Product Overview
The GE IC755CSS15CDA is a high-performance communication interface module designed for GE’s advanced industrial control systems, particularly the QuickPanel+ HMI series and PACSystems. As a critical connectivity hub, GE IC755CSS15CDA enables seamless data exchange between HMIs, PLCs, and remote devices, supporting both real-time operational data transmission and bidirectional control commands. Its integration into GE’s automation ecosystem makes it a versatile solution for bridging different system components, ensuring that operators have instant access to critical metrics while allowing for timely adjustments to processes.
What sets GE IC755CSS15CDA apart is its robust protocol support and industrial-grade durability, making it suitable for harsh environments with electrical noise, vibration, and temperature fluctuations. Whether deployed in manufacturing plants, power facilities, or process industries, GE IC755CSS15CDA maintains stable communication, reducing the risk of data loss or system lag that could impact productivity. Its compact design and plug-and-play compatibility further simplify integration into existing setups, minimizing downtime during installation or upgrades.
Technical Specifications
| Parameter |
Value |
| Product Model |
GE IC755CSS15CDA |
| Manufacturer |
GE |
| Product Type |
Industrial Communication Interface Module |
| Compatible Systems |
GE QuickPanel+ HMIs, PACSystems RX3i/7i PLCs, Mark VIe DCS |
| Supported Protocols |
Ethernet/IP, Modbus TCP/IP, Profibus DP, OPC UA |
| Data Transfer Rate |
Up to 1 Gbps (Ethernet/IP); 12 Mbps (Profibus DP) |
| Operating Temperature |
-10°C to 60°C (14°F to 140°F) |
| Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
| Power Requirements |
24V DC (from system backplane or external supply) |
| Power Consumption |
6.2W typical |
| Dimensions |
105mm x 130mm x 28mm (4.1" x 5.1" x 1.1") |
| Weight |
Approx. 230g (0.51 lbs) |
| Mounting Type |
QuickPanel+ backplane slot; compatible with standard 35mm DIN rail |
| Protection Rating |
IP20 (suitable for panel mounting in enclosed industrial cabinets) |
Key Features and Benefits
GE IC755CSS15CDA excels in multi-protocol flexibility, supporting a range of industry-standard communication protocols to connect diverse system components. This eliminates the need for multiple specialized modules, simplifying system architecture and reducing integration costs—especially valuable in facilities with mixed-vendor equipment. Its high data transfer rate (up to 1 Gbps via Ethernet/IP) ensures that large volumes of real-time data, such as sensor readings or equipment status updates, are transmitted without latency, critical for time-sensitive applications like synchronized production lines.
Durability is a core strength, with a rugged design that withstands industrial stressors including vibration, electromagnetic interference, and wide temperature ranges. This reliability ensures consistent performance in demanding environments, from factory floors to power plant control rooms, minimizing unplanned downtime.
Installation and configuration are streamlined by GE IC755CSS15CDA’s plug-and-play compatibility with GE’s QuickPanel+ HMIs and PACSystems, requiring minimal technical expertise. Its compact form factor saves space in control cabinets, while built-in diagnostic tools provide real-time alerts for communication issues, enabling quick troubleshooting and reducing maintenance time.
Application Scenarios
GE IC755CSS15CDA is widely used in industries requiring seamless connectivity between control systems and HMIs. In automotive manufacturing, it links QuickPanel+ HMIs to PACSystems RX3i PLCs controlling robotic assembly lines, transmitting data on robot positions, weld quality, and production counts. This allows operators to monitor line performance in real time and adjust parameters to optimize throughput.
In chemical processing plants, GE IC755CSS15CDA facilitates communication between HMI terminals and DCS modules managing reactor systems, ensuring that temperature, pressure, and chemical flow data are relayed instantly. Operators can use this data to make timely adjustments, preventing process deviations that could affect product quality or safety.
Water and wastewater treatment facilities rely on GE IC755CSS15CDA to connect HMIs with PLCs controlling pump stations and filtration systems. It ensures that data on water levels, flow rates, and equipment health is transmitted reliably, supporting efficient operation and regulatory compliance.
Related Models
GE IC755CSS10CDA – Compact 10-port variant of
GE IC755CSS15CDA with reduced protocol support, ideal for smaller-scale systems.
GE IC755CSS20CDA – Higher-capacity model with 20 communication ports, designed for large industrial networks.
GE IC754CSS15CDA – Previous generation of
GE IC755CSS15CDA with limited Ethernet speed (100 Mbps vs. 1 Gbps).
GE QuickPanel+ 2000 – HMI terminal fully compatible with
GE IC755CSS15CDA for seamless integration.
GE IC698CPE030-GJ – PACSystems RX3i CPU module that pairs with
GE IC755CSS15CDA for enhanced control capabilities.
GE IC755CSS15CRA – Ruggedized variant of
GE IC755CSS15CDA with IP65 protection for outdoor installations.
Installation and Maintenance
Installing GE IC755CSS15CDA requires a compatible QuickPanel+ backplane slot or 35mm DIN rail in a protective enclosure, with ambient temperatures between -10°C and 60°C. Ensure proper grounding (≤4Ω resistance) to minimize electromagnetic interference, which can disrupt communication. Allow at least 40mm of clearance around the module for ventilation and wiring access. Verify that the 24V DC power supply is stable before connecting to prevent damage.
For maintenance, inspect GE IC755CSS15CDA quarterly to check for loose connections or corrosion on ports, tightening terminals as needed. Use GE’s diagnostic software to monitor communication status and address error alerts promptly. Clean dust from vents annually with compressed air to prevent overheating. Consider replacing the module every 8–10 years in high-vibration environments to maintain optimal performance.
Product Warranty
GE IC755CSS15CDA is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., covering manufacturing defects and performance issues under normal operating conditions. During the warranty period, we provide free replacement for any faulty units, ensuring minimal disruption to your operations. Our global technical support team offers assistance with installation, protocol configuration, and troubleshooting, leveraging over a decade of industrial automation expertise. We stand behind the quality of GE IC755CSS15CDA, ensuring it meets the rigorous demands of industrial communication systems.
