Product Overview
The GE IC697MDL240 is a 16-channel digital output module designed for seamless integration with GE’s Series 90-70 programmable logic controller (PLC) systems, serving as a critical interface between the PLC’s central processing unit (CPU) and external industrial devices. Its core function is to convert digital control signals from the CPU into actionable outputs, enabling the operation of equipment such as solenoid valves, motor starters, alarms, and indicator lights.
As a relay-based output module, the GE IC697MDL240 offers robust switching capabilities, making it ideal for controlling high-power devices in demanding environments. What sets it apart is its combination of reliability and flexibility: each channel operates independently, allowing precise control over individual devices without affecting the entire system. The GE IC697MDL240 integrates effortlessly with other Series 90-70 components, from CPUs to backplane modules, simplifying system design and upgrades. For industrial automation setups requiring dependable, high-current switching, the GE IC697MDL240 is a trusted solution that minimizes downtime and enhances operational efficiency.
Technical Specifications
| Parameter |
Value |
| Product Model |
GE IC697MDL240 |
| Manufacturer |
GE |
| Product Type |
Digital Output Module (Relay) |
| Number of Channels |
16 (independent) |
| Output Type |
Form C electromechanical relays |
| Rated Output Voltage |
24V DC |
| Maximum Current per Channel |
2A (resistive load) |
| Isolation |
Channel-to-channel: 250V AC rms |
| Operating Temperature |
0°C to 60°C (32°F to 140°F) |
| Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
| Dimensions |
120mm x 80mm x 150mm (L x W x H) |
| Mounting Type |
Series 90-70 chassis slot |
| Protection Features |
Overcurrent protection per channel |
| Weight |
Approximately 0.7kg |
| Compliance |
UL, CE, CSA certified |
| Relay Life |
100,000 operations (at rated load) |
Key Features and Benefits
The GE IC697MDL240 excels in providing reliable switching for industrial devices, thanks to its 16 independent channels that allow precise control over multiple pieces of equipment. This channel independence ensures that a fault in one device (e.g., a shorted valve) does not disrupt operation of the others, enhancing system resilience—a critical advantage in production lines where downtime is costly.
As a relay-based module, the GE IC697MDL240 offers robust performance with a 2A per channel current rating, making it suitable for powering high-demand devices like solenoid valves and small motor starters. The Form C relays (changeover contacts) provide flexibility, supporting both normally open (NO) and normally closed (NC) configurations to match diverse application needs.
Isolation between channels (250V AC rms) prevents electrical interference from affecting signal integrity, ensuring stable operation even in noisy industrial environments. The GE IC697MDL240 also features built-in overcurrent protection, safeguarding both the module and connected devices from damage due to overloads. Its seamless compatibility with all Series 90-70 components eliminates integration hurdles, while tool-less installation simplifies setup and reduces maintenance time.
Application Scenarios
The GE IC697MDL240 is widely deployed in industries where precise control of electromechanical devices is essential. In water and wastewater treatment plants, for example, it controls solenoid valves regulating water flow, sludge pumps, and chemical dosing systems. The GE IC697MDL240’s 16 channels allow operators to manage multiple valves across different treatment stages, ensuring efficient processing and compliance with quality standards.
In automotive manufacturing facilities, the GE IC697MDL240 integrates with Series 90-70 PLCs to activate robotic end-effectors, conveyor belt motors, and assembly line indicators. Its relay-based design handles the intermittent high currents of these devices, while channel independence ensures a single malfunctioning component doesn’t halt the entire line.
In food and beverage processing, the GE IC697MDL240 controls mixers, packaging machines, and sterilization equipment. Its rugged construction withstands the washdown environments common in these facilities, while reliable switching ensures consistent operation of critical processes like filling and capping, reducing product waste and downtime.
Related Models
GE IC697MDL241 – 32-channel variant of the
GE IC697MDL240, ideal for larger systems requiring more output points.
GE IC697MDL230 – Transistor-based digital output module with faster switching speeds, offering an alternative to the
GE IC697MDL240’s relay design.
GE IC697MDL242 – High-current version of the
GE IC697MDL240 with 5A per channel, suitable for heavier loads like large motor starters.
GE IC697MDL220 – Previous generation 16-channel module with basic functionality, superseded by the
GE IC697MDL240’s enhanced protection features.
GE IC697MDL250 – 8-channel compact variant, a space-saving option for smaller setups compared to the
GE IC697MDL240.
GE IC697MDL243 – Isolated version of the
GE IC697MDL240 with enhanced noise immunity for high-interference environments.
GE IC693MDL645 – Digital output module for GE’s Series 90-30 PLCs, sharing design principles with the
GE IC697MDL240 but for smaller systems.
Installation and Maintenance
Installation of the GE IC697MDL240 requires a free slot in a Series 90-70 chassis (e.g., IC697CHS790G), ensuring compatibility with the system backplane. Prior to mounting, verify that the connected devices operate within the module’s 24V DC and 2A per channel limits to prevent overloads. Secure wiring connections using appropriate terminals, ensuring tight fittings to avoid voltage drops or arcing. Ground the GE IC697MDL240 properly to minimize electrical noise, which can disrupt relay operation.
For maintenance, inspect the GE IC697MDL240 quarterly to check for loose wiring or signs of overheating (e.g., discolored terminals). Test each channel periodically using a multimeter to confirm proper switching functionality, as relay contacts can wear over time. Clean dust from the module’s surface annually to maintain airflow, particularly in dusty environments like foundries. While the GE IC697MDL240 is designed for long life, consider replacing it after 5-7 years in high-cycle applications to avoid unexpected relay failures.
Product Warranty
The GE IC697MDL240 is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., covering manufacturing defects and ensuring reliable performance. During this period, we offer free replacement for any faulty units, minimizing operational downtime for your industrial automation systems. Our technical support team is available globally to assist with installation guidance, troubleshooting, and compatibility questions, leveraging our decade of experience in industrial automation. We stand behind the GE IC697MDL240’s quality, sourced directly from trusted suppliers, and are committed to ensuring customer satisfaction through responsive service and dependable products.
