The brand SARTORIUS
Name, micro electronic balance
Model number MDB-8E
MDB-8E SARTORIUS
The SARTORIUS MDB-8E is a high-precision, high-performance electronic scale that uses unique digital signal processing technology for extreme accuracy and stability. The electronic scale is widely used in various industrial fields, such as pharmaceutical, chemical, food, medical and so on.
Product specification
· Weighing mode: Electronic · Display mode: LCD · Unit of measurement :g,kg, lb,oz· Communication interface :RS232C· Housing material: stainless steel. Protection level :IP54 application field
The SARTORIUS MDB-8E scale is widely used in the following areas:. Pharmaceutical industry: for the weighing and mixing of pharmaceuticals.
. Chemical industry: used for weighing and mixing chemical reagents. Food industry: Used for weighing and mixing food. Medical industry: Used for weighing and measuring medical supplies.
Regardless of the field, the SARTORIUS MDB-8E electronic scale provides high precision, high stability weighing services, and is an indispensable tool for a variety of industries.
Product description
The MDB-8E load cell is actually a device that converts a mass signal into a measurable electrical output. The use of sensors should first consider the actual working environment of the sensor, which is the correct choice
Weighing sensor is very important, it is related to the normal operation of the sensor and its safety and service life, and even the reliability and safety of the whole weighing device.
There are qualitative differences between old and new countries in the basic concepts and evaluation methods of the main technical indicators of weighing sensors. There are mainly S-type, cantilever type, spoke type, plate ring type, diaphragm type, bridge type, cylinder-cylinder type and so on.
According to the conversion method, MDB-8E weighing sensor is divided into photoelectric type, hydraulic type, electromagnetic force type, capacitive type, magnetic pole variable form, vibration type, gyro ceremony, resistance strain type and other 8 categories. The photoelectric type includes grating type and code disk type. The grating sensor uses the moire fringe formed by the light shed to convert the angular displacement into an photoelectric signal. The grating has two pieces, a fixed grating and a moving grating mounted on the dial axis. The measured object added to the bearing table rotates the dial axis through the force transfer lever system, drives the moving grating to rotate, and makes the Moire fringe move with it. Using photocell, conversion circuit and display instrument, we can calculate the number of moire fringes moved and measure the rotation Angle of the grating, so as to determine and read the quality of the measured object.
