Product Overview
The IC695CRU320-DZ is a critical redundancy control unit designed for GE’s RX3i series, serving as the backbone of fault-tolerant industrial automation systems. Its primary function is to enable seamless failover between primary and backup CPU modules, ensuring uninterrupted operation in environments where even seconds of downtime can result in significant losses.
As a key component in the RX3i ecosystem, the IC695CRU320-DZ synchronizes data and operations between paired CPUs (such as the IC695CPU374), monitoring system health in real time to detect failures. When a primary CPU encounters an issue, the IC695CRU320-DZ triggers an automatic switch to the backup unit, typically within milliseconds, preventing process disruptions. What sets the IC695CRU320-DZ apart is its ability to maintain precise synchronization without data loss, combined with robust design that withstands industrial harshness. This makes it invaluable for mission-critical applications where reliability is non-negotiable, reinforcing the RX3i system’s reputation for resilience.
Technical Specifications
| Parameter |
Value |
| Product Model |
IC695CRU320-DZ |
| Manufacturer |
GE |
| Product Type |
Redundancy Control Unit (RX3i Series) |
| Compatibility |
GE RX3i CPUs (IC695CPU374, IC695CPU380, etc.) |
| Failover Time |
< 50 ms typical |
| Synchronization Method |
Real-time data mirroring |
| Power Requirements |
5V DC, 1.2A |
| Operating Temperature Range |
-20°C to 70°C |
| Dimensions (W x H x D) |
110mm x 85mm x 145mm |
| Mounting Type |
DIN Rail (35mm) |
| Diagnostic Outputs |
LED status indicators, error logging via RX3i software |
| Redundancy Type |
Hot standby (no process interruption during switchover) |
| Communication Interface |
Integrated backplane for CPU synchronization |
Key Features and Benefits
The IC695CRU320-DZ delivers ultra-fast failover, with typical switchover times under 50 ms—fast enough to prevent process trips in time-sensitive applications like turbine control or chemical batch processing. This speed is achieved through advanced real-time synchronization, which mirrors all CPU operations, data, and configuration settings between primary and backup units continuously.
Seamless integration with RX3i CPUs eliminates compatibility issues, allowing easy retrofitting into existing systems. The unit’s diagnostic capabilities, including LED status indicators and software-integrated error logs, provide clear visibility into redundancy status, making it simple to identify issues before they escalate.
Built to industrial standards, the IC695CRU320-DZ operates reliably in extreme temperatures (-20°C to 70°C) and resists vibration and electrical noise, ensuring performance in harsh environments like offshore platforms or steel mills. Its low power consumption (1.2A at 5V DC) minimizes strain on system power supplies, while the compact design saves space in control cabinets.
Perhaps most importantly, the IC695CRU320-DZ reduces operational risk by eliminating single points of failure. This translates to lower maintenance costs, fewer production losses, and enhanced compliance with safety standards in regulated industries.
Application Scenarios
The IC695CRU320-DZ finds its greatest utility in industries where continuous operation is mission-critical. In power generation, for example, it is deployed in coal-fired and nuclear plants to protect turbine control systems. A sudden CPU failure here could lead to turbine shutdowns, costing thousands in lost generation and requiring hours to restart—risks mitigated by the IC695CRU320-DZ’s instant failover.
In oil and gas refineries, the IC695CRU320-DZ safeguards processes like distillation column controls and pipeline pumping stations. A disruption in these systems could cause product contamination, equipment damage, or safety hazards, making the unit’s redundancy essential for maintaining operational integrity.
Water and wastewater treatment facilities rely on the IC695CRU320-DZ to ensure continuous operation of pump stations and chemical dosing systems. Interruptions here could lead to untreated water releases or service outages, violating environmental regulations and impacting public health.
Semiconductor manufacturing, where even brief downtime can ruin expensive wafers, also benefits from the IC695CRU320-DZ. It protects control systems for precision deposition and etching equipment, preserving production yields and reducing waste.
Related Models
IC695CRU320 – Base model without the -DZ designation, offering similar redundancy features but with a narrower temperature range (-10°C to 55°C).
IC695CPU374 – Primary CPU module commonly paired with IC695CRU320-DZ in RX3i redundant systems.
IC695CPU380 – High-performance CPU compatible with IC695CRU320-DZ, ideal for large-scale redundant setups.
IC695PWR330 – Power supply module optimized for use with IC695CRU320-DZ and RX3i redundancy configurations, providing stable power to both CRU and CPUs.
IC695ETM001 – Ethernet module that integrates with IC695CRU320-DZ to enable remote monitoring of redundancy status.
IC695CRU310 – Legacy redundancy unit for older RX3i systems, with slower failover times (100+ ms) compared to IC695CRU320-DZ.
IC695I/O131 – Digital I/O module that works alongside IC695CRU320-DZ in redundant systems, ensuring I/O signals remain operational during CPU switchover.
IC695LRE001 – Redundancy link extension module that allows IC695CRU320-DZ to support longer distances between primary and backup CPUs in distributed setups.
Installation and Maintenance
Installation preparation for the IC695CRU320-DZ requires a compatible RX3i chassis with sufficient slots to accommodate both the unit and paired CPUs. Ensure the mounting DIN rail is securely fastened to a stable surface to minimize vibration, which can disrupt synchronization. The environment should be free from excessive dust, moisture, and corrosive gases, with temperatures within -20°C to 70°C. Proper grounding (using 6mm² copper wire) is critical to reduce electrical noise that could interfere with synchronization signals. Verify compatibility with the target CPU model (e.g., IC695CPU374) before installation to ensure seamless integration.
Maintenance for the IC695CRU320-DZ involves quarterly checks of LED status indicators to confirm normal operation—steady green lights indicate proper synchronization, while flashing or red lights signal issues. Use GE’s Proficy software monthly to review error logs and verify synchronization accuracy. Clean the module’s vents annually with compressed air to prevent overheating. Replace the unit if persistent synchronization failures occur despite troubleshooting, with an expected service life of 8–10 years under typical operating conditions.
