Model IS200EBKPG1A
Brand GE
Category, analog module
The IS200EBKPG1A is an EX2100 excitation control backplane for analog modules.
The analog module is the EX2100 excitation control backplane.
IS200EBKPG1A Excitation control backplane is an analog input/output module used to control the AC power supply of the exciter. By adjusting the current size and direction of the AC power supply of the exciter, the magnetic field strength and direction of the exciter are controlled to achieve the normal operation of the exciter.
The function of the IS200EBKPG1A analog module is to control the AC power supply of the exciter, and control the magnetic field strength and direction of the exciter by adjusting the current size and direction of the AC power supply of the exciter, so as to achieve the normal operation of the exciter.
The difference between analog and digital quantities:
Different definitions. The IS200EBKPG1A analog is continuous in both time and value. Numerical quantities are discrete in time and value.
The transmission mode is different. During analog transmission, it is not only subject to noise interference, but also susceptible to transmission line effect interference. When digital transmission, optical fiber transmission is usually used, which can effectively avoid external interference, so the reliability of digital transmission is higher.
The resolution is different. The analog resolution is low; High resolution of digital quantity.
Analog input/output data are signed integers.
In the S7-200, the value range of unipolar analog input/output signal is 0~32000; The value range of the bipolar analog signal is -32000~32000. The analog is represented in PLC as an integer value between -32000 and +32000, but in reality the value can be the entire range of 16-bit signed integers.
