The IS200VSVOH1B is a board component manufactured by General Electric for the Mark VI. Mark VI was released by GE,
The series began as part of its long-popular Speedtronic series of gas steam turbine management
In the 1960s, the company released the Mark l system. The Mark VI and Mark VIe turbine control lines continued to evolve until the 2000s. Mark VI includes Ethernet communication aid
The operator interface of the PC and integrated hardware and software designed specifically for turbine control
IS200VSVOH1B is a control board in the servo control system produced by the United States General Company, which is mainly used in the VME bus system. This control board, with the action of a servo control (VSVO) board, controls the position of the steam and fuel valves by directing the four electro-hydraulic servo valves that operate the steam/fuel valves. In addition, it uses a linear variable differential transformer to determine valve position and perform loop control algorithms.
The IS200VSVOH1B control panel is commonly used in gas turbine control systems to control the position of steam and fuel valves to ensure the normal operation of the gas turbine. In addition, it can be used in other industrial automation and control applications that require precise control of steam and fuel valves.
The IS200VSVOH1B is a board component manufactured by General Electric for the Mark VI. The Mark VI was released by GE as part of its long-popular Speedtronic series of gas steam turbine management, which began
In the 1960s, the company released the Mark I system. Until the 2000s, the turbine control lines of the Mark VI and Mark Vle were continuously developed. The Mark VI includes Ethernet communication capabilities, an operator interface for the PC, and integrated hardware and software specifically designed for turbine control.
IS200VSVOH1B is used as servo control board. The board drives the fuel steam valve by controlling four electro-hydraulic servo valves. The board also provides pulse rate flow input, LVDT excitation, and LVDT position feedback.
IS200VSVOH1B can be used in triple redundant systems and can be used in simplex systems.
The IS200VSVOH1B has a single-slot front panel connected to the PCB. The panel includes a cable connector (J5) and LED indicators for status information. The three leds on the front panel include - a RUN
Light (green), a FAIL light (color), and a STATUS light. The STATUS lamp is usually not powered on. However, if an alarm occurs, the ED will power up and appear as a stable orange color.
The IS200VSVOH1B has six connectors, including two backplanes (P1/P2) and four connectors made of conductive trace lines (P3 to P6). The board includes four relays (K1 to K4). Each of these components
The top surface of each has a printed drawing. Resistors, capacitors and TP test points are installed on the circuit board. It also has an inductor bead (L1-L10). The board has more than 70 integrated circuits.
