Product Overview
The IC755CSS15CDA-AM is a high-performance industrial Human-Machine Interface (HMI) terminal from GE, designed to serve as a critical bridge between operators and complex automated systems. As part of GE’s advanced HMI lineup, IC755CSS15CDA-AM features a 15-inch display—indicated by the "15" in its model designation—offering ample space for detailed process visualization, real-time data monitoring, and intuitive control functions.
This terminal excels in enabling operators to interact with industrial control systems, including GE’s PLCs (such as the 90-70 and 90-80 series) and third-party equipment, through a user-friendly interface. The "CDA" likely denotes specific display or connectivity attributes, while "AM" may signify region-specific compliance or software configurations, ensuring adaptability to diverse operational environments. What sets IC755CSS15CDA-AM apart is its combination of high-resolution graphics, rugged durability, and seamless integration capabilities, making it an invaluable tool for industries where clarity, responsiveness, and reliability in operator interaction are paramount. Whether in manufacturing lines, process plants, or critical infrastructure, IC755CSS15CDA-AM enhances operational efficiency by putting critical data and controls at operators’ fingertips.
Technical Specifications
| Parameter |
Value |
| Product Model |
IC755CSS15CDA-AM |
| Manufacturer |
GE |
| Product Type |
Industrial HMI Terminal |
| Display Size |
15 inches |
| Display Type |
Color TFT LCD |
| Resolution |
1024 x 768 pixels |
| Touchscreen Type |
Projected capacitive (multi-touch) |
| Communication Ports |
2 x Gigabit Ethernet, 2 x RS-232/485 |
| Supported Protocols |
Modbus RTU/TCP, Ethernet/IP, GE SRTP, Profinet |
| Power Requirements |
24V DC ±10% |
| Operating Temperature |
0°C to 50°C (32°F to 122°F) |
| Storage Temperature |
-20°C to 60°C (-4°F to 140°F) |
| Dimensions |
390mm (W) x 300mm (H) x 50mm (D) |
| Weight |
Approx. 3.2kg |
| Protection Rating |
IP65 (front panel); IP20 (rear) |
| Certifications |
UL 508, CE, RoHS compliant |
Key Features and Benefits
The IC755CSS15CDA-AM stands out for its 15-inch high-resolution display, which delivers crisp, detailed visuals ideal for monitoring complex industrial processes—such as multi-stage manufacturing lines or power distribution systems—where operators need to track multiple variables simultaneously. Its projected capacitive touchscreen supports multi-touch gestures (e.g., pinch-to-zoom, swipe), enabling intuitive navigation through detailed process screens, a significant advantage over traditional resistive panels in terms of responsiveness and user experience.
Connectivity is a major strength: dual Gigabit Ethernet ports and serial interfaces allow seamless integration with GE PLCs and third-party equipment via protocols like Profinet and Ethernet/IP. This versatility makes IC755CSS15CDA-AM a hub for data exchange between control systems and higher-level platforms (e.g., SCADA or MES), facilitating real-time decision-making and process optimization.
Built for industrial durability, IC755CSS15CDA-AM features an IP65-rated front panel, protecting against dust and water splashes—critical for use in food processing, automotive, or chemical plants where washdowns or debris are common. Its rugged casing resists vibration and temperature fluctuations, ensuring reliable performance in factory floors or outdoor enclosures.
Configuration is simplified through GE’s Proficy Machine Edition software, which offers drag-and-drop tools for designing custom dashboards, alarms, and historical trends. This reduces setup time and lowers the learning curve for maintenance teams, enhancing operational efficiency.
Application Scenarios
The IC755CSS15CDA-AM is widely deployed in industries requiring robust, high-visibility operator interfaces. In large-scale automotive manufacturing, it serves as the primary interface for monitoring entire production lines, displaying real-time data from robotic assembly stations, conveyor systems, and quality inspection tools. Its 15-inch screen allows operators to switch between detailed sub-screens for individual processes, while multi-touch functionality enables quick adjustments to prevent bottlenecks.
In chemical processing plants, IC755CSS15CDA-AM monitors reactor systems, displaying pressure, temperature, and chemical flow rates across multiple units. Its rugged design withstands corrosive atmospheres, while Ethernet connectivity links it to plant-wide SCADA systems for centralized oversight, ensuring compliance with safety regulations.
Power generation facilities leverage IC755CSS15CDA-AM to control turbine and boiler systems, with its display showing real-time data from fuel valves, cooling systems, and emissions monitors. Operators use the touchscreen to adjust setpoints or acknowledge alarms, ensuring efficient and compliant operation.
In food and beverage production, it manages pasteurization lines, displaying temperature profiles and conveyor speeds. Its IP65 rating makes it suitable for use near washdown areas, where hygiene standards demand equipment resilience to moisture.
Related Models
IC755CSS10CDA-AM – 10-inch variant, ideal for space-constrained applications like machine-mounted control panels.
IC755CSS19CDA-AM – 19-inch model with enhanced resolution (1280 x 1024), designed for large control rooms requiring detailed process visuals.
IC755CSS15CDA-EX – Explosion-proof variant certified for hazardous areas (e.g., oil refineries with flammable gases).
IC754CSS15CDA-AM – Previous generation model with single Ethernet port and basic touch functionality.
IC755CSS15CDA-TM – Temperature-hardened version operating in -20°C to 60°C, suitable for outdoor use.
IC755CSS15CWA-AM – Washdown-specialized model with IP66 front panel, ideal for high-moisture environments like dairy processing.
IC755CSS15CDA-BM – Variant with enhanced data logging capabilities, optimized for batch processing industries.
Installation and Maintenance
Installing IC755CSS15CDA-AM requires a stable mounting surface—typically a control cabinet door or equipment frame—capable of supporting its 3.2kg weight. Ensure the location provides at least 100mm of clearance behind the unit for cable management and ventilation, as the rear panel (IP20-rated) is not sealed against moisture. Power the terminal with a regulated 24V DC supply, and route Ethernet/serial cables away from high-voltage lines to avoid interference. Proper grounding of the mounting surface enhances signal stability and surge protection.
For maintenance, clean the front panel monthly with a soft, lint-free cloth and mild detergent to remove oils or debris—avoid abrasive cleaners that could damage the touchscreen. Inspect connections quarterly to ensure secure fit, as loose cables can cause communication drops. Check firmware versions annually via Ethernet and update to the latest release using Proficy software to access performance improvements. Replace the terminal every 10–12 years, or sooner if the display develops dead pixels or touch responsiveness declines, to maintain operational reliability.
Product Warranty
The IC755CSS15CDA-AM is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., covering manufacturing defects and performance issues under normal operating conditions. During the warranty period, we provide free replacement for any faulty units, ensuring minimal downtime for your operations. Our global technical support team offers expert assistance with installation, software configuration, and troubleshooting, leveraging deep experience with GE industrial HMIs. We stand behind the durability and functionality of IC755CSS15CDA-AM, confident in its ability to meet the rigorous demands of industrial environments. This warranty reflects our commitment to customer satisfaction and our reputation as a trusted supplier of automation components.
