Product Overview
The GE IC697CHS790G is a high-performance chassis module designed as the foundational component of GE’s Series 90-70 programmable logic controller (PLC) systems, serving as the structural and connectivity hub for industrial automation setups. Its primary role is to house and interconnect critical system components, including processors, I/O modules, power supplies, and communication cards, ensuring seamless data transfer and power distribution across the system.
As a 10-slot chassis, the GE IC697CHS790G provides ample space for configuring tailored automation solutions, balancing compact design with expandability. What makes it valuable is its robust construction, optimized for industrial environments, and its compatibility with the full range of Series 90-70 modules—eliminating integration barriers. By providing a secure, standardized platform, the GE IC697CHS790G ensures that all system components work in harmony, reducing downtime and simplifying maintenance. Whether in new installations or system upgrades, the GE IC697CHS790G is a reliable backbone for mission-critical control systems.
Technical Specifications
| Parameter |
Value |
| Product Model |
GE IC697CHS790G |
| Manufacturer |
GE |
| Product Type |
PLC Chassis Module |
| Number of Slots |
10 slots (for Series 90-70 modules) |
| Compatible Modules |
Processors, I/O modules, power supplies, communication cards |
| Material |
Cold-rolled steel with powder coating |
| Dimensions |
356mm x 178mm x 114mm (L x W x H) |
| Mounting Type |
Panel mount or 35mm DIN rail |
| Operating Temperature |
0°C to 60°C (32°F to 140°F) |
| Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
| Weight |
Approximately 2.8kg |
| EMI/RFI Protection |
Compliant with EN 61000-6-2 industrial standards |
| Backplane Bus Speed |
10 Mbps |
| Compliance |
UL, CE, CSA certified |
| Humidity Resistance |
5% to 95% non-condensing |
Key Features and Benefits
The GE IC697CHS790G excels in providing a flexible, durable platform for Series 90-70 systems. Its 10-slot design strikes a balance between compactness and expandability, making it suitable for both small-scale setups (e.g., standalone machines) and mid-sized systems requiring multiple I/O modules and communication interfaces. This versatility allows users to start with a basic configuration and scale up by adding modules as needs evolve.
A standout feature is the chassis’s robust steel construction, which protects internal components from physical damage, vibration, and electromagnetic interference (EMI)—common in industrial environments like factories or power plants. The powder coating adds corrosion resistance, extending the GE IC697CHS790G’s lifespan even in humid or dusty conditions.
The integrated backplane bus, operating at 10 Mbps, ensures fast, reliable data transfer between modules, critical for real-time control applications where delays could impact process accuracy. Compatibility with all Series 90-70 components eliminates integration headaches, allowing engineers to mix and match modules without worrying about protocol conflicts. Additionally, the GE IC697CHS790G’s tool-less module insertion simplifies installation and maintenance, reducing downtime during upgrades or replacements.
Application Scenarios
The GE IC697CHS790G is widely deployed in industries where reliable, scalable automation is essential. In power generation facilities, for example, it serves as the housing for Series 90-70 processors and I/O modules that monitor and control turbine operations, boiler systems, and electrical distribution. The GE IC697CHS790G’s rugged design ensures these critical components remain protected in environments with high vibration and temperature fluctuations.
In chemical processing plants, where precise control of mixing, heating, and pressure is vital, the GE IC697CHS790G houses modules that regulate valves, pumps, and sensors. Its 10-slot capacity allows integration of multiple I/O modules to handle the diverse range of process variables, while the fast backplane bus ensures timely data transmission for safe, efficient operation.
In automotive manufacturing, the
GE IC697CHS790G supports PLC systems controlling assembly line robots, conveyor belts, and quality inspection tools. Its expandability lets manufacturers add modules as production lines are upgraded, ensuring the automation system keeps pace with changing production demands without requiring a complete overhaul.
Related Models
GE IC697CHS780 – 5-slot compact variant of the GE IC697CHS790G, ideal for space-constrained setups with minimal module requirements.
GE IC697CHS791 – 16-slot high-capacity chassis, offering expanded module support for larger systems needing more I/O than the GE IC697CHS790G.
GE IC697CHS750 – Redundant chassis system that pairs with the GE IC697CHS790G to provide failover protection in mission-critical applications.
GE IC697CHS760 – Previous generation 10-slot chassis with basic backplane functionality, superseded by the GE IC697CHS790G’s enhanced EMI protection.
GE IC693CHS390 – 10-slot chassis for GE’s smaller Series 90-30 PLCs, sharing design principles but optimized for lower-power modules.
GE IC697CHS790F – Ruggedized version of the GE IC697CHS790G with extended temperature range (-20°C to 70°C) for extreme environments.
GE IC697CHS792 – Smart chassis with built-in diagnostic features, offering real-time monitoring of backplane health compared to the standard GE IC697CHS790G.
GE IC697CHS770 – 8-slot mid-range chassis, balancing capacity between the 5-slot IC697CHS780 and 10-slot GE IC697CHS790G.
Installation and Maintenance
Installation of the GE IC697CHS790G requires a stable mounting surface—either a 35mm DIN rail or a panel—with sufficient space for module insertion and airflow (minimum 50mm clearance on all sides). Ensure the mounting location is free from direct exposure to water, chemicals, or excessive vibration. Proper grounding of the chassis is critical to minimize EMI; connect the grounding terminal to the system’s main ground bus before installing modules. Verify that the power supply module (compatible with Series 90-70) is correctly rated to support the total load of modules planned for the GE IC697CHS790G.
For maintenance, inspect the GE IC697CHS790G quarterly to ensure module connections are secure, as loose fittings can cause communication errors. Clean dust from the chassis vents using compressed air to maintain airflow and prevent overheating. Check the steel frame for signs of corrosion annually, especially in humid environments, and touch up paint if needed to protect against further damage. While the GE IC697CHS790G is designed for long service, consider replacing it every 10-12 years in harsh conditions to avoid backplane degradation that could affect system performance.
Product Warranty
The
GE IC697CHS790G is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., covering manufacturing defects and ensuring reliable performance. During this period, we offer free replacement for any faulty units, minimizing operational downtime. Our technical support team is available globally to assist with installation guidance, troubleshooting, and compatibility questions, leveraging our decade of experience in industrial automation. We stand behind the
GE IC697CHS790G’s quality, sourced directly from trusted suppliers, and are committed to ensuring customer satisfaction through responsive service and reliable products.
