Brand: MOOG
Model: J869-1001A
Product type: Servo valve
Payment method: Wire transfer, Western Union
Port of shipment for remittance: Xiamen, China
Delivery time: 1-3 working days
Condition: New and 100% original
Warranty: 12 months
Product characteristicsJ869-1001A servo valve is mainly used for hydraulic pressure control, in the electro-hydraulic servo system, it can accept the electrical analog signal, and the corresponding output modulated flow and pressure. As an electro-hydraulic conversion component and power amplifier component, it can convert low-power electrical input signals into high-power hydraulic energy (flow and pressure) outputs.
Material and structure: The product is made of metal material and has a high-performance bipolar design. The pilot stage is a symmetrical double nozzle and baffle structure, driven by a double air gap, and the motor is a dry torque type. The output stage is a four-way slide valve. Mechanical feedback to the spool position is provided by a cantilever spring.
Flow control: At 7.0Mpa valve rated pressure drop, the J869-1001A can control rated flow from 3.2 to 64L/min.
Application: Due to its simple design, high stability and good repeatability, the J869-1001A servo valve is ideal for industrial automatic control applications where high stability and high repeatability are required.
Main application areas:Aerospace industry: In the aerospace industry, servo valves are widely used in flight control systems, engine control systems, and various hydraulic actuation systems. The J869-1001A plays a key role in these complex and demanding systems with its high accuracy, high reliability and fast response.
Marine and Marine engineering: In Marine and Marine engineering, servo valves are used in various ships' propulsion systems, steering gear control systems, stable fin control systems, etc. The J869-1001A servo valve meets the precise control and fast response requirements of these systems.
Heavy machinery and manufacturing: In heavy machinery and manufacturing, servo valves are used in hydraulic systems of various large equipment, such as injection molding machines, die casting machines, iron and steel metallurgy equipment, etc. The high performance of the J869-1001A meets the high precision, high efficiency and stability requirements of these devices.
Energy and power industry: In the energy and power industry, servo valves are used in the control systems of various generator sets, wind turbines, hydroelectric generators, etc. The high reliability and precision of the J869-1001A ensure the stable operation and efficient generation of these power plants.
