Product Overview
The IC695CPE302 is a high-performance CPU module from GE’s RX3i series, serving as the "brain" of programmable logic controller (PLC) systems in industrial automation. Its core function is to execute control logic, process real-time data from connected I/O modules, and manage communication with external devices such as HMIs, SCADA systems, and other controllers. As a key component in RX3i setups, the IC695CPE302 plays a critical role in ensuring precise, synchronized operation of complex industrial processes.
What makes the IC695CPE302 valuable is its balance of processing power and efficiency. Designed to handle demanding control tasks without sacrificing speed, it supports large program sizes and high I/O counts, making it suitable for mid-to-large scale applications. Its compatibility with all RX3i modules—including communication modules like the IC695CMU310-DL and I/O cards—ensures flexibility, whether deployed in new systems or as an upgrade to existing RX3i installations. The IC695CPE302 thus delivers the reliability and performance needed to keep industrial operations running smoothly.
Technical Specifications
| Parameter |
Value |
| Product Model |
IC695CPE302 |
| Manufacturer |
GE |
| Product Type |
CPU Module (RX3i Series) |
| Processor |
32-bit RISC, 400 MHz |
| Program Memory |
8 MB flash (expandable to 16 MB) |
| Data Memory |
4 MB RAM |
| Communication Ports |
1 x Ethernet (10/100 Mbps), 1 x serial (RS-232) |
| Operating Voltage |
24 VDC (from RX3i chassis) |
| Operating Temperature |
0°C to 60°C (32°F to 140°F) |
| Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
| Dimensions (HxWxD) |
120 mm x 30 mm x 180 mm (4.7" x 1.2" x 7.1") |
| Mounting Type |
RX3i chassis slot (primary CPU slot) |
| Certifications |
CE, UL, cUL |
| Power Consumption |
Max 8 W |
| Compatibility |
GE RX3i chassis (IC695CHS007-CA, IC695CHS016-CA, etc.) |
Key Features and Benefits
The IC695CPE302 delivers exceptional processing power with its 400 MHz 32-bit RISC processor, enabling rapid execution of complex control logic—critical for applications like high-speed packaging lines or precision chemical mixing. Its expandable program memory (up to 16 MB) accommodates large, sophisticated programs, while 4 MB RAM ensures ample space for real-time data storage, reducing the need for external memory modules.
Communication capabilities are a strong suit of the IC695CPE302. The built-in Ethernet port supports fast data exchange with HMIs and SCADA systems, while the RS-232 port enables connectivity with legacy devices, ensuring compatibility with existing infrastructure. This versatility simplifies integration in mixed-technology environments.
Reliability is embedded in the IC695CPE302’s design. It includes watchdog timers and error-checking mechanisms to detect and recover from faults, minimizing unplanned downtime. Integration with GE’s Proficy Machine Edition software allows easy programming, monitoring, and diagnostics, putting powerful tools at technicians’ fingertips. Its rugged construction ensures stable performance in harsh industrial conditions, making it a dependable choice for critical operations.
Application Scenarios
The IC695CPE302 is a cornerstone in mid-to-large scale automation systems across industries. In chemical processing plants, it manages complex batch recipes, coordinating valves, pumps, and temperature sensors to ensure precise mixing and reaction times. Its processing speed is vital here, as delays could compromise product quality or safety.
In automotive assembly, the IC695CPE302 controls robotic welding stations, conveyor systems, and quality inspection tools, synchronizing their actions to maintain production 节奏. Its ability to handle multiple I/O points ensures all components work in harmony, reducing cycle times.
For water treatment facilities, the IC695CPE302 oversees filtration, disinfection, and distribution processes, processing data from hundreds of sensors to adjust operations in real time. Its reliability in damp environments and compatibility with communication modules like the IC695CMU310-DL make it ideal for these settings.
In all these applications, the IC695CPE302 serves as the central processing hub, ensuring automation systems operate efficiently, safely, and consistently.
Related Models
IC695CPE300 – Entry-level RX3i CPU with lower processing speed (200 MHz) for smaller applications.
IC695CPE402 – High-performance variant with 800 MHz processor and expanded memory for large-scale systems.
IC695CHS016-CA – 16-slot RX3i chassis optimized for use with the IC695CPE302 in large setups.
IC695CMU310-DL – Communication module that pairs with the IC695CPE302 to extend connectivity.
IC695PWR120 – Power supply module compatible with the IC695CPE302 for stable operation.
IC695MEM102 – Memory expansion module that increases the IC695CPE302’s program storage to 16 MB.
IC695CPE302-DL – Ruggedized version of the IC695CPE302 with extended temperature range (-20°C to 70°C).
IC695I/O134 – 32-channel digital I/O module commonly used with the IC695CPE302 to expand input/output capabilities.
Installation and Maintenance
Installing the IC695CPE302 requires a compatible RX3i chassis (such as the IC695CHS016-CA) with a designated primary CPU slot. Power off the chassis before insertion, then slide the module into the slot until it locks into place—ensure the connection is secure to prevent communication issues. Verify the chassis is properly grounded and supplied with stable 24 VDC power to avoid damage.
For maintenance, schedule quarterly checks of the
IC695CPE302. Inspect the module for dust buildup, using compressed air to clean vents if necessary. Back up program and configuration data regularly via Proficy software to prevent loss in case of failure. Check firmware versions annually and update as needed to access new features and security patches. Monitor CPU load and memory usage during operation—consistently high load may indicate the need for a higher-capacity model. With proper care, the
IC695CPE302 is designed to operate reliably for 10+ years.
Product Warranty
The IC695CPE302 is covered by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., protecting against manufacturing defects and premature failure under normal operating conditions. If the IC695CPE302 malfunctions within this period, the company provides free replacement to minimize downtime. Xiongba’s technical support team offers assistance with installation, programming, and troubleshooting, leveraging over a decade of industry experience to ensure customers get the most from their investment. This commitment to quality and service gives users confidence in the IC695CPE302’s performance and longevity.
