Product Overview
The IC695SPF002 is a specialized safety power filter module designed for GE’s RX3i series of industrial automation systems, engineered to protect sensitive electronic components from electrical noise, voltage transients, and power surges. As a critical protective component in the RX3i ecosystem, its primary function is to clean incoming power supplies by filtering out high-frequency interference and suppressing transient voltage spikes, ensuring only stable, noise-free power reaches connected RX3i modules such as CPUs, I/O units, and communication interfaces.
Unlike standard power filters, the IC695SPF002 is optimized for industrial environments where electrical noise—generated by heavy machinery, motors, or variable frequency drives—is prevalent. It integrates seamlessly into RX3i systems, adding a layer of protection that prevents interference-induced malfunctions, data corruption, or component damage. What sets the IC695SPF002 apart is its balance of high filtering efficiency and low power loss, ensuring it enhances system reliability without compromising power delivery. Whether in factories with high electromagnetic interference (EMI) or facilities with unstable power grids, the IC695SPF002 acts as a "shield" for RX3i systems, extending their operational lifespan and reducing unplanned downtime.
Technical Specifications
| Parameter |
Value |
| Product Model |
IC695SPF002 |
| Manufacturer |
GE |
| Product Type |
Safety Power Filter Module (RX3i Series) |
| Input Voltage Range |
85–264V AC, 50/60 Hz |
| Output Voltage Range |
85–264V AC (filtered), 50/60 Hz |
| Filtering Frequency |
10 kHz–30 MHz |
| Surge Handling Capacity |
6 kV (contact), 10 kV (air) per IEC 61000-4-5 |
| Operating Temperature Range |
-10°C to 60°C |
| Dimensions (W x H x D) |
90mm x 75mm x 140mm |
| Mounting Type |
DIN Rail (35mm) |
| Compatibility |
GE RX3i Power Supplies (IC695PSA140, IC695PSD040H) and RX3i Chassis |
| Insertion Loss |
≥30 dB at 1 MHz |
| Protection Rating |
IP20 (control cabinet installation) |
Key Features and Benefits
The IC695SPF002 delivers exceptional noise filtering across a broad frequency range (10 kHz–30 MHz), effectively mitigating interference from industrial equipment like motors, welders, and transformers—common sources of EMI that can disrupt RX3i CPU operations. This filtering ensures stable communication between modules and prevents data errors in time-sensitive processes, such as synchronized manufacturing lines.
High surge handling capacity (6 kV contact, 10 kV air) protects RX3i components from voltage spikes caused by lightning strikes, grid switching, or equipment startups, reducing the risk of costly component failures. Its low insertion loss (≤1 dB at 50 Hz) ensures minimal power degradation, so filtered power remains efficient and meets the RX3i system’s voltage requirements.
Seamless compatibility with RX3i power supplies (e.g., IC695PSA140) and chassis allows for easy integration into existing systems without modifications, simplifying upgrades or retrofits. The module’s rugged design—operating reliably in -10°C to 60°C temperatures—ensures performance in harsh environments, from foundries to outdoor enclosures.
By extending the lifespan of connected RX3i modules and reducing downtime from electrical issues, the IC695SPF002 lowers long-term maintenance costs. Its compact size saves space in control cabinets, making it suitable for both new installations and system expansions.
Application Scenarios
The IC695SPF002 is widely deployed in industries where electrical noise and surges pose significant risks to automation systems. In automotive manufacturing plants, it protects RX3i CPUs and I/O modules controlling robotic assembly lines, where EMI from spot welders and conveyor motors can disrupt sensor data and cause positioning errors. By filtering power, the IC695SPF002 ensures consistent robot performance, reducing scrap rates and rework.
In metal processing facilities, the IC695SPF002 safeguards RX3i systems managing rolling mills and forging presses. These environments generate intense electrical noise from high-power motors, and the module’s surge protection prevents voltage spikes from damaging temperature controllers or pressure sensors—critical for maintaining precise metal forming conditions.
Oil and gas refineries rely on the IC695SPF002 to protect RX3i modules in pump stations and valve control systems. Lightning strikes or switching transients in remote pipeline networks can send surges through power lines; the module’s robust filtering ensures these transients do not reach sensitive communication interfaces, preventing lost data or system shutdowns.
In renewable energy plants (solar or wind), the IC695SPF002 filters power for RX3i systems monitoring inverter performance and grid synchronization. Fluctuations in renewable energy generation create electrical noise, and the module ensures stable operation of data loggers and control algorithms, supporting efficient energy distribution.
Related Models
IC695SPF001 – Previous generation power filter with basic noise suppression (10 kHz–10 MHz range), suitable for low-interference environments.
IC695SPF003 – Advanced variant with enhanced surge handling (8 kV contact) and extended frequency filtering (1 kHz–50 MHz) for high-noise settings.
IC695PSA140 – RX3i power supply commonly paired with IC695SPF002 to deliver clean, filtered power to the system.
IC695PWR330 – Compact power supply compatible with IC695SPF002, ideal for small RX3i setups needing noise protection.
IC695SPS010 – Safety monitoring module that works with IC695SPF002 to provide comprehensive system protection in safety-critical applications.
IC695EMI001 – External EMI filter designed to complement IC695SPF002 in extreme noise environments, such as near radio transmitters.
IC695PSD040H – Redundant power supply that integrates with IC695SPF002 to ensure filtered power in failover configurations.
Installation and Maintenance
Installation preparation for the IC695SPF002 requires a 35mm DIN rail in a control cabinet with ambient temperatures between -10°C and 60°C. Ensure the module is mounted upstream of RX3i power supplies (e.g., IC695PSA140) to filter power before it reaches system components. Use 16AWG wiring for input and output connections, and verify tight terminations to prevent resistance-induced heating. Proper grounding (4mm² copper wire) is critical to effective noise dissipation—connect the module’s ground terminal directly to the cabinet’s main ground bus.
Maintenance for the IC695SPF002 involves quarterly visual inspections of wiring and terminals to check for corrosion or looseness. Annually, use an EMI analyzer to verify filtering efficiency; a drop in performance (e.g., insertion loss below 25 dB at 1 MHz) indicates the need for replacement. After a significant surge event (e.g., lightning strike), test the module’s surge handling capability—replace it if damage is suspected, as internal components may degrade without visible signs. The module has an expected service life of 7–9 years under normal conditions.
Product Warranty
The IC695SPF002 is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd. Branch, covering manufacturing defects and performance issues under normal operating conditions. During this period, any verified faults—such as reduced filtering efficiency or failed surge protection—will be addressed with free replacement, ensuring minimal disruption to your RX3i system’s protective infrastructure. Our technical support team provides guidance on installation, grounding, and performance testing, leveraging global resources to deliver timely assistance. Sourced directly from trusted manufacturers, the IC695SPF002 is guaranteed authentic, and our warranty reflects confidence in its reliability as a critical protective component. We are committed to ensuring your industrial automation systems remain shielded from electrical threats, with the support needed to maintain uninterrupted operation.
