The IC754VSI12CTD is a QuickPanel terminal manufactured by General Electric (GE), which is an industrial operator terminal. Machine operators can simply use it to monitor their applications or to monitor, control, and adjust their applications.
The device has a 12-inch screen size with color graphics support. The operator can operate with a fingertip (with or without gloves) or a stylus, as long as the stylus tip is not too thin or sharp. On the screen, it is forbidden to use sharp objects or blunt and heavy objects, as they may damage the screen.
In addition, the IC754VSI12CTD touch screen terminals can be used as part of a network or as stand-alone devices. It weighs 10 pounds and measures 8 x 14 x 16 inches. This touchscreen is programmed using Professional View Machine Edition programming software and comes with the Windows CE operating system.
GE IC754VSI12CTD module
The GE IC754VSI12CTD is an industrial operator terminal that is a color touch screen 1.
The industrial operator terminal has a 12-inch wide screen with color graphics and can be used with fingertips (with or without gloves) or a stylus. It weighs 10 pounds, measures 8x14x16 inches, and can be accessed via RS-232
The message port, RS-485 communication terminal [] and GE Fanuc HMI-CAB-C110 communication cable communicate with other devices in the network 1.
GE IC754VSI12CTD Technical description
Technical specifications for the GE IC754VSI12CTD include:
Pre-installed Microsoft Windows Compact Embedded (CE) operating system, providing a user-friendly environment with standard Microsoft Windows commands and features.
Support 10/100 Mbps transmission rate Ethernet communication interface.
Control commands are entered via a touch screen, allowing the operator to enter commands directly by touching the appropriate runtime icon or object.
Use a single RS232/RS485 combination port to communicate with the controller in a point-to-point or multipoint serial topology1.
The GE IC754VSI12CTD features the following:
Enables the advanced ARM Cortex-A8 processor and color TFT screen 1.
Built-in Windows CE 6.0 operating system, support a variety of communication interfaces, including RS232, RS485 and Ethernet 1.
It has the characteristics of fast response, easy operation, stable and reliable.
It has excellent protective properties, can adapt to various harsh environments, and ensure long-term stable operation.
Any operator or user can monitor or control the connected machine or process2 through the provided monitor, touch input connection [and communication connection].
The display screen can provide visualization of the process through custom design 2.
GE IC754VSI12CTD Application areas
The GE IC754VSI12CTD operating panel is mainly used in factory floor HMI (Human Machine Interface) 1.
Manufactured by General Electric (GE) Fanuc Automation, the panel comes pre-loaded with the Microsoft Windows Compact Embedded (CE) operating system, which provides any operation
Staff or users are familiar with the configuration and maintenance interface. It not only provides a user-friendly environment, but also standard Microsoft Windows commands and features such as File Transfer Protocol, Pocket Internet
Explorer, etc. 1.
GE IC754VSI12CTD benefits:
It uses an advanced ARM Cortex-A8 processor and a color TFT screen1.
Supports a variety of communication interfaces, including RS232, RS485 and Ethernet 1.
It has good protective performance, can adapt to various harsh environments, and ensure long-term stable operation.
A touch-screen operating interface with a variety of I/O options, a variety of standard ports and expansion buss2 capable of connecting most I devices.
In the event of a sudden power outage, the program remains in flash memory, and user data can remain in SRAM, which is fully battery-supported 2.
