Product Overview
The IC697PWR711 is a robust power supply module designed specifically for GE’s 90-70 Programmable Logic Controller (PLC) system, serving as the critical energy source that powers interconnected modules within the control architecture. As a foundational component, IC697PWR711 converts incoming AC power to stable DC voltages, ensuring consistent and reliable operation of processors, I/O modules, communication cards, and expansion units in the 90-70 series.
What makes IC697PWR711 indispensable is its ability to deliver regulated power even in fluctuating industrial environments, where voltage spikes or drops are common. Its design prioritizes stability, with built-in protection mechanisms to safeguard sensitive electronics from overloads or short circuits. Compatible with all 90-70 backplanes—including models like IC697CHS7906 and IC697CHS791—IC697PWR711 supports modular system configurations, allowing users to scale their control setups without compromising power integrity. Whether in retrofits or new installations, this module ensures the 90-70 system operates with minimal downtime, making it a cornerstone of reliable industrial automation.
Technical Specifications
| Parameter |
Value |
| Product Model |
IC697PWR711 |
| Manufacturer |
GE |
| Product Type |
Power Supply Module (90-70 PLC Series) |
| Input Voltage |
100-240V AC (50/60 Hz) |
| Output Voltage |
5V DC ±5% (primary); 24V DC ±10% (auxiliary) |
| Output Current |
5V: 10A; 24V: 2A |
| Efficiency |
Up to 85% at full load |
| Operating Temperature |
0°C to 60°C (32°F to 140°F) |
| Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
| Dimensions |
105mm (L) x 80mm (W) x 25mm (H) |
| Weight |
Approx. 350g |
| Protection Features |
Overload, short-circuit, and overvoltage protection |
| Compatibility |
GE 90-70 backplanes (IC697CHS7906, IC697CHS791) |
| Certifications |
UL 508, CE, RoHS compliant |
Key Features and Benefits
The IC697PWR711 excels in power stability, a critical trait for industrial control systems where voltage fluctuations can disrupt logic execution or damage sensitive electronics. Its dual-output design—delivering 5V DC (for processors and digital modules) and 24V DC (for sensors and actuators)—eliminates the need for separate power supplies, simplifying system architecture and reducing potential failure points.
Built-in protection mechanisms are a standout feature. IC697PWR711 includes overload and short-circuit safeguards that automatically limit current during faults, preventing damage to connected modules. It also withstands input voltage variations from 100V to 240V AC, making it adaptable to global power grids and unstable industrial electrical systems—ideal for facilities with inconsistent power quality.
Efficiency is another strength: with up to 85% efficiency at full load, IC697PWR711 minimizes energy waste and heat generation, reducing cooling requirements in control cabinets. Its rugged construction, including a metal casing and reinforced connectors, ensures durability in harsh environments, resisting vibration, dust, and temperature swings common in factories, refineries, and power plants.
Installation is streamlined thanks to its plug-and-play compatibility with 90-70 backplanes, allowing quick integration during system setup or upgrades. This design also simplifies replacement, minimizing downtime when maintenance is needed.
Application Scenarios
The IC697PWR711 is widely deployed in industries relying on GE’s 90-70 PLCs for uninterrupted operation. In automotive manufacturing plants, it powers the control systems managing assembly lines, supplying stable voltage to robotic controllers, conveyor logic modules, and safety interlock sensors. Its overload protection is critical here, as sudden mechanical jams or sensor faults could otherwise damage expensive automation equipment.
In water and wastewater treatment facilities, IC697PWR711 ensures consistent power to pump controllers, valve actuators, and pH monitoring modules. Its ability to handle voltage fluctuations is valuable in these settings, where utility power can vary due to heavy motor loads from pumps and compressors.
Food and beverage processing plants also depend on IC697PWR711. It supplies power to temperature control modules, filling line sensors, and packaging equipment controllers, with its dust-resistant design maintaining reliability in environments where cleaning processes generate airborne particles.
Power generation facilities, including natural gas plants, use IC697PWR711 to support turbine control systems, ensuring processors and I/O modules regulating fuel flow and pressure receive stable power—critical for preventing costly shutdowns or equipment damage during grid fluctuations.
Related Models
IC697PWR710 – Lower-current variant (5V: 6A, 24V: 1A) ideal for small-scale 90-70 systems.
IC697PWR712 – High-capacity model (5V: 15A, 24V: 3A) designed for large 90-70 configurations with multiple modules.
IC697PWR720 – DC-input version (24V DC in) for applications with direct battery or solar power sources.
IC697PWR730 – Redundant power supply pairing with IC697PWR711 to provide failover capability in mission-critical systems.
IC697PWR740 – Compact model with 5V-only output, suitable for processor-focused 90-70 setups.
IC693PWR330 – Legacy power supply compatible with older 90-30 PLCs, serving as a predecessor to the 90-70 series modules like IC697PWR711.
IC697PWR711-T – Temperature-hardened variant operating in -20°C to 70°C, designed for outdoor or unheated industrial spaces.
Installation and Maintenance
Installing IC697PWR711 requires a compatible 90-70 backplane with an available power supply slot, typically located at the end of the chassis for easy access. Before installation, verify the input voltage matches the facility’s AC supply (100-240V) to prevent damage. Ensure the mounting surface—whether DIN rail or panel—is clean and secure, with at least 50mm of clearance around the module for heat dissipation. Proper grounding is essential: connect the module’s ground terminal to the system’s main ground bus to reduce electrical noise and enhance protection against surges.
For maintenance, inspect
IC697PWR711 semi-annually. Check for loose input/output connections, which can cause voltage drops or overheating. Clean dust from the module’s vents using compressed air to maintain cooling efficiency. Monitor the power LED—steady green indicates normal operation, while a blinking or red light signals a fault requiring investigation (e.g., overload or input voltage issues). Replace the module every 8–10 years, or sooner if it frequently triggers overload protection, to ensure consistent performance in critical systems.
Product Warranty
The IC697PWR711 is covered by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., which includes free replacement for units with manufacturing defects or performance issues under normal operating conditions. Our technical support team provides guidance on installation, troubleshooting, and compatibility with 90-70 systems, ensuring minimal downtime if issues arise. We stand behind the reliability of IC697PWR711, leveraging our decade of experience in industrial automation to deliver components that meet the rigorous demands of industrial environments. This warranty reflects our commitment to quality and customer satisfaction, ensuring you can trust IC697PWR711 to power your critical control systems.
