Product Overview
The IC697PWR711N is a robust power supply module engineered for GE’s Series 90-70 programmable logic controller (PLC) system, a cornerstone of industrial automation celebrated for its reliability in demanding environments. As the primary power source for Series 90-70 components, IC697PWR711N converts alternating current (AC) from the main supply into stable direct current (DC) voltages, ensuring consistent operation of CPUs, I/O modules, and communication interfaces—critical for maintaining uninterrupted industrial processes.
In automation setups, the stability of power delivery directly impacts system performance. The IC697PWR711N excels here by regulating output voltages even amid fluctuations in the input supply, protecting sensitive electronics from damage caused by surges or drops. Its design is fully integrated with Series 90-70 chassis, allowing for straightforward installation without additional adapters. What distinguishes IC697PWR711N is its blend of ruggedness and efficiency, making it a trusted power backbone for both small-scale control panels and large industrial systems.
Technical Specifications
| Parameter |
Value |
| Product Model |
IC697PWR711N |
| Manufacturer |
GE |
| Product Type |
Power Supply Module |
| Compatibility |
GE Series 90-70 PLC Systems |
| Input Voltage |
100-240V AC (50/60 Hz) |
| Output Voltage |
5V DC (main); 24V DC (auxiliary) |
| Output Current |
8A (5V DC); 0.3A (24V DC) |
| Efficiency |
Up to 82% at full load |
| Operating Temperature Range |
0°C to 60°C (32°F to 140°F) |
| Storage Temperature Range |
-40°C to 85°C (-40°F to 185°F) |
| Dimensions (H x W x D) |
127mm x 38mm x 146mm (5.0" x 1.5" x 5.75") |
| Mounting Type |
Rack-mounted (Series 90-70 chassis slot) |
| Protection Features |
Overload, short-circuit, and overvoltage protection |
| Cooling Method |
Convection cooling (fanless) |
| Weight |
Approximately 280g (0.62 lbs) |
Key Features and Benefits
The IC697PWR711N delivers stable 5V DC power to Series 90-70 components, ensuring consistent performance of CPUs and I/O modules even when the input supply fluctuates—common in industrial settings with heavy machinery. This stability prevents data corruption in the PLC’s memory and avoids unexpected shutdowns, a critical advantage in continuous-process industries like chemical manufacturing.
Built-in protection mechanisms are a standout feature of IC697PWR711N. Overload protection limits current output during electrical faults, such as a shorted I/O module, while short-circuit protection instantly cuts power to prevent damage to connected hardware. These safeguards extend the lifespan of expensive PLC components and reduce maintenance costs over time.
Efficiency is another strength, with up to 82% energy conversion at full load. This minimizes heat generation, allowing the module to operate reliably without a fan. The fanless design is ideal for dusty or humid environments—such as food processing plants or outdoor enclosures—where fan-driven cooling could introduce contaminants or fail due to moisture.
Compatibility with Series 90-70 chassis ensures seamless integration, with a plug-and-play design that simplifies setup. The 8A output at 5V DC easily supports typical system configurations, while the 24V DC auxiliary output (0.3A) can power low-energy devices like proximity sensors or status indicators, reducing reliance on external power sources.
Application Scenarios
The IC697PWR711N is indispensable in industrial environments where GE Series 90-70 PLCs manage critical processes. In automotive parts manufacturing, for example, production lines use PLCs to control stamping presses, robotic assemblers, and conveyor systems. The IC697PWR711N ensures these PLCs receive stable power, preventing sudden shutdowns that could misalign machinery or damage tooling—costly issues in high-volume production where even a 10-minute outage can disrupt schedules.
In municipal water treatment plants, the IC697PWR711N powers PLCs that regulate pump stations, filtration units, and chemical dosing systems. These plants often operate with variable grid power, especially in rural areas, making the module’s voltage regulation vital. By maintaining steady power to the PLC, it ensures consistent water flow rates and chemical mixing—essential for meeting drinking water standards and avoiding regulatory penalties.
For packaging facilities, the
IC697PWR711N supports PLCs controlling filling machines, sealers, and labeling systems. Its fanless design resists dust from cardboard or plastic materials, ensuring reliable operation in environments where airborne particles are common. Stable power delivery here prevents mislabeling or improper sealing, reducing product waste and maintaining brand quality.
Related Models
IC697PWR711 – Base model of IC697PWR711N with identical specifications, designed for standard industrial environments.
IC697PWR712 – Higher-capacity variant with 12A output at 5V DC, suitable for larger Series 90-70 systems with more I/O modules.
IC697PWR720 – Redundant power supply that pairs with IC697PWR711N for failover protection in mission-critical setups, such as nuclear power control rooms.
IC697PCM711 – Modernized successor to IC697PWR711N with enhanced efficiency (85%) and extended temperature range.
IC697PWR705 – Lower-output model (4A at 5V DC) for small-scale Series 90-70 systems, ideal for basic control tasks like lighting or valve control.
IC697PWR750 – DC-input variant (24-48V DC) compatible with IC697PWR711N-based systems in off-grid locations, such as remote oil rigs.
IC697CHS790 – 8-slot Series 90-70 chassis optimized to house IC697PWR711N and complementary modules, providing a compact system platform.
Installation and Maintenance
Installation of IC697PWR711N requires a dedicated power supply slot in the Series 90-70 chassis, with at least 30mm of clearance on all sides to facilitate convection cooling. Prior to mounting, confirm the input power source matches the 100-240V AC range and ensure proper grounding to minimize electrical noise. The module connects via the chassis backplane, and securing clips should be fully engaged to prevent disconnections in high-vibration areas, such as near industrial pumps.
For maintenance, inspect
IC697PWR711N quarterly for dust buildup on vents, cleaning gently with compressed air if needed. Measure output voltages periodically using a multimeter to ensure they remain within 5V ±5% and 24V ±10%—deviations may indicate component wear. Check for signs of overheating, such as discolored casing, which could signal impending failure. While the module is designed for 8–10 years of service, consider replacement if voltage regulation issues persist, as unstable power can compromise the entire PLC system.
Product Warranty
The IC697PWR711N is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., which includes free replacement service for any defects in materials or workmanship. As a trusted supplier with over a decade of experience in industrial automation, Xiamen Xiongba ensures the IC697PWR711N meets rigorous quality standards, sourced directly from reliable manufacturers to guarantee authenticity. Customers benefit from global technical support, with experts available to assist with installation guidance, troubleshooting, and warranty claims. This commitment ensures users of IC697PWR711N can operate with confidence, knowing reliable power supply performance is supported by responsive service and replacement options.
