Product Overview
The IC695CPE330-AAAB is a high-performance CPU module within GE’s RX3i series, engineered as a central processing hub for large-scale industrial automation systems. Designed to handle complex control tasks, its core function is to execute advanced logic, process real-time data from hundreds of connected I/O modules, and manage seamless communication with HMIs, SCADA systems, and other controllers. This makes the IC695CPE330-AAAB a cornerstone in setups where speed, scalability, and region-specific compliance are critical.
What distinguishes the IC695CPE330-AAAB is its enhanced processing power and tailored firmware, optimized for specific regional standards—such as North American industrial protocols and safety certifications. This ensures it integrates smoothly into local infrastructure, eliminating compliance barriers. Whether deployed in new plants or retrofitted into existing RX3i systems, the IC695CPE330-AAAB delivers consistent performance in harsh environments, from high-vibration factories to temperature-fluctuating processing facilities, solidifying its role as a reliable industrial CPU.
Technical Specifications
| Parameter |
Value |
| Product Model |
IC695CPE330-AAAB |
| Manufacturer |
GE |
| Product Type |
High-Performance CPU Module (RX3i Series) |
| Processor |
32-bit RISC, 1 GHz |
| Program Memory |
32 MB flash (expandable to 64 MB) |
| Data Memory |
16 MB RAM (ECC-enabled) |
| Communication Ports |
2 x Gigabit Ethernet, 1 x RS-485 |
| Operating Voltage |
24 VDC (from RX3i chassis) |
| Operating Temperature |
-20°C to 70°C (-4°F to 158°F) |
| Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
| Dimensions (HxWxD) |
120 mm x 30 mm x 180 mm (4.7" x 1.2" x 7.1") |
| Mounting Type |
RX3i chassis primary CPU slot |
| Certifications |
UL, cUL, CSA, [Region-Specific Standards] |
| Power Consumption |
Max 12 W |
| Compatibility |
GE RX3i chassis (IC695CHS016-CA, IC695CHS010-CA, etc.) |
Key Features and Benefits
The IC695CPE330-AAAB stands out with its 1 GHz processor, delivering 2x faster logic execution than previous RX3i models—critical for large-scale systems like automotive assembly lines or multi-zone chemical plants. Its 32 MB expandable flash memory accommodates sophisticated programs, while 16 MB ECC RAM ensures data integrity, even in high-noise environments.
Communication capabilities are a highlight: dual Gigabit Ethernet ports enable high-speed data exchange with cloud platforms and SCADA systems, while the RS-485 port supports legacy devices, ensuring backward compatibility. The module’s region-specific firmware aligns with North American standards (e.g., NEC electrical codes), simplifying compliance and reducing installation delays.
Reliability is engineered into the IC695CPE330-AAAB, with an extended temperature range (-20°C to 70°C) for harsh environments and watchdog timers to recover from faults. Integration with GE’s Proficy Machine Edition software streamlines programming, with tools for real-time monitoring and diagnostics. Whether in dusty warehouses or outdoor installations, its rugged design ensures consistent performance, making it a trusted core for critical operations.
Application Scenarios
The IC695CPE330-AAAB excels in large-scale North American industrial setups. In automotive plants, it controls robotic welding stations, paint lines, and final assembly checks, using its 1 GHz processor to synchronize 100+ I/O points and maintain production 节奏. Its compliance with UL standards ensures it meets factory safety requirements.
In oil and gas midstream facilities, the IC695CPE330-AAAB manages pipeline pumps, pressure sensors, and valve controllers, processing real-time data to prevent overpressure events. Its extended temperature range withstands outdoor installations in cold climates, while Gigabit Ethernet connects to cloud-based monitoring platforms for remote oversight.
For water treatment plants in the region, it oversees filtration and disinfection systems, adjusting operations based on sensor data. Its compatibility with local SCADA systems and adherence to CSA standards make it a seamless fit. In all cases, the
IC695CPE330-AAAB acts as the central hub, ensuring efficient, compliant operation.
Related Models
IC695CPE330 – Base model without region-specific firmware, suitable for global applications.
IC695CPE310-AAAB – Previous generation with 600 MHz processor, compatible with the IC695CPE330-AAAB’s systems.
IC695CHS016-CA – 16-slot chassis optimized for the IC695CPE330-AAAB in large I/O setups.
IC695CMU310-DL – Communication module pairing with the IC695CPE330-AAAB to extend protocol support.
IC695MEM108 – Memory expansion module boosting the IC695CPE330-AAAB’s storage to 64 MB.
IC695CPE330-ABAF – Regional variant with European certifications, detailed below.
Installation and Maintenance
Installing the IC695CPE330-AAAB requires a compatible RX3i chassis (e.g., IC695CHS016-CA) with a primary CPU slot. Power off the chassis, slide the module into place until it locks, and verify a secure connection. Ensure the chassis is grounded to ≤4Ω and supplied with stable 24 VDC to avoid damage.
For maintenance, inspect quarterly: use compressed air to clean vents and check for loose connections. Back up programs via Proficy software monthly, using region-specific protocols. Update firmware annually with North American-optimized releases. Monitor CPU load—sustained high usage may require a higher-capacity model. With care, the
IC695CPE330-AAAB operates reliably for 10+ years.
Product Warranty
The IC695CPE330-AAAB is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., covering defects under normal use. This includes free replacement if the module fails, with support from technicians familiar with North American standards. Xiongba’s decade of experience ensures reliable service, giving customers confidence in the IC695CPE330-AAAB’s performance.
