Product Overview
The IC698CPE030-HN is a high-performance processor module serving as the central computing core of GE’s 90-80 Programmable Logic Controller (PLC) system, engineered to handle complex industrial control tasks with precision and efficiency. As the "brain" of the 90-80 architecture, IC698CPE030-HN executes control logic, processes real-time data from connected I/O modules, and manages communication across industrial networks—with the "-HN" suffix indicating enhanced networking capabilities, likely optimized for seamless integration with modern Ethernet-based systems.
This processor stands out for its balance of processing power and connectivity, making it ideal for medium to large-scale automation setups where data flow between devices and higher-level systems is critical. Compatible with the full range of 90-80 modules and backplanes (such as the IC698CHS017), IC698CPE030-HN enables flexible system design, allowing users to scale operations or upgrade legacy setups without sacrificing performance. Its rugged design ensures reliability in harsh industrial environments, solidifying its role as a trusted solution for maintaining operational continuity in mission-critical applications.
Technical Specifications
| Parameter |
Value |
| Product Model |
IC698CPE030-HN |
| Manufacturer |
GE |
| Product Type |
Advanced Processor Module (90-80 PLC Series) |
| Processing Speed |
50 MHz 32-bit RISC processor |
| Memory |
16 MB RAM, 8 MB EEPROM (user program storage) |
| Communication Ports |
2 x Gigabit Ethernet, 1 x RS-232 |
| Supported Protocols |
Ethernet/IP, Modbus TCP/IP, GE SRTP, Profinet (enhanced via HN) |
| Power Requirements |
5V DC ±5% (via 90-80 backplane) |
| Operating Temperature |
0°C to 60°C (32°F to 140°F) |
| Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
| Dimensions |
108mm (L) x 82mm (W) x 26mm (H) |
| Weight |
Approx. 200g |
| Compatibility |
GE 90-80 backplanes (IC698CHS017, IC698CHS012) |
| Certifications |
UL 508, CE, RoHS, IEC 61131-2 compliant |
Key Features and Benefits
The IC698CPE030-HN delivers exceptional processing performance, driven by a 50 MHz 32-bit RISC processor that executes up to 15,000 instructions per millisecond. This speed enables it to handle complex control logic—such as multi-stage batch processes or synchronized motion control in manufacturing—with minimal latency, ensuring precise, real-time responsiveness to changing conditions.
The "-HN" designation highlights its enhanced networking capabilities: dual Gigabit Ethernet ports and support for Profinet and Ethernet/IP make it a powerful hub for connecting to SCADA systems, MES platforms, and cloud-based analytics tools. This seamless integration simplifies the transition to smart manufacturing, allowing facilities to collect, analyze, and act on operational data in real time.
Expanded memory (16 MB RAM, 8 MB EEPROM) supports large user programs, historical data logging, and advanced diagnostics, eliminating the need for external memory modules in most applications. This reduces system complexity and potential failure points, enhancing overall reliability.
Built for industrial durability, IC698CPE030-HN withstands vibration, voltage fluctuations, and extreme temperatures, ensuring reliable operation in harsh environments like chemical plants or outdoor industrial sites. Its plug-and-play compatibility with 90-80 backplanes simplifies installation and upgrades, minimizing downtime during system modifications.
Application Scenarios
The IC698CPE030-HN is widely deployed in industries requiring robust processing and advanced networking. In automotive component manufacturing, it serves as the core processor for production lines, executing logic that controls CNC machines, robotic assembly arms, and quality inspection systems. Its enhanced Ethernet capabilities enable real-time data sharing with plant-wide MES systems, optimizing production scheduling and reducing waste.
In water treatment facilities, IC698CPE030-HN manages filtration and chemical dosing processes, processing data from flow meters and pH sensors to maintain regulatory compliance. Its Profinet support allows integration with remote monitoring tools, enabling operators to adjust settings from central control rooms without on-site visits.
Food and beverage processing plants rely on IC698CPE030-HN for batch control, where its fast processing ensures precise timing of mixing, heating, and packaging stages. The "-HN" networking features facilitate connectivity with traceability systems, logging ingredient data and processing times to meet food safety standards.
In pharmaceutical manufacturing, IC698CPE030-HN controls sterile filling lines, leveraging its processing power to manage complex sequence logic while its Ethernet ports connect to validation systems, ensuring compliance with FDA regulations for process documentation.
Related Models
IC698CPE020-HN – Previous generation processor with a 30 MHz speed, suitable for medium-complexity applications.
IC698CPE031-HN – High-memory variant with 32 MB RAM, designed for large-scale program execution and extended data logging.
IC698CPE030 – Non-HN variant with standard Ethernet (10/100 Mbps) and limited protocol support.
IC698CMM311 – Ethernet communication module that enhances IC698CPE030-HN’s network redundancy capabilities.
IC698PWR330 – Power supply module optimized for use with IC698CPE030-HN in 90-80 backplanes.
IC698CPE040-HN – Next-generation model with 75 MHz processor and 5G-ready networking for future-proofing.
IC698I/O201 – Digital I/O module commonly paired with IC698CPE030-HN to expand input/output capacity.
Installation and Maintenance
Installing IC698CPE030-HN requires a compatible 90-80 backplane (such as IC698CHS017) with an available processor slot. Ensure the backplane is powered down before insertion to prevent electrostatic damage, and align the module with guide rails for a secure fit. Proper grounding is critical—connect the backplane’s grounding terminal to the facility’s main ground bus to minimize electrical noise and protect against surges. The module’s networking features require Cat 6 Ethernet cables for Gigabit performance; verify cable routing to avoid interference from high-voltage lines.
For maintenance, inspect IC698CPE030-HN quarterly to ensure secure backplane connections—loose contacts can cause communication drops or erratic performance. Clean the module’s surface with a dry cloth to remove dust, which can trap heat. Check firmware versions annually via Ethernet and update to the latest release to access performance improvements and security patches. Replace the module every 10–12 years, or sooner if it exhibits frequent communication errors, to maintain optimal reliability.
Product Warranty
The IC698CPE030-HN is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., covering manufacturing defects and performance issues under normal operating conditions. During the warranty period, we provide free replacement of faulty units to minimize operational downtime. Our technical support team offers expert guidance on installation, protocol configuration, and troubleshooting, leveraging deep expertise in GE 90-80 systems. We stand behind the durability and performance of IC698CPE030-HN, confident in its ability to meet the rigors of industrial environments. This warranty reflects our commitment to customer satisfaction and our reputation as a trusted supplier of industrial automation components.
