Product Overview
The IC755CSW07CDA is a high-performance communication module from GE, designed to enhance connectivity within the RX3i PLC system—a cornerstone of GE’s industrial automation portfolio. As a critical interface component, it facilitates seamless data exchange between the RX3i controller and external devices, including human-machine interfaces (HMIs), SCADA systems, and other PLCs, enabling centralized monitoring and control in complex automation environments.
Integral to the IC755 series, IC755CSW07CDA specializes in translating PLC data into formats compatible with diverse industrial protocols, ensuring interoperability across mixed-vendor systems. What sets IC755CSW07CDA apart is its balance of speed and reliability, supporting high-throughput data transfer while withstanding the harsh conditions of factory floors, water treatment plants, and power facilities. Its plug-and-play design simplifies integration into existing RX3i setups, making it a valuable asset for both system upgrades and new installations, where uninterrupted communication is key to operational efficiency.
Technical Specifications
| Parameter |
Value |
| Product Model |
IC755CSW07CDA |
| Manufacturer |
GE |
| Product Type |
Communication Module (RX3i PLC System) |
| Supported Protocols |
Ethernet/IP, Modbus TCP/IP, Profibus DP |
| Communication Ports |
2 x Ethernet (RJ45), 1 x Profibus DP |
| Data Transfer Rate |
Up to 100 Mbps (Ethernet), 12 Mbps (Profibus) |
| Power Requirements |
24 VDC ±10% |
| Operating Temperature |
0°C to 60°C (32°F to 140°F) |
| Dimensions |
120 mm x 80 mm x 40 mm (4.7 in x 3.1 in x 1.6 in) |
| Mounting Type |
DIN rail (35 mm) in RX3i rack |
| Protection Rating |
IP20 (dust-protected for control cabinets) |
| Certification |
CE, UL 61010-1 |
| Compatibility |
GE RX3i PLC controllers (IC695CPU315, IC695CPU331) |
Key Features and Benefits
The IC755CSW07CDA delivers exceptional protocol flexibility, supporting Ethernet/IP, Modbus TCP/IP, and Profibus DP to connect the RX3i PLC with legacy and modern systems alike. This eliminates the need for multiple gateway devices, reducing hardware complexity and integration costs—especially valuable in facilities undergoing automation upgrades.
High-speed data transfer ensures real-time communication, with 100 Mbps Ethernet ports enabling rapid exchange of process data between the PLC and HMI or SCADA systems. This speed is critical for time-sensitive applications, such as packaging lines or water treatment plants, where delayed data could disrupt process control.
Reliability is a standout trait of IC755CSW07CDA. Its rugged design withstands temperature fluctuations and electrical noise common in industrial environments, while built-in diagnostics continuously monitor port status and data flow, alerting operators to issues like cable faults or protocol mismatches via GE’s Proficy Machine Edition software. This proactive monitoring minimizes downtime and simplifies troubleshooting.
Installation is streamlined, with plug-in connectivity to the RX3i rack and intuitive configuration via GE’s software, reducing commissioning time. The module’s compact size optimizes rack space, making it suitable for both large control cabinets and space-constrained enclosures.
Application Scenarios
The IC755CSW07CDA is widely used in industries relying on GE RX3i PLCs for automation. In manufacturing, it connects assembly line PLCs to SCADA systems, enabling centralized monitoring of conveyor speeds, robotic arm positions, and quality control sensors—critical for automotive plants aiming to optimize production throughput and reduce defects.
Water and wastewater treatment facilities utilize IC755CSW07CDA to link RX3i controllers with HMI panels and remote monitoring systems, facilitating real-time adjustments to pump speeds, valve positions, and chemical dosing based on water quality data. This ensures compliance with regulatory standards and efficient resource usage.
Power generation plants deploy the module to connect PLCs controlling boiler feed pumps and turbine auxiliary systems to the plant’s DCS, enabling coordinated operation and quick response to load changes. Its Profibus support is particularly valuable here, integrating with legacy motor drives while maintaining compatibility with modern Ethernet-based systems.
Related Models
IC755CSW06CDA – Previous generation with limited protocol support, serving as the foundation for IC755CSW07CDA.
IC755CSW08CDA – Enhanced variant with 4 Ethernet ports, ideal for large-scale systems requiring multiple connections.
IC755CSW07CDE – ATEX-certified model for explosive environments, such as chemical processing plants.
IC755CSW07CDB – Compact version with reduced dimensions, designed for space-constrained RX3i racks.
IC755CSW07CDF – Extended-temperature variant (-20°C to 70°C), suitable for outdoor installations like solar farms.
IC755CSW10CDA – High-speed model with 1 Gbps Ethernet, optimized for data-intensive applications like robotics.
Installation and Maintenance
Installation of IC755CSW07CDA requires a 35 mm DIN rail in the RX3i rack, with adequate clearance for ventilation to prevent overheating. Ensure the operating environment stays within 0°C to 60°C, with low humidity to avoid condensation. Verify the 24 VDC power supply is stable and properly grounded to minimize electrical interference. When connecting cables, use shielded Ethernet and Profibus lines, routing them away from high-voltage wiring to preserve signal integrity.
For maintenance, inspect IC755CSW07CDA quarterly to check for loose connections or dust accumulation on ports, which can impede performance. Clean with compressed air if needed. Use GE’s Proficy software monthly to run diagnostic tests, verifying protocol functionality and data transfer rates. Update firmware annually via the software to access the latest security patches and protocol enhancements. Replace cables every 3–5 years to prevent signal degradation from wear or corrosion.
Product Warranty
The IC755CSW07CDA is backed by a one-year warranty from Xiamen Xiongba E-commerce Co., Ltd., covering defects in materials and workmanship under normal operating conditions. This warranty includes free replacement service for any module found faulty within the coverage period, reflecting our confidence in its reliability. Our global support team provides technical assistance with installation, configuration, and troubleshooting, ensuring seamless integration of IC755CSW07CDA into your RX3i system. We are committed to minimizing downtime and supporting the efficiency of your industrial automation operations through responsive service.
