The IC697CPM790 is a 64 MHz CPU manufactured by Agfanuc with computing power using a 32-bit floating point and a microprocessor 80486DX2. The CPU uses a single slot for Windows or Windows
Programming software MS-DOS performs configuration and programming.
The IC697CPM790 includes up to 12K discrete inputs and outputs (mixed simplex mode only). It has flash memory dedicated to the operating system firmware, allowing access through the connection between the PC and the module serial port
Row firmware update. The user can program the software or control the operation of the module by running/stopping the operation mode of the three-position switch. Memory-protected keys or software passwords lock configuration and program data.
The IC697CPM790 has four green leds that indicate the status of the CPU. Air cooling requires fan assemblies. Donkey can connect the bus transmitter module IC697BEM713 to the programmer of the parallel interface. with
A 15-pin Type D connector connects the serial port, which is compatible with RS-485. During actual operation and power-up, the CPU verifies the rack configuration while its alarm function reports the programming and/or actual configuration
Set any deviation. The IC697CPM790 is equipped with a lithium battery that keeps the calendar clock running, data storage and program storage.
It is important to note that the IC697CPM790 module must be used with a separate C program that provides E-mode redundancy (TMR) operation and automated test procedures. Unless the process is included in the loaded application
Program, otherwise it won't run.
The following option modules are supported :IC697 LAN interface module, programmable coprocessor, female digital display coprocessor, bus controller for IC660/661/0 products, communication module, /O link interface
To absorb the IC697 series discrete and analog /O modules.
The IC697CPM790 is a 90-70 series Programmable Logic controller (PLC) CPU. The CPU is a single-slot wide module designed for emergency shutdowns of systems, disasters, gas, and other applications
Key application. The CPU supports 3 = heavy media redundancy (TMR) through a console and independent C program to enable automated test routines.
The IC697CPM790 has 1 MB of battery-operated memory, of which up to 512 KB is available for user programs configured using the ladder programming language. When configured in single I mode, the CPU
Support up to 12K arbitrary combination of discrete input and output points; 2048 discrete vote inputs and 2048 discrete vote outputs. Similarly, IC697CPM790 votes in simplex mode and 1024
Capable of handling any combination of analog inputs and outputs up to 8K when run under analog inputs. It is equipped with an 80486DX2 microprocessor with a clock speed of 64 MHz. The CPU has relatively relatively
Fast scan rate, 0.4 microseconds per Boolean function, suitable for critical applications.
The IC697CPM790 supports Triple module redundancy (TMR), which allows the system to avoid downtime. This TMR setup essentially consists of a triple PLC rack with one (1) of each rack
The IC697CPM790 CPU, triple Genius I/O bus, and triple input sensor and triple output load.
The IC697CPM790 is equipped with one (1) 15-pin Sub-D connector that allows communication with RS485 compatible devices. Other forms of communication, such as a connection to a programming computer, can be used
Rs-422 / RS-485 to RS 232 converters with part number IC690ACC900 or RS-232 to RS-422 microconverters with part number IC690ACC901.
The IC697CPM790 programmable controller CPU is also suitable for critical industrial and commercial safety-related applications, such as fire and gas related applications and ESD or emergency shutdown systems. It uses...
Windows or MS-DOS software is programmed and capable of communicating with I/O modules and smart options modules installed in the same PLC system via a rack-mounted backplane. IC697CPM790 can
A programming controller CPU cannot run unless it contains a stand-alone C program as part of an application loaded by the CPU.
The IC697CPM790 programmable controller CPU must be used with stand-alone C programs to run TMR or triple module redundancy as well as automated test and operation routines. The CPU has 1 MB
Battery-operated memory, up to 512 KB of memory available for ladder diagram programs. The IC697CPM790 programmable controller CPU can handle up to 12,000 arbitrarily mixed discrete inputs and outputs
As long as both inputs and outputs are in simplex mode, and it can handle up to 2048 discrete inputs and up to 2048 discrete outputs. Other features of the CPU include configurable programs and
Data storage, 4 LED status indicators, password-controlled machine access, 3-bit operating mode control switch and a battery-operated calendar clock.
