Product Overview
The GE IC697CPX9285 is a high-performance central processing unit (CPU) module, serving as the core of GE’s Series 90-70 programmable logic controller (PLC) systems. Designed to handle complex automation tasks, its primary function is executing control logic, processing real-time data from connected I/O modules, and coordinating communication between system components. As a critical decision-making component, the GE IC697CPX9285 ensures seamless operation of industrial processes by interpreting inputs, applying programmed logic, and generating outputs to regulate machinery, sensors, and actuators.
What distinguishes the GE IC697CPX9285 is its balance of processing speed and memory capacity, enabling it to manage large-scale automation setups with hundreds of I/O points. It integrates seamlessly with the Series 90-70 ecosystem, including backplanes, I/O modules, and communication cards, making it a versatile choice for both new installations and system upgrades. By delivering reliable performance in demanding environments, the GE IC697CPX9285 minimizes downtime and enhances the efficiency of industrial control systems.
Technical Specifications
| Parameter |
Value |
| Product Model |
GE IC697CPX9285 |
| Manufacturer |
GE |
| Product Type |
PLC Central Processing Unit (CPU) |
| Processing Speed |
200 ns per instruction (typical) |
| Program Memory |
8 MB flash memory |
| Data Memory |
512 KB RAM |
| Compatible System |
GE Series 90-70 PLC systems |
| Communication Ports |
1 x RS-232, 1 x Ethernet (10/100 Mbps) |
| Operating Temperature |
0°C to 60°C (32°F to 140°F) |
| Power Requirements |
5V DC ±5% |
| Current Consumption |
1.2A typical |
| Dimensions |
120mm x 80mm x 150mm (L x W x H) |
| Mounting Type |
Series 90-70 chassis slot (10-slot compatible) |
| Compliance |
UL, CE, CSA certified |
| Weight |
Approximately 0.9kg |
Key Features and Benefits
The GE IC697CPX9285 stands out for its processing power, with a 200 ns instruction cycle that enables rapid execution of complex control algorithms—critical for applications where split-second decisions impact process efficiency or safety. This speed allows it to handle thousands of I/O points without latency, making it suitable for large-scale automation systems.
A major advantage is its generous memory capacity: 8 MB of flash memory for program storage ensures ample space for intricate control logic, while 512 KB of RAM supports real-time data processing. The flash memory retains programs even during power outages, eliminating the need for constant backups.
The GE IC697CPX9285 also excels in connectivity, featuring both RS-232 and Ethernet ports. This dual-interface design simplifies integration with human-machine interfaces (HMIs), SCADA systems, and other PLCs, enabling centralized monitoring and control. Built-in diagnostic tools provide real-time alerts for faults like communication errors or memory issues, reducing troubleshooting time.
Compatibility with all Series 90-70 modules—from I/O cards to communication adapters—ensures seamless system expansion. Its rugged design, rated for industrial temperatures, guarantees reliable operation in harsh environments, from factory floors to outdoor enclosures.
Application Scenarios
The GE IC697CPX9285 is a workhorse in industries requiring precise, high-speed automation. In power generation facilities, it serves as the brain of Series 90-70 systems controlling turbine governors, boiler feedwater pumps, and emissions monitoring equipment. The GE IC697CPX9285’s fast processing ensures rapid adjustments to load changes, maintaining grid stability and efficient power output.
In oil and gas refineries, where complex processes like distillation and catalytic cracking demand tight control, the GE IC697CPX9285 manages hundreds of I/O points—regulating valves, heaters, and pressure sensors. Its Ethernet port allows integration with plant-wide SCADA systems, enabling operators to monitor processes remotely and respond to anomalies quickly.
In large-scale manufacturing, such as automotive assembly plants, the GE IC697CPX9285 coordinates robotic arms, conveyor systems, and quality checks. Its ability to process multiple inputs simultaneously ensures synchronized operation across the production line, reducing bottlenecks and improving throughput.
Related Models
GE IC697CPX927 – Previous generation processor with a 300 ns instruction cycle, offering basic functionality for smaller systems.
GE IC697CPX935 – High-performance variant of the GE IC697CPX9285 with 16 MB flash memory and 1 GHz processing speed for ultra-large systems.
GE IC697CPX928 – Compact version with reduced memory (4 MB flash) but identical processing speed, ideal for mid-sized setups.
GE IC697CPX940 – Redundant processor designed to pair with the GE IC697CPX9285 for failover protection in mission-critical applications.
GE IC693CPX340 – Processor for GE’s Series 90-30 PLCs, sharing programming software with the GE IC697CPX9285 but optimized for smaller systems.
GE IC697CPX9286 – Enhanced model with integrated cybersecurity features, including encrypted communication protocols.
GE IC697CPX926 – Entry-level processor with a 500 ns cycle, serving as a cost-effective alternative to the GE IC697CPX9285 for simple control tasks.
Installation and Maintenance
Installation of the GE IC697CPX9285 requires a compatible Series 90-70 chassis (such as the IC697CHS790G), with a free slot in the 10-slot configuration. Ensure the chassis power supply provides stable 5V DC within the ±5% range to prevent damage to the GE IC697CPX9285. Prior to mounting, verify firmware compatibility with existing modules—updates may be needed for older I/O cards. Secure the processor firmly in the slot to avoid vibration-induced connection issues.
For maintenance, regularly use the GE IC697CPX9285’s diagnostic tools to check for memory errors or communication faults, ideally during scheduled downtime. Update firmware annually to access performance improvements and security patches. Inspect Ethernet and RS-232 connections quarterly to ensure tight fittings, as loose cables can disrupt data transfer. The GE IC697CPX9285 is designed for long service, but consider replacement every 8-10 years in harsh environments to avoid degradation in processing speed.
Product Warranty
The GE IC697CPX9285 is covered by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., protecting against manufacturing defects. During this period, we offer free replacement for any faulty units, ensuring minimal disruption to your operations. Our global technical support team provides assistance with installation, firmware updates, and troubleshooting, leveraging over a decade of experience in industrial automation. We stand behind the GE IC697CPX9285’s quality, sourced directly from trusted suppliers, and are committed to ensuring customer satisfaction through reliable service and responsive support.
