible power supply) |
| Operating Temperature |
0°C to 60°C (32°F to 140°F) |
| Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
| Dimensions (HxWxD) |
130 mm x 580 mm x 220 mm (5.1" x 22.8" x 8.7") |
| Mounting Type |
DIN rail (35 mm) or panel mount |
| Material |
Reinforced aluminum frame with steel cover |
| Certifications |
CE, UL, cUL, ATEX |
| Compatibility |
GE RX3i CPUs, I/O modules, and communication accessories |
Key Features and Benefits
The IC695CHS016-CA excels in scalability, making it ideal for large automation systems that require extensive module integration. Its 16-slot design allows for the integration of multiple CPUs, high-density I/O modules, and specialized communication cards, all working together via a 160 Mbps backplane. This high-speed data transfer ensures minimal latency, a critical advantage in time-sensitive applications such as real-time monitoring in power plants or synchronized motion control in automotive production lines.
Durability is a standout feature of the IC695CHS016-CA. Its reinforced aluminum frame and steel cover provide excellent resistance to mechanical stress and corrosion, while ATEX certification enables safe operation in hazardous areas like oil refineries and chemical plants. Unlike fixed-configuration systems, it supports hot-swappable modules (when paired with compatible RX3i components), allowing for maintenance or upgrades without shutting down the entire system—significantly reducing downtime.
Diagnostic capabilities enhance the usability of the IC695CHS016-CA. Integrated backplane monitoring tracks module health and connectivity, with alerts easily accessible through GE’s Proficy Machine Edition software. This proactive monitoring helps identify potential issues before they cause failures, a key benefit in mission-critical operations. Additionally, its compatibility with the entire RX3i ecosystem ensures seamless integration with existing GE systems, simplifying retrofits and expansions.
Application Scenarios
The IC695CHS016-CA is well-suited for large-scale industrial environments where complex automation demands robust integration. In power generation facilities, it serves as the backbone of control systems managing turbines, boilers, and auxiliary equipment, connecting hundreds of I/O points to ensure synchronized operation and real-time data flow to the plant’s DCS.
In oil and gas refineries, the IC695CHS016-CA thrives in hazardous areas, housing explosion-proof I/O modules and communication cards that link distillation units, storage tanks, and processing equipment. Its 16-slot capacity reduces the need for multiple chassis, streamlining system design and improving reliability.
Large automotive manufacturing plants also benefit from the IC695CHS016-CA, as it integrates robotic cells, vision inspection systems, and conveyor controls into a cohesive network. This centralization simplifies programming and monitoring, essential for maintaining high production rates in high-volume assembly lines.
Related Models
IC695CHS007-CA – 7-slot compact variant, ideal for smaller systems or space-constrained installations.
IC695CHS010-CA – 10-slot mid-range chassis, balancing capacity and footprint for medium-scale applications.
IC695PSD140 – 24 VDC power supply specifically designed to power the IC695CHS016-CA and connected modules.
IC695CPU331 – High-performance RX3i CPU module fully compatible with the IC695CHS016-CA for advanced control tasks.
IC695ETM002 – Gigabit Ethernet module that fits the IC695CHS016-CA, enabling high-speed network connectivity.
IC695I/O134 – 32-channel digital I/O module, a common companion to the IC695CHS016-CA in large-scale I/O applications.
IC695CHS016 – Non-CA variant with identical functionality, tailored for regions with different certification requirements.
IC695CMM003 – Serial communication module compatible with the IC695CHS016-CA, supporting Modbus and Profibus protocols.
Installation and Maintenance
Installation of the IC695CHS016-CA requires a sturdy mounting surface with adequate space—allow at least 150 mm of clearance on all sides to ensure proper airflow, which is crucial given its larger size. It can be mounted on a 35 mm DIN rail or directly to a panel using pre-drilled holes; ensure the surface can support its weight (approximately 4.5 kg when fully loaded). Proper grounding is essential: connect the chassis ground terminal to a dedicated earth ground (≤4Ω resistance) to minimize electrical interference, especially in high-noise environments.
For maintenance, inspect the IC695CHS016-CA quarterly. Use compressed air to remove dust from slots and vents, taking care not to damage internal components. Annually, verify backplane continuity with a multimeter to ensure consistent power and data transfer. Check module connectors for corrosion or wear, replacing any damaged parts promptly. With proper care, the IC695CHS016-CA is designed to operate reliably for 10+ years in typical industrial conditions.
Product Warranty
The IC695CHS016-CA is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., covering manufacturing defects and premature failure under normal operating conditions. This includes free replacement of the IC695CHS016-CA if it malfunctions within the warranty period. Beyond the warranty, Xiongba’s global support network provides technical assistance, including installation guidance and troubleshooting, to minimize downtime. With over a decade of experience in industrial automation, the company stands behind the quality of the IC695CHS016-CA, ensuring customers have confidence in their investment and access to reliable service when needed.
