Product Details: H201TI Continuous Dissolved Gas Analysis (DGA) monitor Composite gas sensor
The HydranTM 201Ti is a compact mounted continuous Solution in oil (DGA) monitor. It provides the basic information used by the IEEE@standard C57.104 and can be used as basic
The first provides a line of defense for transformers in the fleet to obtain advance warning of failure conditions to minimize the risk of unplanned downtime.
The 201Ti's composite gas sensor uses a fuel cell to deliver the world famous "Hydran gas value "technology (described as a stationary instrument). Method 3 of the standard). Its reaction to hydrogen is 100%(- general failure
Gas), is also sensitive - carbon oxide (overheated paper), acetylene (arc and zene (overheated oil), thus covering the root cause of all main transformer failures. Since the monitoring unit is mounted on a single valve, and
Dynamic oil sampling is used, so there is no need for a pump or additional piping to connect to different valves. Due to its uncomplicated features and the easy-to-understand information it provides, the 201Ti has become the monitor's
Choose one of the largest installed bases of any monitor over the years. With the latest Mark IV version, the Hydran 201Ti indicator has been completely revamped with new electronic circuit boards and power supplies
RoHS compliant, fixes any outdated issues and advances this time-proven product. It now offers additional features such as:
Improved sensor
.modbus@protocol communication isolation RS-485
The local USB port to replace the RS-232 port is no longer available on most field laptops
Compatible with GE's acclaimed PerceptionTM Fleet software download, trend and analyze data like any other GE DGA monitoring device
Key benefits
Continuous measurement of major H2 fault gas
Local LCD display
Remote communication of gas ppm values
Proven and constantly improving design (over 30,000 units sold)
Easy to install, single valve mounting
The 201T can be connected to an optional controller to prevent the creation of a local network when communicating with multiple elements. The Ci-1 controller is a part of the human single-channel controller interface that replicates functions (gas values
Alarm button). It is ideal for 201i installation on the valve in the upper part of the transformer. It also reduces alarm relay contacts and analog outputs for easy wiring.
The Ci-C controller receives gas ppm data for up to four H201Ti, providing a single point of communication for all four monitors. It has no alarm relay or analog output. When protecting 3 single-phase transformers + 1
When this is ideal for backup.
Up to 32 controllers or 201Ti ports can be "Daisy chained" with the RS-485. The large chain distance (all cables combined) is 1200m(4000 ft). All connected to any Daisy chain controller
The 201 Ti can be passed through any controller in the local network, thus facilitating communication by simply having an RS 232 modem as an example.
