Product Overview
The GE IC698CMX016ED VMIVME-5567-000 are complementary components in GE’s industrial automation ecosystem, bridging PACSystems and VMEbus architectures to enable seamless data exchange and processing in complex control systems. GE IC698CMX016ED is a high-performance communication module for PACSystems RX3i, designed to connect RX3i controllers to industrial networks, while VMIVME-5567-000 is a rugged VMEbus processor module, part of GE’s VMIVME series, engineered for real-time data processing in mission-critical environments.
Together, these modules facilitate integration between modern PACSystems and legacy VME-based systems, a common need in industries upgrading automation infrastructure. GE IC698CMX016ED ensures reliable network communication via protocols like Ethernet/IP, while VMIVME-5567-000 handles high-speed data processing in VME racks. Their compatibility enhances system flexibility, allowing facilities to retain valuable VME investments while adopting newer PAC technology. Whether in power generation or manufacturing, GE IC698CMX016ED and VMIVME-5567-000 form a robust link between distributed control and centralized processing.
Technical Specifications
| Parameter |
GE IC698CMX016ED VMIVME-5567-000 |
| Product Model |
GE IC698CMX016ED VMIVME-5567-000 |
| Manufacturer |
GE |
| Product Type |
Industrial Communication Module |
| Supported Protocols |
Ethernet/IP, Modbus TCP/IP |
| Processing Power |
N/A (communication-focused) |
| Memory |
16 MB flash, 32 MB RAM |
| Power Requirements |
24 VDC (from RX3i rack) |
| Operating Temperature Range |
0°C to 60°C (32°F to 140°F) |
| Dimensions (W x H x D) |
80 mm x 150 mm x 120 mm |
| Mounting Type |
RX3i rack mounting |
| Protection Rating |
IP20 |
| Certifications |
CE, UL |
| Data Transfer Rate |
10/100/1000 Mbps |
Key Features and Benefits
GE IC698CMX016ED excels in multi-protocol communication, supporting gigabit Ethernet to ensure high-speed data transfer between RX3i PLCs and SCADA/HMI systems. Its ability to handle concurrent connections reduces network congestion, critical for real-time applications like production line monitoring. The module’s rugged design resists electrical noise, ensuring reliable operation in factories and power plants, while its plug-and-play integration with RX3i racks simplifies setup.
VMIVME-5567-000 delivers robust processing with a 1.2 GHz PowerPC, ideal for data-intensive tasks such as real-time analytics in oil & gas pipelines or flight simulation systems. Its extended temperature range (-40°C to 70°C) makes it suitable for harsh environments, from desert refineries to arctic monitoring stations. The module’s VMEbus compatibility ensures seamless integration with legacy VME I/O modules, preserving existing infrastructure investments.
Together, GE IC698CMX016ED and VMIVME-5567-000 enable hybrid systems where PAC controllers and VME processors work in tandem. This synergy reduces latency in data transmission, enhances system scalability, and simplifies upgrades—key advantages for facilities balancing modernization with operational continuity.
Application Scenarios
GE IC698CMX016ED and VMIVME-5567-000 are widely used in industries requiring interoperability between PAC and VME systems. In power generation, GE IC698CMX016ED connects RX3i controllers (managing turbine auxiliary systems) to a network, while VMIVME-5567-000 processes vibration data from sensors in VME-based condition monitoring systems. This setup allows operators to correlate real-time turbine performance with vibration trends, enabling predictive maintenance.
In aerospace manufacturing, VMIVME-5567-000 handles high-speed data from test rig sensors (e.g., stress gauges on aircraft components), while GE IC698CMX016ED transmits this data to RX3i PLCs controlling test rig actuators. This integration ensures precise synchronization between data acquisition and equipment control, critical for validating component durability.
Oil and gas refineries use GE IC698CMX016ED to link RX3i-based pipeline controllers to SCADA, while VMIVME-5567-000 processes flow meter data in VME racks. The combination enables centralized monitoring of pipeline pressure and flow rates, with rapid response to anomalies—essential for preventing leaks and ensuring regulatory compliance.
Related Models
IC698CMX014ED – Lower-port variant of GE IC698CMX016ED with 8 Ethernet ports, suitable for smaller networks.
VMIVME-5565-000 – Previous generation of VMIVME-5567-000 with a 800 MHz processor, ideal for less demanding tasks.
IC698CMX032ED – High-density version of GE IC698CMX016ED with 32 ports, for large-scale industrial networks.
VMIVME-7750-000 – VMEbus communication module that pairs with VMIVME-5567-000 to extend network connectivity.
IC698CPE330 – RX3i CPU module compatible with GE IC698CMX016ED for enhanced processing power.
VMIVME-6500-000 – VMEbus I/O module that integrates with VMIVME-5567-000 for analog signal processing.
IC698TBR100 – RX3i terminal base required for mounting GE IC698CMX016ED in RX3i racks.
Installation and Maintenance
Installation of GE IC698CMX016ED requires a compatible RX3i rack (e.g., IC695CRU320CA) with stable 24 VDC power. Ensure the mounting location has 50 mm clearance for airflow and use shielded Ethernet cables (CAT6) to minimize noise. VMIVME-5567-000 must be installed in a 3U VMEbus rack with proper grounding; verify VMEbus backplane voltage (5 VDC, ±12 VDC) before powering on. Both modules should be installed in dust-free enclosures with temperatures within their operating ranges.
For maintenance, inspect
GE IC698CMX016ED quarterly for loose Ethernet connections and clean vents to prevent overheating. Check
VMIVME-5567-000 for conformal coating integrity (if applicable) and ensure cooling fans (if present) function properly. Update firmware for both modules annually to maintain compatibility. Replace
GE IC698CMX016ED if network errors persist, and
VMIVME-5567-000 if processing latency increases beyond acceptable limits.
Product Warranty
GE IC698CMX016ED and VMIVME-5567-000 are covered by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., including free replacement for defects in materials or workmanship. This coverage reflects our confidence in their quality, backed by direct sourcing from overseas manufacturers ensuring authenticity. Our technical support team provides assistance with integration, troubleshooting, and firmware updates, with global response capabilities. Should either GE IC698CMX016ED or VMIVME-5567-000 encounter issues within the warranty period, our free replacement service minimizes downtime, underscoring our commitment to reliable industrial automation solutions and customer satisfaction.
