Product Overview
The GE IC697BEM713-J is a critical backplane expansion module designed for GE’s 90-70 series Programmable Logic Controllers (PLCs), a staple in industrial automation systems. As a key component in modular control architectures, GE IC697BEM713-J enables seamless expansion of I/O capabilities, allowing users to connect additional input/output modules to the 90-70 backplane without compromising system performance. This flexibility is invaluable in setups where process requirements evolve, as it eliminates the need for complete system overhauls.
What sets GE IC697BEM713-J apart is its robust design, engineered to maintain reliable communication between the PLC’s central processing unit (CPU) and expanded I/O modules even in harsh industrial environments. By acting as a bridge between the main backplane and auxiliary modules, it ensures data transfer speeds remain consistent, supporting real-time control operations. Whether deployed in small-scale machinery or large industrial complexes, GE IC697BEM713-J enhances system scalability, making it a cost-effective solution for growing automation needs.
Technical Specifications
| Parameter |
Value |
| Product Model |
GE IC697BEM713-J |
| Manufacturer |
GE |
| Product Type |
Backplane Expansion Module |
| Compatible Series |
GE 90-70 PLC Series |
| Backplane Support |
10-slot and 16-slot backplanes |
| Power Requirements |
5V DC (from backplane) |
| Operating Temperature |
0°C to 60°C (32°F to 140°F) |
| Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
| Dimensions |
127mm x 89mm x 38mm (5.0" x 3.5" x 1.5") |
| Weight |
Approx. 150g (0.33 lbs) |
| Communication Protocol |
Proprietary GE 90-70 backplane protocol |
| Mounting Type |
DIN rail or panel mount (via backplane) |
| Protection Rating |
IP20 (indoor, panel-mounted) |
Key Features and Benefits
GE IC697BEM713-J excels in modular scalability, allowing users to expand their 90-70 PLC systems with additional I/O modules—such as analog input cards, digital output modules, or communication interfaces—without disrupting existing operations. This modular approach reduces upfront investment by enabling incremental expansion as needs grow, a critical advantage for facilities with evolving production demands.
Another standout feature is its robust data integrity. GE IC697BEM713-J incorporates built-in error-checking mechanisms to ensure accurate communication between the CPU and expanded modules, minimizing the risk of data loss or system errors. This reliability is enhanced by its industrial-grade construction, which resists vibration, electromagnetic interference (EMI), and temperature fluctuations common in factory floors and process plants.
Installation is streamlined thanks to plug-and-play compatibility with 90-70 backplanes, reducing setup time and technical expertise required. Additionally,
GE IC697BEM713-J supports hot-swapping of compatible I/O modules in some configurations, allowing for maintenance or upgrades without shutting down the entire system—significantly reducing downtime and operational disruptions.
Application Scenarios
GE IC697BEM713-J finds its place in a variety of industrial settings where modular PLC systems are central to operations. In automotive manufacturing plants, it enables expansion of assembly line control systems, supporting additional sensors and actuators as production lines are reconfigured for new vehicle models. Its ability to handle multiple I/O types makes it ideal for integrating robotics, conveyor systems, and quality control sensors into a unified control architecture.
In water and wastewater treatment facilities, GE IC697BEM713-J facilitates the addition of flow meters, pressure transducers, and valve control modules to monitor and adjust treatment processes. This scalability is crucial as plants upgrade to meet stricter regulatory standards or expand capacity.
Power generation facilities also benefit from GE IC697BEM713-J, where it expands control capabilities for auxiliary systems like fuel handling, cooling water pumps, and emissions monitoring. Its reliability in high-temperature environments ensures consistent performance even in the demanding conditions of power plants.
Related Models
IC697BEM711 – Earlier generation backplane expansion module for 90-70 systems with basic compatibility, limited to 8-slot backplanes.
IC697BEM712 – Intermediate model with improved EMI resistance, serving as a predecessor to GE IC697BEM713-J.
IC697BEM714 – Higher-capacity variant of GE IC697BEM713-J, supporting 20-slot backplanes for larger-scale expansions.
IC697CHS791 – 10-slot backplane designed to work seamlessly with GE IC697BEM713-J for foundational system builds.
IC697CPU780 – High-performance 90-70 CPU module fully compatible with GE IC697BEM713-J for expanded control systems.
IC697ALG220 – Analog input module commonly paired with GE IC697BEM713-J to add temperature and pressure sensing capabilities.
IC697DIA320 – Digital input module that integrates with GE IC697BEM713-J for monitoring limit switches and proximity sensors.
IC697BEM715 – Ruggedized version of GE IC697BEM713-J with extended temperature range (-20°C to 70°C) for harsh environments.
Installation and Maintenance
Installation of GE IC697BEM713-J requires a compatible 90-70 backplane (10-slot or 16-slot) with proper grounding to prevent EMI. Ensure the mounting location provides adequate ventilation, as the module relies on ambient cooling. The backplane should be securely fastened to a DIN rail or panel, with sufficient space (minimum 50mm) around the module for wiring and heat dissipation. Prior to installation, verify that the backplane power supply (5V DC) is stable to avoid damage during initial setup.
For maintenance, regularly inspect connections between GE IC697BEM713-J and the backplane to ensure tight, corrosion-free contacts—this prevents intermittent communication issues. Use the 90-70 PLC’s diagnostic software to check for error codes related to the expansion module, addressing any alerts promptly. While GE IC697BEM713-J has a long service life, consider replacement every 8–10 years in high-vibration environments to maintain optimal performance.
Product Warranty
GE IC697BEM713-J is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., covering manufacturing defects and performance issues under normal operating conditions. During the warranty period, we offer free replacement for any faulty units, ensuring minimal disruption to your operations. Our global support network provides technical assistance for installation, troubleshooting, and compatibility checks, leveraging over a decade of industrial automation expertise. We stand behind the quality of GE IC697BEM713-J, ensuring it meets the rigorous demands of industrial environments and delivering peace of mind to our customers.
