Product Overview
The IC698CPE030 is a high-performance central processing unit (CPU) module designed for GE’s PACSystems RX3i programmable automation controller (PAC) system, a advanced platform in industrial automation known for its flexibility and processing power. As the core of the RX3i system, IC698CPE030 executes complex control logic, manages data flow between I/O modules and external devices, and enables seamless integration with industrial networks—making it a vital component in modern automation setups.
In industrial environments, the ability to handle diverse tasks—from discrete machine control to process regulation—requires a CPU that balances speed, memory, and connectivity. The IC698CPE030 excels here, offering robust processing capabilities to support large user programs and real-time data processing. Its design prioritizes scalability, allowing users to expand I/O capacity or add communication modules without sacrificing performance. What sets IC698CPE030 apart is its adaptability, making it suitable for both small-scale machines and large, distributed control systems, while maintaining the reliability GE is known for.
Technical Specifications
| Parameter |
Value |
| Product Model |
IC698CPE030 |
| Manufacturer |
GE |
| Product Type |
CPU Module |
| Compatibility |
GE PACSystems RX3i Series |
| Processor |
32-bit ARM Cortex-A9, 800 MHz |
| Memory |
256 MB RAM; 512 MB flash (user program storage) |
| Communication Ports |
2 x 10/100/1000 Ethernet (RJ45); 1 x USB 2.0 |
| Supported Protocols |
Ethernet/IP, Modbus TCP/IP, PROFINET (via add-ons) |
| Power Requirements |
5V DC, 1.5A (from RX3i backplane) |
| Operating Temperature Range |
0°C to 60°C (32°F to 140°F) |
| Storage Temperature Range |
-40°C to 85°C (-40°F to 185°F) |
| Dimensions (H x W x D) |
130mm x 40mm x 180mm (5.1" x 1.6" x 7.1") |
| Mounting Type |
Rack-mounted (RX3i chassis slots) |
| Protection Rating |
IP20 (dust-protected, indoor use) |
| Max I/O Capacity |
Up to 8,192 digital points; 1,024 analog points |
| Redundancy Support |
Yes (with compatible modules) |
Key Features and Benefits
The IC698CPE030 delivers exceptional processing power with its 32-bit ARM Cortex-A9 processor running at 800 MHz, enabling rapid execution of complex control logic—from motion control algorithms to batch processing sequences. This speed ensures minimal latency between sensor input and actuator response, critical for high-precision applications like semiconductor manufacturing or synchronized packaging lines.
Expanded memory—256 MB RAM and 512 MB flash—allows the IC698CPE030 to handle large user programs and store extensive historical data, eliminating the need for external memory devices. This is particularly valuable in industries like pharmaceuticals, where detailed batch records are required for regulatory compliance and process optimization.
Dual Gigabit Ethernet ports support high-speed communication with HMIs, SCADA systems, and other PACs, facilitating real-time data exchange across large industrial networks. Compatibility with Ethernet/IP and Modbus TCP/IP simplifies integration with third-party equipment, while optional PROFINET support extends connectivity to European-standard automation components—reducing integration time and costs.
Redundancy capabilities make the IC698CPE030 ideal for mission-critical applications. When paired with redundant power supplies and communication modules, it ensures seamless failover in the event of a primary CPU fault, minimizing downtime in industries like power generation or oil refining where even brief outages are costly.
Built-in diagnostics, accessible via GE’s Proficy Machine Edition software, provide real-time insights into CPU load, memory usage, and network status. This allows engineers to proactively address issues—such as excessive I/O traffic or communication bottlenecks—before they impact operations, enhancing overall system reliability.
Application Scenarios
The IC698CPE030 is well-suited for industries requiring advanced control of complex, interconnected processes. In semiconductor fabrication, for example, precision is paramount—etching, deposition, and inspection tools must operate within micrometer tolerances. The IC698CPE030 coordinates these tools, executing intricate recipes that control temperature, pressure, and chemical flow with sub-second accuracy. Its high processing speed ensures that feedback from optical sensors—monitoring wafer alignment—is processed instantly, preventing costly defects.
In renewable energy facilities, such as solar farms, the IC698CPE030 manages inverter systems, tracking systems, and grid integration. It processes data from thousands of solar panels—including voltage, current, and efficiency—to optimize power output, while communicating with a central SCADA system to balance load and prevent grid overloads. Its redundancy support is critical here, as downtime directly reduces energy production and revenue.
For food and beverage manufacturers with multi-stage production lines, the
IC698CPE030 integrates mixing, cooking, and packaging processes. It coordinates conveyor speeds with filling machines, adjusts oven temperatures based on product type, and logs data for batch traceability. The dual Ethernet ports connect to HMIs on the floor (for operator control) and corporate networks (for production analytics), enabling both real-time adjustments and long-term process optimization.
Related Models
IC698CPE010 – Entry-level RX3i CPU with 400 MHz processor and 128 MB RAM, suitable for small-scale applications requiring basic control.
IC698CPE020 – Mid-range variant with 600 MHz processor, bridging the performance gap between IC698CPE010 and IC698CPE030.
IC698CPE040 – High-performance upgrade of IC698CPE030 with 1 GHz processor and 1 GB RAM, designed for large-scale, data-intensive systems.
IC698ETM001 – Ethernet expansion module that adds 2 additional ports to IC698CPE030, enhancing network flexibility.
IC698PWR330 – Redundant power supply module optimized for use with IC698CPE030 in mission-critical setups.
IC698CMM320 – Communication module enabling IC698CPE030 to interface with PROFIBUS networks, expanding compatibility with European industrial equipment.
IC698TBM200 – Terminal base module that provides physical mounting and backplane connectivity for IC698CPE030 in RX3i chassis.
Installation and Maintenance
Installation of IC698CPE030 requires a compatible GE RX3i chassis (such as IC698CHS110) with an available CPU slot, ensuring at least 50mm of clearance for airflow to dissipate heat from the 800 MHz processor. Prior to mounting, verify the chassis is properly grounded to minimize electromagnetic interference, which can disrupt high-speed communication. The module connects via the RX3i backplane, with securing screws tightened to 0.4 Nm to prevent movement in high-vibration environments. Ambient conditions should remain within 0°C to 60°C, with relative humidity below 95% (non-condensing) to maintain performance.
For maintenance, regular checks using Proficy Machine Edition are recommended to monitor IC698CPE030’s CPU load (aim to keep below 70% during peak operation) and memory usage. Inspect Ethernet ports quarterly for dust or corrosion, cleaning gently with compressed air if needed. Firmware updates should be applied annually to access new protocol support and security patches. While the module is designed for 10+ years of service, consider replacement if consistent performance degradation or communication errors occur despite troubleshooting, to avoid unplanned downtime in critical processes.
Product Warranty
The IC698CPE030 is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., which includes free replacement service for any defects in materials or workmanship. As a specialist in industrial automation with over a decade of experience, Xiamen Xiongba ensures the IC698CPE030 meets strict quality standards, sourced directly from trusted manufacturers to guarantee authenticity and performance. Customers benefit from global technical support, with experts available to assist with installation guidance, software configuration, and warranty claims. This commitment to quality ensures users of IC698CPE030 can operate with confidence, knowing reliable support and replacement options are readily available to minimize downtime and maintain system efficiency.
